Quadratic Optimality of the

Zero-Phase Repetitive Control

Hakan Ko¨rog˘lu

e-mail: koroglu@ee.bilkent.edu.tr

O

¨ mer Morgu¨l

Bilkent University, Department of Electrical &

Electronics Engineering, Bilkent, 06533, Ankara, Turkey

We consider the quadratically optimal repetitive control problem in discrete-time and show that the existing zero-phase repetitive controller is quadratically optimal for stable plants.

关DOI: 10.1115/1.1389310兴

I Introduction

In the beginning of the 80s, the study on the control strategies for the tracking/rejection of 共unknown兲 periodic signals 共with known period兲 evolved as a new discipline, which then began to be referred to as ‘‘repetitive control.’’ The design of discrete-time repetitive controllers was considered by Tomizuka et al. in关1兴 and a prototype repetitive controller was developed using the zero phase error tracking controller 共ZPETC兲 of 关2兴. This was then modified in关3,4兴 for the improvement of the stochastic behavior and the stability robustness. Though studied in关3兴, the optimality of the modified zero-phase repetitive control is not fully elabo-rated. In this note, we first study the quadratically optimal repeti-tive control problem in Section 2 and then show in Section 3 that the modified zero-phase repetitive controller is quadratically opti-mal for stable plants.

II Quadratically Optimal Repetitive Control

In this section, we derive a condition for the quadratic optimal-ity of discrete-time repetitive control systems. We consider the linear time-invariant feedback system of Fig. 1 with a periodic x

⫽r⫺d signal of the form x共t兲⫽

兺

i⫽0 n⫺1

Xm共␻i兲cos共␻it⫹␪i兲, (1)

where n is the period, Xm(␻i) are the magnitudes of the signal at

␻i⫽2␲i/n, and ␪i are the phases. As is well known, periodic

signals of period n contain n frequencies given by␻i⫽2␲i/n;

i⫽0, . . . ,n⫺1 and can be expressed as in 共1兲. Next, we consider

the quadratic cost defined by

J⫽

兺

where Em(␻i) and Um(␻i) denote the magnitudes of,

respec-tively, the error共e兲 and the control input 共u兲 signals at␻i, and␭is

denote non-negative constants. By the minimization of the qua-dratic cost of共2兲, the tracking error, as well as the control input, are kept small when the reference (r)/disturbance共d兲 signals are periodic with period n. In fact, this cost has a time-domain equiva-lent, which is also quadratic共see 关5兴兲. The values of ␭is determine

the level of penalization on the power of the control input at the frequencies present in the considered periodic signals. With ␭i

⫽0, the tracking error is minimized 共in a quadratic sense兲 by the

minimization of this cost. In the sequel, we will call the systems minimizing this cost as quadratically optimal.

In the following theorem, we give the condition on L⫽PC for the minimization of J. For notational simplicity, we use H(␻) to denote H(ej␻_).

Theorem 1. Consider the control system of Fig. 1 with the x ⫽r⫺d signal of 共1兲 and assume that the system is stable. The

feedback system is quadratically optimal with␭iif and only if

L共␻i兲⫽␭i⫺1兩P共␻i兲兩2; ᭙i,i⫽0, . . . ,n⫺1. (3)

The optimal cost is given by

Jopt_⫽

兺

i⫽0

n⫺1

共1⫹␭i⫺1兩P共␻i兲兩2兲⫺1兩Xm共␻i兲兩2. (4)

Proof: It follows from the feedback system relations that 兩Um(␻i)兩⫽兩C(␻i)储S(␻i)储Xm(␻i)兩 and 兩Em(␻i)兩

⫽兩S(␻i)储Xm(␻i)兩, where S⫽1/(1⫹L). Thus we can express J as

J⫽

兺

i⫽0

n⫺1

共1⫹␭i兩C共␻i兲兩2兲兩S共␻i兲兩2兩Xm共␻i兲兩2.

With T defined as T⫽L/(1⫹L), we have 兩S兩2_{⫽兩1⫺T兩}2 _and

兩C兩2_兩S兩2_⫽兩P兩⫺2_兩T兩2_{. Expanding兩1⫺T兩}2_{, we can write} J⫽

兺

the term in the square brackets in兩G(␻i)兩2parentheses and

com-pleting the squares, we can reorganize this expression as

J⫽

兺

i⫽0

n⫺1

兩G共␻i兲兩2兩T共␻i兲⫺兩G共␻i兲兩⫺2兩2兩Xm共␻i兲兩2⫹Jopt.

Contributed by the Dynamic Systems and Control Division for publication in the JOURNAL OFDYNAMICSYSTEMS, MEASUREMENT,ANDCONTROL. Manuscript received by the Dynamic Systems and Control Division June 30, 2000. Associate Editor: J. Tu.

Fig. 1 Unity feedback control system

554 Õ Vol. 123, SEPTEMBER 2001 Copyright©2001 by ASME Transactions of the ASME

If T(␻i)⫽兩G(␻i)兩⫺2 is satisfied for all i, then J will be

mini-mum, as Jopt_{is a term that is independent of C(␻}

i). Using the

inverse relation L⫽T/(1⫺T), this condition can be transformed to L(␻i)⫽(兩G(␻i)兩2⫺1)⫺1, which is equivalent to 共3兲. If the

controller is not of restricted complexity, it is always possible to find a stable closed-loop that satisfies共3兲, and this proves the only if part.

Remark 1. If Xm(␻i)⫽0 for some i, it is not necessary to have

the conditions of共3兲 satisfied at those i.

III Quadratic Optimality of the Zero-Phase Repetitive Control

Discrete-time modified repetitive control structures are formed by the inclusion of the modified delayed positive feedback unit in the feedback loop. This unit has the transfer function given by

CR共z兲⫽

F共z兲z⫺n

1⫺F共z兲z⫺n, (5)

where n is the period of the considered signals and F is a stable low-pass filter which satisfies兩F(␻)兩⭐1. In order to preserve the internal stability, this unit should be accompanied with an appro-priate controller. The prototype repetitive controllers developed by Tomizuka et al. in关1,3,4兴 use the ZPETC of 关2兴 as the accom-panying part. ZPETC was developed originally for feedforward tracking purposes. If the transfer function of a stable and causal plant is denoted as P(z)⫽z⫺␦P_N

P(z⫺1)/DP(z⫺1), with NP and

DP being coprime numerator/denominator polynomials having

nonzero leading coefficients and ␦P being the plant delay, the

ZPETC is given by CZP共z兲⫽ z␦P_D P共z⫺1兲NP⫺共z兲 储NP⫺储⬁2NP⫹共z⫺1兲 . (6)

Here, NP⫹and NP⫺denote, respectively, the stable共i.e., cancelable兲

and the unstable共i.e., noncancelable兲 parts of NP, and储N⫺P储⬁ is

defined as储NP⫺储⬁⫽sup␻兩NP⫺(e⫺ j␻)兩. Thus, the modified

repeti-tive controller is formed as

CZPR共z兲⫽kCR共z兲CZP共z兲, (7)

where k denotes a scalar which is usually referred to as the repeti-tive control gain. The control system of Fig. 1 is stable with C

⫽CZPR for a stable plant P, if k苸(0,2) and 兩F(␻)兩⭐1. For the

controller to be implementable, we should, moreover, have n

⭓␦P⫹deg NP⫺⫺␦F, where ␦F is the filter delay 共i.e. F(z)

⫽z⫺␦F_N

F(z⫺1)/DF(z⫺1)兲, which is allowed to be negative. The

perfect repetitive controller structure of关1兴, which supplies zero tracking error, can be recovered with F⫽1.

The modified form of the repetitive controller共i.e., the repeti-tive controller with F⫽1兲 offers improved stability robustness 关4兴 and stochastic behavior 关3兴 at the cost of degraded tracking/ rejection performance especially over the high-pass band. We show below that it also minimizes the quadratic cost of共2兲 if F is a filter of zero-phase nature共as proposed in 关4,6兴兲.

Theorem 2. Let the plant of the control system of Fig. 1

have a causal and stable transfer function P given by P(z)

⫽z⫺␦P_N

P(z⫺1)/DP(z⫺1). The feedback system will be

quadrati-cally optimal with C⫽CZPR if F is chosen as F(z)

⫽M(z⫺1_{) M (z), where M is a polynomial with a degree less than}

or equal to n⫺␦P⫺deg NP⫺. The ␭is of the optimized cost are

given by

␭i⫽

储NP⫺储⬁2共兩M共␻i兲兩⫺2⫺1兲兩NP⫹共␻i兲兩2

k兩DP共␻i兲兩2

. (8)

The optimum value of the cost with these␭is is

JZPR opt_⫽

兺

冉

冊

Proof: The loop gain of the feedback system with P

and C⫽CZPR can be found as LZPR(z)

⫽k储NP⫺储⬁⫺2NP⫺(z)NP⫺(z⫺1)CR(z). Since e⫺ j␻in⫽1 for ␻i

⫽2␲i/n, we have LZPR(␻i)⫽k储N⫺P储⬁⫺2兩NP⫺(␻i)兩2F(␻i)(1

⫺F(␻i))⫺1. With F(z)⫽M(z⫺1) M (z), we have F(␻i)

⫽兩M(␻i)兩2 and thus LZPR(␻i)s are all zero-phase. Hence by

Theorem 1, the feedback system with CZPRis quadratically

opti-mal with ␭i⫽LZPR⫺1(␻i)兩P(␻i)兩2, which can be found as in共8兲.

Inserting共8兲 in 共4兲, we can find the optimum cost for this case as in共9兲.

Remark 2. It is possible to verify the well-known facts about the

tracking/rejection performance of the perfect and the modified re-petitive control systems via the help of共8兲 and 共9兲. For the perfect repetitive control case, we have F⫽M⫽1 and thus ␭i⫽0. Hence,

in this case we have no penalization on the power of the control input and the cost to be minimized is simply the variance of the tracking error. With␭i⫽0, we have JZPR

opt_{⫽0, which means that}

perfect discrete-time repetitive control systems supply zero track-ing error. In the modified repetitive control case, F共and thus M兲 is-usually-of low-pass nature and hence␭is are small for is which

are close to 0 or n, and large for␭is which are close to n/2. This

corresponds to more penalization on the power of the control in-put over the high-pass band and thus degraded tracking/rejection performance at the high frequency region.

IV Concluding Remarks

We considered the quadratically optimal repetitive control problem and have shown that the modified zero-phase repetitive controllers are quadratically optimal for stable plants. As pointed out in关3兴, the zero-phase repetitive controller can be constructed for an unstable plant by first stabilizing this plant via an inner loop, and then using the transfer function of the stabilized loop. In this case, the overall system will not necessarily be quadratically optimal 共with the cost defined using the original control input兲. This is because the stabilizing controller will affect the control input to the plant. Yet, a quadratically optimal repetitive controller structure can be developed for general共i.e., stable as well as un-stable兲 plants by using the ideas and techniques presented in 关5兴. This will be a generalization of the zero-phase repetitive control for general plants and is left for a future work.

References

关1兴 Tomizuka, M., Tsao, T. C., and Chew, K. K., 1989, ‘‘Analysis and synthesis of discrete-time repetitive controllers,’’ ASME J. Dyn. Syst., Meas., Control,

111, No. 3, pp. 353–358.

关2兴 Tomizuka, M., 1987, ‘‘Zero phase error tracking algorithm for digital con-trol,’’ ASME J. Dyn. Syst., Meas., Control, 109, No. 1, pp. 65–68. 关3兴 Chew, K. K., and Tomizuka, M., 1990, ‘‘Steady-state and stochastic

perfor-mance of a modified discrete-time prototype repetitive controller,’’ ASME J. Dyn. Syst., Meas., Control, 112, No. 1, pp. 35–41.

关4兴 Tsao, T. C., and Tomizuka, M., 1994, ‘‘Robust adaptive and repetitive digital tracking control and application to hydraulic servo for noncircular machin-ing,’’ ASME J. Dyn. Syst., Meas., Control, 116, No. 1, pp. 24–32. 关5兴 Ko¨rog˘lu, H., and Morgu¨l, O¨., 1999, ‘‘Discrete-time LQ optimal repetitive

control,’’ Proceedings of American Control Conference, San Diego, CA, June, pp. 3287–3291.

关6兴 Tomizuka, M., 1993, ‘‘On the design of digital tracking controllers,’’ ASME J. Dyn. Syst., Meas., Control, 115, No. 2B, pp. 412–418.
