Balkon, teras, çatı ve yer süzgeçleri: S 10 ve S 15 serisi Balcony, terrace, roof and floor drains: Series S 10 and S 15
S 10 Serisi
6-11.5 cm uygulama yüksekliği Series S 10
6-11.5 cm build in height
S 15 Serisi
11 -15 cm uygulama yüksekliği Series S 15
11-15 cm build in height
S 10 Serisi
Küçük, kompakt ve pratik
Büyük kardeşine göre daha küçük gövde yapısı ve kompakt tasarımıyla özellikle düşük uygulama yüksekliği gerektiren detaylar için tasarlanmıştır. Yenileme işleri, hemzemin duş uygulamaları veya ince şap içinde bitirilmesi gereken uygulamalar ile karşılaştığınızda seçmeniz gereken S 10 serisidir. Koku problemine kesin çözüm getiren Dallmer klape, S 10 serisindeki tüm süzgeç başlıklarına uygulanabilir.
S 15 Serisi Büyük ve güçlü
Küçük kardeşinden, daha büyük olan gövde yapısı ve bunun getirdiği ek özellikleri ile ayrılmaktadır. Ağır şartlara dayanıklı ve yüksek akış debilerini karşılayacak bir süzgeç arıyorsanız size önerimiz S 15 serisidir.
20 x 20 cm ebatlarında ızgara seçeneği, ısıtma sistemli çatı süzgeçleri gibi özel alternatifleri S 15 serimizde bulabilirsiniz.
Series S 10 floor drains Small, compact and practical Series S 10 floor drains are almost as versatile as their big brothers, but have a smaller body and are therefore
particularly suitable for level access showers where building height is restricted. Series S 10 floor drains offer particular advantages in renovation work.
Series S 15 floor drains Reliable, robust and versatile
Larger drain bodies, higher flow rate capacities and ability to confront heavy duty jobs are the right words than can be used to distinguish series S 15 from its little brother. Special options like 20 x 20 cm grating or self-heating roof drains are offered in series S 15.
Dizayn ızgaralar Design grates
ASTRASTONE
ASTRA
COLORED
DIMENSION DIMENSION
QUADRASTONE
Sirius Rosso Verona
Sirius Nero Assoluto
Sirius Verde Forest
Sirius Padang Hellgrau
Sirius Azul Bahia
Sirius Custom
Cut Loire
QuadraStone Nero Assoluto
QuadraStone Verde Forest
Nil
Pavo Puls
Graphite
Sol Rosso Verona
Sol Nero Assoluto
Sol Verde Forest
Sol Padang Hellgrau
Sol Azul Bahia
Sol Custom
Galaxy Seine
QuadraStone Azul Bahia
QuadraStone Padang Hellgrau
Yukon
Quadra Round Aquarius
Gold
Gemini Rosso Verona
Gemini Nero Assoluto
Gemini Verde Forest
Gemini Padang Hellgrau
Gemini Azul Bahia
Gemini Custom
Saturn Orinoco QuadraStone Rosso Verona
QuadraStone Custom
Quadra
Güvenli yalıtım çözümleri
Reliable waterproofing solutions
Süzgeçlerin kullanım yerleri eğimli yüzeylerin en sığ noktalarıdır. Bu noktalarda aşırı yağışlarda göllenmeler de görülebilmektedir. Kullanılan süzgecin su yalıtımı ile geçirimsiz ve kalıcı olarak birleştirilememesi durumunda bu bölgelerde su sızıntısı yaşanabileceği unutulmamalıdır.
Dallmer süzgeç sistemleri günümüzde kullanılan her tip su ve ısı yalıtımı uygulamasına uyumlu süzgeç birleşimi çözümlerini içermektedir.
Detaylarınızı oluştururken, kullanmayı düşündüğünüz su ve ısı yalıtımı tipine göre süzgeç ve yalıtım bağlantı aksesuarları seçmenizi öneririz.
Roofers and waterproofing specialists always pay special care to drainage points since a poor adhesion between waterproofing layer and drain might result in leakages. Dallmer drains are incorporated with profound waterproofing and insulation connection solutions. We recommend designers choose the drain body and accessory which are compatible with the selected waterproofing and insulation system
Bitümlü membran uygulaması Torch applied bituminous membrane
Likit / sürme esaslı membran uygulaması Liquid/brushable waterproofing materials
PVC, EPDM, TPO, FPO ve diğer polimer membran uygulaması Polymer membranes
DALLMER süzgeç sistemi ile bitirme Finishing with DALLMER
Su yalıtımını süzgeç ile birleştirin
Apply waterproofing material Süzgeç başlığının uzatma borusunu gerekli
seviyeden kesip başlığı yerleştirin ve zemin kaplamanızı yanaştırarak bitirin.
Cut the extension to the height to suit the thick- Kaplama altına sızan suları tahliye edebilmek için
alt drenaj elemanını yerleştirin.
Fit the white spacer-ring to allow seepage to escape to the drain
1. Dallmer “DallBit” kendinden bitüm yakalı veya YapıBit kendinden yapışan manşet ve flanş’dan oluşan yakayı yüzeye yapıştırın.
2. Bitümlü membran rulosunun uç kısmını süzgecin yakası üzerine getirin ve şalumo ile eriterek yapıştırın.
1. YapıStick kendinden yapışkan manşeti, süzgeç yakası ve zemin üzerine yapıştırın.
2. Paslanmaz çelik flanşı yerleştirip, sabitleyin
3. Likit membranı manşet ve flanşı kaplayacak şekilde uygulayın.
1. Kullanılan yalıtım membran tipine uygun olan Dallmer yalıtım manşetini süzgeç yakası üzerine oturtun. Paslanmaz çelik flanşı yerleştirip sabitleyin
2. Polimer membran rulosunun uç kısmını manşet üzerine ısısalveya kimyasal yöntemler ile yapıştırın.
1. Factory fitted modified bitumen collar fully bonded to the substrate. Alternatively, YapıBit self-adhesive bituminous collar and stainless steel clamp ring can be fitted on site 2. Surrounding waterproofing membrane is welded onto the collar.
1. YapıStick self adhesive collar is bonded on drain body and substrate.
2.Stainless steel clamp ring is fixed and secured
3. Liquid/brushable waterproofing material is applied on the collar.
1. Collar made of polymer membrane is laid over the flange. Membrane is permanently secured with the stainless steel clamp ring 2. Surrounding membrane is bonded to collar.
Üçüncü Çözümümüz: Dallmer SimpliPrimus koku Hnleme sistemidir. Koku fermatüründe su bulunduğunda su perdesi kokuyu engeller.
Koku fermatüründe su kalmadığında ise yüzer çan boru ağzını kapatarak kokunun geçişini engeller.
Süzgeçlerden gelen kötü koku nedeniyle, kimi ıslak hacimlerde süzgeçlerin bantlandığına siz de şahit olmuşsunuzdur. Bu tip uygulamalar hem çirkin bir görüntü oluşturmakta hem de yer süzgecinin fonksiyonunu yerine getirmesine engel olmaktadır.
Kokusuz süzgeçler!
No foul odour from drains!
Yer süzgeçlerinden koku neden gelir?
EN 1253 (Bina drenaj sistemleri) normu doğrultusunda tüm ıslak hacim süzgeçleri, su perdesi en az 5 cm olan sulu sistem koku fermatürlerine haiz olmalıdır. Bunun için süzgeçlerin içinde ‘S’ şeklinde koku fermatürleri bulunur. Süzgecin içine akan su, fermatürden geçerken perde boyunca yükselir ve taşarak pissu tesisatına ulaşır.
Fermatür içinde kalan su ise bahsettiğimiz koku perdesini oluşturur. Ancak sifonlama ve buharlaşma gibi etkenlerden dolayı fermatür içindeki su eksilebilir ve koku perdesi ortadan kalkar. Günümüzde ıslak hacimlerin yıkanması yerine, genelde, sadece silinmesi söz konusu olduğundan, eksilen suyun kendiliğinden tamamlanması da olası değildir.
Birinci çözümümüz: DIN ve EN normlarının gerektirdiğinin bile üzerinde koku fermatürü yüksekliğidir. Bu sayede koku fermatüründeki su perdesinin buharlaşarak yokolması, standart süzgeçlere göre çok daha uzun zaman almaktadır.
İkinci çözümümüz: Dallmer’e özgü klape sistemidir.Dallmer klape, koku fermatüründeki suyun buharlaşarak eksilmesini önler.
Su perdesi bu şekilde sürekli muhafaza edildiğinden kötü kokunun iç mekana geçişi engellenir. Yağmur suyu tesisatı pissu sistemine bağlandığında ise, balkon ve teras süzgeçlerinden koku gelir. Bu gibi durumlarda susuz çalışan bir önlem almak gereklidir.
Klape, drenaj esnasında açılarak suyun tahliyesine izin verir, su akışı olmadığında kapalı durumda olduğundan, kötü kokunun ve haşeratın balkon ve teraslara yayılmasına izin vermez. Susuz çalışan bir sistem olduğundan soğukta donmaz, dış mekan kullanımına uygundur.
Dallmer’in koku problemine getirdiği çözümler Dallmer drains offer two types of solutions to foul odour problem:
Why is foul odour transmitted through traps Typical “S” traps are incorporated in the floor drain bodies in order to block foul odour from sewage system. A trap can block foul odour as long as it is filled with water. On the contrary, loss of water in the trap means diminishing of the barrier between sewage system and wet area. The loss of water might be due to negative pressure irregularities in the pipe system or evaporation. The latter is the most common reason in many cases, since households of modern community do not tend to wash their wetrooms any more but just wipe. Because of this change in cleaning habits traps are deprieved of the only source of water and they dry out.
1. Increased water trap height: Dallmer drains which conform and exceed the european norm requirements, are incorporated with extended water trap height. This means longer periods before water level drops.
2. Dallmer self closing flap valve: This accessory can be incorporated into the gratings and provides extended foul odour protection. The self closing valve opens whenever water is drained and turns to closed position once drainage is completed. There are no mechanical parts like springs which might wear or break down. A simple but functional solution by DALLMER.
3. Dallmer SimpliPrimus odour prevention system: As long as water exists in the trap, passage of odour is prevented by the water curtain In case the trap dries out, bell trap closes and prevents bad odours
Foul odour which is transmitted through the traps of floor drains has always been an issue.
In worst cases, grates are covered, in this case taped by users, in order to prevent foul odours.
S 10 Serisi balkon, teras ve yer süzgeçleri Balcony, terrace and floor drains, Series S 10
S 10 Serisi yer süzgeçleri 6.9-11.5 cm uygulama yüksekliği
Series S 10 floor drains 6.9-11.5 cm build-in height
S 10 Serisi balkon ve teras süzgeçleri 6-8.5 cm uygulama yüksekliği Series S 10 balcony and terrace drains
6-8.5 cm build-in height
S 10 Serisi
Küçük, kompakt ve pratik
Büyük kardeşine göre daha küçük gövde yapısı ve kompakt tasarımıyla özellikle düşük uygulama yüksekliği gerektiren detaylar için tasarlanmıştır. Yenileme işleri, hemzemin duş uygulamaları veya ince şap içinde bitirilmesi gereken uygulamalar ile karşılaştığınızda seçmeniz gereken S 10 serisidir. Koku problemine kesin çözüm getiren Dallmer klape S 10 serisindeki tüm süzgeç başlıklarına uygulanabilir.
Series S 10
Small, compact and practical Series S 10 floor drains are almost as versatile as their big brothers, but have a smaller body and are therefore
particularly suitable for level access showers where building height is restricted. Series S 10 floor drains offer particular advantages in renovation work.
Tip Detay Örnekleri*
Design examples*
Balkon ve teras, yan ç›k›fl balcony and terrace, side outlet
Islak hacim, yan ç›k›fl wet duty room, side outlet
*Projenize özel detay çözümleri için satış bölümümüze başvurunuz.
We can design unique system solutions for your projects, please enquire Süzgeç başlığı KE 10
type KE 10 grating
Finiş kaplama floor finish
Seramik kaplama ceramic floor tiles Seramik yapıştırıcı tile adhesive Su yalıtımı under tile waterproofing Cam elyaf file glassfibre mat screedŞap Şap ayırıcı folyo slip membrane Isı - ses yalıtımı thermal sound insulation Betonarme döşeme concrete slab Şap screed Su yalıtımı waterproofing Isı yalıtımı thermal insulation Buhar kesici vapour barrier Betonarme döşeme concrete slab Alt drenaj elemanı S 10
perforated collar / gravel guard
Paslanmaz çelik ızgara grate, stainless steel Flanş S 10
clamp ring S 10 Süzgeç gövdesi 83 Ø 50 type 83 balcony drain body, DN 50
Kerdiplan K 10 süzgeç seti complete floor drain KerdiPlan K 10
Kokusuz süzgeçler!
No foul odour from drains!
Islak hacim, alt çıkış
wet duty room, vertical outlet
Islak hacim, yan ç›k›fl wet duty room, side outlet
*Projenize özel detay çözümleri için satış bölümümüze başvurunuz.
We can design unique system solutions for your projects, please enquire Süzgeç başlığı
grating
Süzgeç başlığı grating Flanş S 10 clamp ring S 10
Flanş S 10 clamp ring S 10 Süzgeç gövdesi 40 Ø 50 type 40 floor drain body, DN 50
Süzgeç gövdesi 42 Ø 50 type 42 floor drain body, DN 50
Finiş kaplama floor finish
Finiş kaplama floor finish Ayırıcı folyo slip membrane Isı - ses yalıtımı thermal sound insulation
Ayırıcı folyo slip membrane Isı - ses yalıtımı thermal sound insulation screedŞap
screedŞap Su yalıtımı waterproofing
Su yalıtımı waterproofing Betonarme döşeme concrete slab
Betonarme döşeme concrete slab
S 10 Serisi yer süzgeci setleri complete floor drain assemblies, Series S 10
Süzgeç Seti KerdiPlan K 10 KerdiPlan K 10 floor drain
Yer Süzgeci SimpliPlan VK 12 Floor drain SimpliPlan VK 12
DALLMER Yer Süzgeci Seti KerdiPlan
DIN EN 1253‘e uygun (onaylı)
DALLMER Yer Süzgeci SimpliPlan VK
DALLMER type KerdiPlan floor drain
Conforming to DIN EN 1253 (approval)
DALLMER floor drain SimpliPlan VK
Çıkış tipi: Ø 40 / Ø 50, 0°-15° ayarlana bilen, mafsallı, yan çıkış içeriği: Geçici koruma kapağı, non- woven kumaş kaplı Kerdi-membran
yaka,
Yüksekliği ayarlanabilir başlık Malzeme: Polipropilen
Izgara: 304 paslanmaz çelik, K 3 sınıfı
Çıkış tipi: Ø 50, alt çıkış
içeriği: Non-woven kumaş kaplı, sürme esaslı su yalıtım ürünleri ile uyumlu yalıtım yakası,
Çıkarılabilir/temizlenebilir koku
fermatürü,
Geçici koruma kapağı Yükseklik ayarlı süzgeç başlığı Malzeme: Polipropilen
Izgara: 304 paslanmaz çelik, K 3 sınıfı
Yer Süzgeci Seti KerdiPlan K 10:
Çerçeve: ABS, 95 x 95 mm
Yer Süzgeci Seti KerdiPlan K 12:
Çerçeve: ABS, 120 x 120 mm
DALLMER Yer SHzgeci SimpliPlan VK10
Çerçeve: ABS, 95 x 95 mmDALLMER Yer Süzgeci SimpliPlan VK 12
Çerçeve: ABS, 120 x 120 mm
outlet: DN 40/DN 50 horizontal, ball-joint, adjustable 0-15°
with: flange with fleece surface Kerdi
membrane,
temporary blanking
plate, height adjustable grating material: polypropylene
grate: 304 stainless steel, class K 3
outlet:
with:
material:
grate:
DN 50 vertical,
flange with fleece surface Kerdi-membrane removable trap insert temporary blanking plate height adjustable grating polypropylene
304 stainless steel, class K 3
type KerdiPlan K 10 floor drain
frame: ABS, 95 x 95 mm
type KerdiPlan K 12 floor drain
frame: ABS, 120 x 120 mm
DALLMER floor drain SimpliPlan VK10
frame: ABS, 95x95 mmDALLMER floor drain SimpliPlan VK 12
frame: ABS, 120 x 120 mm Kod
Kod 513113 513090
513489 513472
Ø 40 / Ø 50 Ø 40 / Ø 50
Ø 50Ø 50 95x95
120 x120
95x95 120 x120 Süzgeç Seti KerdiPlan K 10
Süzgeç Seti KerdiPlan K 12
Yer Süzgeci SimpliPlan VK 10 Yer Süzgeci SimpliPlan VK 12 Ürün
Ürün
Çap (mm)
Çap (mm) Çerçeve ebadı (mm)
Çerçeve ebadı (mm) DIN EN 1253’e göre test edilmifl debi
(kapak üzerinde 20 mm yüksekli€inde su ile) Flow rate tested to DIN EN 1253 (with 20 mm water over cover plate) Ø 40
Ø 50
DN 50 DN 50 0.6 l/s
0.6 l/s
0.6 l/s 0.6 l/s
DIN EN 1253’e göre test edilmifl debi
(kapak üzerinde 20 mm yüksekli€inde su ile) Flow rate tested to DIN EN 1253 (with 20 mm water over cover plate)
Standart De€er DALLMER Required DALLMER
0.8 l/s 0.8 l/s
Ø 50 1.34 l/s DN 50 1.34 l/s
S 10 Serisi yer süzgeci setleri complete floor drain assemblies, Series S 10
Süzgeç Seti SimpliPrimus C 12 SimpliPrimus C 12 floor drain
Yer Süzgeci Seti PRONTO Ø 100 floor drain PRONTO DN 100
DALLMER Yer Süzgeci Seti SimpliPrimus
Susuz çalışan koku önlemli
DALLMER YerSüzgeci Seti PRONTO
Ø 100 ve Ø 125 boru içine direkt yerleştirilir.
DALLMER type Simpli Primusfloor drain body
With waterless odour trap
DALLMER floor drain PRONTO
pushes into a DN 100 or DN 125 pipe in a floor without a waterproofing membrane
Çıkış tipi: Ø 40, 0°-15° ayarlanabilen, mafsallı
yan çıkış
içeriği: Süzgeçte su kalmadığında dahi kokuyu engelleyen koku fermatürü, non-woven kumaş kaplı Kerdimem bran yaka, yüksekliği
ayarlanabilir başlık Malzeme: Polipropilen
Izgara: 304 paslanmaz çelik, K 3 sınıfı
Çıkış tipi: Ø 100/Ø 125, alt çıkış
içeriği: Çıkarılabilir ve temizlenebilir koku fermatürü, esnek çok yapraklı conta Malzeme: Polipropilen gövde/TPE (Termo Plastik Elastomer) çok yapraklı
conta
Çerçeve: 304 paslanmaz çelik (Pronto K: polipropilen),
120 x 120 mm
Izgara: 304 paslanmaz çelik , 115 x 115 mm, K 3 sınıfı
Yer Süzgeci Seti SimpliPrimus K 12:
Çerçeve: Polipropilen, 122,5 x 122,5
mm Yer Süzgeci Seti SimpliPrimus K 12:
Çerçeve: 304 paslanmaz çelik,120 x 120 mm
outlet: DN 0 40, horizontal, ball-joint, adjustable 0°-15°
with: Primus odour trap, flange with fleece surface Kerdi-membrane, temprorary blanking plate, height adjustable grating
material: polypropylene
grate: 304 stainless steel, class K 3
with: trap insert removable for cleaning flexible sealing ribs
material: polypropylene/rubber/TPE frame: 304 stainless steel (Pronto K: polypropylene)
120 x 120 mm
grate: 304 stainless steel, 115x115 mm,
class K 3
type Simpli Primus K 12 floor drain:
frame: polypropylene, 122,5 x 122,5 mm
type Simpli Primus C 12 floor drain:
frame: 304stainless steel, 120 x 120 mm
Kod
Kod 513458 513465
700063 700087 700360 700384
Ø 40 / Ø 50 Ø 40 / Ø 50
Ø 100 Ø 125 Ø 100 Ø 125 Yer Süzgeci Seti SimpliPrimus K 12
Yer Süzgeci Seti SimpliPrimus C 12
Yer Süzgeci Seti PRONTO Yer Süzgeci Seti PRONTO Yer Süzgeci Seti PRONTO K Yer Süzgeci Seti PRONTO K Ürün
Ürün
Çap (mm)
Çap (mm) Çerçeve ebadı (mm)
DIN EN 1253’e göre test edilmifl debi
(kapak üzerinde 20 mm yüksekli€inde su ile) Flow rate tested to DIN EN 1253 (with 20 mm water over cover plate)
Ø 40 0.4 l/s DN 40 0.4 l/s
Simpli Primus koku fermatürü çalışma prensibi:
Simpli Primus odour trap function:
Süzgeçte su mevcut olduğu durumda koku fermatüründeki su perdesi kokuyu engeller As long as water exists in the trap, passage of odour is prevented by the water curtain
Süzgeçte su olmadığı durumda çan şeklindeki koku fermatürü kapanarak kokuyu engeller
In case the trap dries out, bell trap closes and prevents bad odours
S 10 Serisi yer süzgeci gövdeleri floor drain bodies , Series S 10
Yer Süzgeci Gövdesi 42 type 42 floor drain body
Rezervasyon ebadı/recess size: 180 x 350 mm Rezervasyon ebadı/recess size: 180 x 350 mm Rezervasyon ebadı/recess size: 150 x 180 mm
Karot delik çapı/core drill: Ø 130 mm Yer Süzgeci Gövdesi 40 S
type 40 floor drain body
Yer Süzgeci Gövdesi 46 type 46 floor drain body
DALLMER Yer Süzgeci Gövdesi 40
DIN EN 1253‘e uygun
Dallmer Yer Süzgeci Gövdesi 42
Dallmer Yer Süzgeci Gövdesi 46
DIN EN 1253‘e uygun
DALLMER type 40 floor drain body
conforming to DIN EN 1253
DALLMER type 42 floor drain body
DALLMER type 46 floor drain body
conforming to DIN EN 1253 Çıkış tipi: Ø 50, alt çıkış
içeriği: Çıkarılabilir, çan şeklinde koku
fermatürü
Geçici koruma kapağı / membran
kesim şablonu
Malzeme: Polipropilen
Çıkış tipi: Ø 50, 0°-15° ayarlanabilen, mafsallı
yan çıkış
içeriği: Ø 40 yan giriş (tapalıdır, istendiğinde lavabo, duş vb. çıkışı bağlanabilir.) Çıkarılabilir koku fermatürü, Geçici koruma kapağı / membran
kesim şablonu
Malzeme: Polipropilen
Çıkış tipi: Ø 50,0°-15° ayarlanabilen, mafsallı,
yan çıkış
içeriği: Ø 40 yan giriş (tapalıdır, istendiğinde lavabo, duş vb. çıkışı bağlanabilir.) Çıkarılabilir koku fermatürü, geçici koruma kapağı / membran kesim
şablonu
Malzeme: Polipropilen
Yer Süzgeci Gövdesi 40 PE:
Polietilen borulara uyumlu
Yer Süzgeci Gövdesi 42/3:
3 adet Ø 40 yan girişli
outlet: DN 50 vertical spigot
with: removable bell trap, temporary blanking plate
material: polypropylene
outlet: DN 50 horizontal with ball-joint, adjustable 0-15°
with: side inlet DN 40, trap insert removable for cleaning, temporary blanking plate
material: polypropylene
outlet: DN 50 with ball-joint, adjustable
0-15°
with: side inlet DN 40, trap insert removable for cleaning, temporary blanking plate
material: polypropylene
type 40 PE:
polyethylene
type 42/3 floor drain body:
with: 3 side inlets DN 40 Kod
Kod
Kod 405128 405135 405227
420022 422026 421722 422729
460059 462053
Ø 50Ø 50 Ø 50
Ø 50Ø 50 Ø 50Ø 50
Ø 50Ø 50 Yer Süzgeci Gövdesi 40 S
Yer Süzgeci Gövdesi 40 PE:
Yer Süzgeci Gövdesi 40, DallBit*
Yer Süzgeci Gövdesi 42 S Yer Süzgeci Gövdesi 42, DallBit * Yer Süzgeci Gövdesi 42/3 Yer Süzgeci Gövdesi 42/3, DallBit *
Yer Süzgeci Gövdesi 46 S Yer Süzgeci Gövdesi 46, DallBit * Ürün
Ürün
Ürün
Çap (mm)
Çap (mm)
Çap (mm) DIN EN 1253’e göre test edilmifl debi
(kapak üzerinde 20 mm yüksekli€inde su ile) Flow rate tested to DIN EN 1253 (with 20 mm water over cover plate)
Standart De€er DALLMER Required DALLMER
0.8 l/s 0.8 l/s
Ø 50 1.34 l/s DN 50 1.34 l/s
DIN EN 1253’e göre test edilmifl debi
(kapak üzerinde 20 mm yüksekli€inde su ile) Flow rate tested to DIN EN 1253 (with 20 mm water over cover plate)
Ø 50 0.62 l/s DN 50 0.62 l/s
DIN EN 1253’e göre test edilmifl debi
(kapak üzerinde 20 mm yüksekli€inde su ile) Flow rate tested to DIN EN 1253 (with 20 mm water over cover plate)
Standart De€er DALLMER Required DALLMER
0.8 l/s 0.8 l/s
Ø 50 0.81 l/s DN 50 0.81 l/s
Çıkış boruları ABS malzemeden ve British Standard ölçülerinde veya PE-HD malzemeden DİN EN 1519a uygun olarak üretilebilmektedir, lütfen satış bölümümüze danışınız.
*DallBit: 0 420 mm çapında, 5 mm kalınlığında bitümlü membran yakalı. Bitümlü yaka, plastik gövdeye basınç ve ısıl işlem ile kaynatılmış ayrıca paslanmaz çelik baskı flanşı ile mekanik olarak sabitlenmistir.
The outlet connector can be supplied in ABS to suit British Standard sizes and PE-HD conforming to DIN EN 1519. Please enquire.
*DallBit: 0 420 mm collar of 5.0 mm thick bituminous membrane, welded to the flange and secured with stainless steel clamp ring
S 10 Serisi balkon ve teras süzgeci gövdeleri balcony and terrace drain bodies, Series S 10
60
DN5
0
Ø230 42
150
DN7
0
150 Ø230
85 54
DN5
0
Ø152
65
150
DALLMER Balkon ve Teras Süzgeci Gövdesi 83
DIN EN 1253 ‘e uygun
DALLMER type 83 Balcony and terrace drain body
Conforming to DIN EN 1253 Ç›k›fl tipi:
içeri€i:
Malzeme:
outlet:
with:
material:
3° e€imli yan ç›k›fl Geçici koruma kapa€› / Membran kesim flablonu Polipropilen, UV dayan›ml›
DIN EN 1253’e göre test edilmifl akıfl h›z›
floor rate in l/s tested to DIN EN 1253
side, 3°
temporary blanking plate polypropylene-UV stabilized
Kod 830029 830043 832023 832047 837028 837042
Ø 50Ø 70
Ø 50Ø 70
Ø 50Ø 70 Balkon ve Teras Süzgeci Gövdesi 83
Balkon ve Teras Süzgeci Gövdesi 83 Balkon ve Teras Süzgeci Gövdesi 83, DallBit*
Balkon ve Teras Süzgeci Gövdesi 83, DallBit*
Balkon ve Teras Süzgeci Gövdesi, FPO**
Balkon ve Teras Süzgeci Gövdesi, FPO**
Ürün Ebat (mm)
Çap/süzgeç üzerindeki su yüksekli€i
size/level over drain 5mm 15mm 25mm 35mm 45mm 55mm 65mm 75mm
Ø / DN 50 0,60 1,00 1,10 1,20 1,30 1,40 1,40 1,50
Ø / DN 70 0,90 2,20 4,00 5,50 7,20 9,40 12,80 16,00
*DallBit: Ø 420 mm çap›nda, 5 mm kal›nl›€›nda bitümlü membran yakal›. Bitümlü yaka, plastik gövdeye bas›nç ve ›s›l ifllem ile kaynat›lm›fl ayr›ca paslanmaz çelik bask› flanfl› ile mekanik olarak sabitlenmifltir.
**FPO: Polipropilen esasl› FPO membranlar plastik yaka üzerine direkt kaynat›labilir.
*DallBit: Ø 420 mm collar of 5.0 mm thick bituminous membrane, welded to the flange and secured with stainless steel clamp ring
**FPO: FPO-membranes based on polypropylene can be welded directly to the flange.
Balkon ve Teras Süzgeci Gövdesi 83 KF
Yakas›z süzgeç gövdesi, özellikle renovasyon iflleri için uygundur
DALLMER type 83 KF Balcony and terrace drain body
body without flange for use without a waterproofing membrane
Ç›k›fl tipi:
içeri€i:
Malzeme:
outlet:
with:
material:
3° e€imli yan ç›k›fl Geçici koruma kapa€›
Polipropilen, UV dayan›ml›
side, 3°
temporary blanking plate polypropylene, UV-stabilized DIN EN 1253’e göre test edilmifl akıfl h›z›
floor rate in l/s tested to DIN EN 1253 Çap/süzgeç üzerindeki su yüksekli€i
size/level over drain 5mm 15mm 25mm 35mm 45mm 55mm 65mm 75mm
Ø / DN 50 0,60 1,00 1,10 1,20 1,30 1,40 1,40 1,50
Ø / DN 70 0,90 2,20 4,00 5,50 7,20 9,40 12,80 16,00
Kod 830326
830340 Ø 50
Balkon ve Teras Süzgeci Gövdesi 83 KF Ø 70 Balkon ve Teras Süzgeci Gövdesi 83 KF
Ürün Ebat (mm)
Balkon ve Teras Süzgeci Gövdesi 83 Ø 50 balcony and terrace drain body 83 DN 50
Balkon ve Teras Süzgeci Gövdesi 83 Ø 70 balcony and terrace drain body 83 DN 70
Balkon ve Teras Süzgeci Gövdesi 83, DallBit Ø 50 balcony and terrace drain body 83, DallBit DN 50
Balkon ve Teras Süzgeci Gövdesi 83, FPO Ø 50 balcony and terrace drain body 83, FPO DN 50
Balkon ve Teras Süzgeci Gövdesi 83 KF Balcony and terrace drain body 83 KF Rezervasyon ebad›/recess size: 180 x 270 mm
S 10 Serisi balkon ve teras süzgeci gövdeleri balcony and terrace drain bodies, Series S 10
DALLMER Balkon ve Teras Süzgeci Gövdesi 84
DIN EN 1253‘e uygun
DALLMER type 84 Balcony and terrace drain body
Conforming to DIN EN 1253 Ç›k›fl tipi:
‹çeri€i:
Malzeme:
outlet:
with:
material:
Alt ç›k›fl
Geçici koruma kapa€› / membran kesim flablonu
Polipropilen, UV dayan›ml›
DIN EN 1253’e göre test edilmifl akıfl h›z›
floor rate in l/s tested to DIN EN 1253
vertical
temporary blanking plate polypropylene, UV-stabilized
Kod 831026 831040 831064 832122 832146 832160 837127 837141 837165
Ø 50Ø 70 Ø 100 Ø 50Ø 70 Ø 100 Ø 50Ø 70 Ø 100 Balkon ve Teras Süzgeci Gövdesi 84
Balkon ve Teras Süzgeci Gövdesi 84 Balkon ve Teras Süzgeci Gövdesi 84 Balkon ve Teras Süzgeci Gövdesi 84, DallBit*
Balkon ve Teras Süzgeci Gövdesi 84, DallBit*
Balkon ve Teras Süzgeci Gövdesi 84, DallBit*
Balkon ve Teras Süzgeci Gövdesi 84, FPO**
Balkon ve Teras Süzgeci Gövdesi 84, FPO**
Balkon ve Teras Süzgeci Gövdesi 84, FPO**
Ürün Ebat (mm)
Çap/süzgeç üzerindeki su yüksekli€i
size/level over drain 5mm 15mm 25mm 35mm 45mm 55mm 65mm 75mm
Ø / DN 50 0,60 1,00 1,10 1,20 1,30 1,40 1,40 1,50
Ø / DN 70 0,90 2,20 4,00 5,50 7,20 9,40 12,80 16,00
Ø / DN 100 0,90 2,10 4,20 5,70 7,20 9,50 12,60 17,00
*DallBit: Ø 420 mm çap›nda, 5 mm kal›nl›€›nda bitümlü membran yakal›. Bitümlü yaka, plastik gövdeye bas›nç ve ›s›l ifllem ile kaynat›lm›fl ayr›ca paslanmaz çelik bask› flanfl› ile mekanik olarak sabitlenmifltir.
**FPO: polipropilen esasl› FPO membranlar plastik yaka üzerine direkt kaynat›labilir.
*DallBit: Ø 420 mm collar of 5.0 mm thick bituminous membrane, welded to the flange and secured with stainless steel clamp ring
**FPO: FPO-membranes based on polypropylene can be welded directly to the flange.
DALLMER Balkon ve Teras Süzgeci Gövdesi 84 KF
Yakas›z süzgeç gövdesi, özellikle renovasyon iflleri için uygundur
DALLMER type 84 KF Balcony and terrace drain body
body without flange for use without a waterproofing membrane
Ç›k›fl tipi:
‹çeri€i:
Malzeme:
outlet:
with:
material:
Alt ç›k›fl
Geçici koruma kapa€›
Polipropilen, UV dayan›ml›
vertical
temporary blanking plate polypropylene, UV-stabilized
DIN EN 1253’e göre test edilmifl akıfl h›z›
floor rate in l/s tested to DIN EN 1253 Çap/süzgeç üzerindeki su yüksekli€i
size/level over drain 5mm 15mm 25mm 35mm 45mm 55mm 65mm 75mm
Ø / DN 50 0,90 2,40 3,70 4,40 5,40 5,50 5,70 5,80
Ø / DN 70 0,90 2,20 3,80 4,90 6,80 9,00 12,00 14,60
Kod 831323
831347 Ø 50
Balkon ve Teras Süzgeci Gövdesi 84 KF Ø 70 Balkon ve Teras Süzgeci Gövdesi 84 KF
Ürün Ebat (mm)
S 10 Serisi süzgeç bafll›klar›
gratings, Series S 10
DALLMER Süzgeç Bafll›€› E 10, EN 10
S 10 serisi süzgeç gövdelerine uygundur.
DALLMER Süzgeç Bafll›€› EC 10, ECN 10
S 10 serisi süzgeç gövdelerine uygundur.
DALLMER Süzgeç Bafll›€› ECS 10
S 10 serisi süzgeç gövdelerine uygundur.
DALLMER Süzgeç Bafll›€› E 12, EN 12
S 10 serisi süzgeç gövdelerine uygundur.
DALLMER Süzgeç Bafll›€› KE 10, KEN 10
S 10 serisi süzgeç gövdelerine uygundur.
DALLMER type EC 10, ECN 10 grating
Used with series S 10 drain bodies
DALLMER type E 10, EN 10 grating
Used with series S 10 drain bodies
DALLMER type ECS 10 grating
Used with series S 10 drain bodies
DALLMER type E 12, EN 12 grating
Used with series S 10 drain bodies
DALLMER type KE 10, KEN 10 grating
Used with series S 10 drain bodies Gövde:
Çerçeve:
Izgara:
EN 10:
Gövde:
Çerçeve:
Izgara:
ECN 10:
Gövde:
Çerçeve:
Izgara:
Gövde:
Çerçeve:
Izgara:
EN 12:
Gövde:
Çerçeve:
Izgara:
KEN 10:
spigot:
frame:
grate:
ECN 10:
spigot:
frame:
grate:
ECN 10:
spigot:
frame:
grate:
spigot:
frame:
grate:
EN 12:
spigot:
frame:
grate:
KEN 10:
Polipropilen, Ø100 plastik boru ile uzat›labilir.
ABS, 100 x 100 mm
304 paslanmaz çelik, K 3 s›n›f›
Vida ile sabitlenebilir ›zgaral›
Polipropilen, Ø 100 plastik boru ile uzat›labilir.
304 paslanmaz çelik, 100 x 100 mm 304 paslanmaz çelik, K 3 s›n›f›
Vida ile sabitlenebilir ›zgaral›
Polipropilen, Ø 100 plastik boru ile uzat›labilir.
304 paslanmaz çelik, 100 x 100 mm 5 mm, 316 paslanmaz çelik, vida ile sabitlenebilir, L 15 s›n›f›
ABS, Ø 100 plastik boru ile uzat›labilir.
304 paslanmaz çelik, 120 x 120 mm 304 paslanmaz çelik, K 3 s›n›f›
Vida ile sabitlenebilir ›zgaral›
Polipropilen, Ø 100 plastik boru ile uzat›labilir.
ABS, 150 x 150 mm
304 paslanmaz çelik, K 3 s›n›f›
Vida ile sabitlenebilir ›zgaral›
polypropylene, extendable with DN 100 plastic pipe
304 stainless steel, 100 x 100 mm 304 stainless steel, class K 3 grate secured
polypropylene, extendable with DN 100 plastic pipe
ABS, 100 x 100 mm
304 stainless steel, class K 3 grate secured
polypropylene, extendable with DN 100 plastic pipe
304 stainless steel, 100 x 100 mm 5 mm 316 stainless steel, secured, class L 15
ABS, extendable with DN 100 plastic pipe
304 stainless steel, 120 x 120 mm 304 stainless steel, class K 3 grate secured
polypropylene, extendable with DN 100 plastic pipe
ABS, 150 X 150 mm 304 stainless steel, class K 3 grate secured
Kod
Kod
Kod
Kod
Kod 510006 510044
510013 510082
510020
510310 510327
510051 510099
100 x 100 100 x 100
100 x 100 100 x 100
100 x 100
120 x 120 120 x 120
150 x 150 150 x 150 Süzgeç Bafll›€› E 10
Süzgeç Bafll›€› EN 10
Süzgeç Bafll›€› EC 10 Süzgeç Bafll›€› ECN 10
Süzgeç Bafll›€› ECS 10
Süzgeç Bafll›€› E 12 Süzgeç Bafll›€› EN 12
Süzgeç Bafll›€› KE 10 Süzgeç Bafll›€› KEN 10 Ürün
Ürün
Ürün
Ürün
Ürün
Ebat (mm)
Ebat (mm)
Ebat (mm)
Ebat (mm)
Ebat (mm)
S›n›f / class Yük / load (kg)
H 1,5 150
K 3 300
L 15 1500
M 125 12500
Yük dayan›m› tablosu / load bearing capacity
S 10 Serisi süzgeç bafll›klar›
gratings, Series S 10
DALLMER Süzgeç Bafll›€› SEC 10, SEN 10, SES 10
S 10 serisi süzgeç gövdelerine uygundur.
DALLMER Süzgeç Bafll›€› KES 11
S 10 serisi süzgeç gövdelerine uygundur.
DALLMER Süzgeç Bafll›€› KEN 11
S 10 serisi süzgeç gövdelerine uygundur.
DALLMER Süzgeç Bafll›€› ER 12
S 10 serisi süzgeç gövdelerine uygundur.
DALLMER type SEC 10, SEN 10, SES 10 grating
Used with series S 10 drain bodies
DALLMER type KES 11 grating
Used with series S 10 drain bodies
DALLMER type ECS 10 grating
Used with series S 10 drain bodies
DALLMER type ER 12 grating
Used with series S 10 drain bodies Gövde:
Çerçeve:
SEC 10:
SEN 10:
SES 10:
Gövde:
Çerçeve:
Izgara:
Gövde:
Çerçeve:
Izgara:
Gövde:
Çerçeve:
Izgara:
spigot:
frame:
SEC 10:
SEN 10:
SES 10:
spigot:
frame:
grate:
spigot:
frame:
grate:
spigot:
frame:
grate:
Polipropilen, Ø 100 plastik boru ile uzat›labilir.
304 paslanmaz çelik, 150 x 150 mm 304 paslanmaz çelik ›zgara, K 3 s›n›f›
304 paslanmaz çelik ›zgara, vida ile sabitlenebilir, K 3 s›n›f›
5 mm, 316 paslanmaz çelik ›zgara, vida ile sabitlenebilir, L 15 s›n›f›
ABS, Ø 100 plastik boru ile uzat›labilir.
304 paslanmaz çelik, 150 x 150 mm 5 mm, 316 paslanmaz çelik, vida ile sabitlenebilir, L 15 sınıfı
ABS, Ø 100 plastik boru ile uzat›labilir.
304 paslanmaz çelik, 150 x 150 mm 304 paslanmaz çelik, vida ile sabitlenebilir, K 3 s›n›f›
ABS, Ø 100 plastik boru ile uzat›labilir.
304 paslanmaz çelik, Ø 120 mm 304 paslanmaz çelik, K 3 s›n›f›
Tüm S 10 serisi süzgeç bafll›klar› contal› Ø 100 plastik borulara direkt ba€lanarak tek bafl›na da kullan›labilir.
E€er kokuya karfl› önlem al›nmak isteniyorsa, Dallmer koku önleyici klapeler S 10 ve S 12 (kod no 495839 veya 495846) süzgeç bafll›€› içine yerlefltirilebilir
All series S 10 gratings have a connector diameter of 110 mm and can be installed as a grating for an untrapped drain. If odour protection is needed, Dallmer self closing valves S 10 and S 12 (Art Nr 495839 or 495846 respectively) can be installed in the gratings.
polypropylene, extendable with DN 100 plastic pipe
304 stainless steel, 150 x 150 mm grate 304 stainless steel, class K 3 grate 304 stainless steel, secured, class K 3
grate 5 mm 316 stainless steel, secured, class L 15
ABS, extendable with DN 100 plastic pipe
304 stainless steel, 150 x 150 mm 5 mm 316 stainless steel, secured, class L 15
ABS, extendable with DN 100 plastic pipe
304 stainless steel, 150 x 150 mm 304 stainless steel, secured, class K 3
ABS, extendable with DN 100 plastic pipe
304 stainless steel, Ø 120 mm 304 stainless steel, class K 3 Kod
Kod
Kod
Kod 510105 510136 510143
510129
510112
510334
150 x 150 150 x 150 150 x 150
150 x 150
150 x 150
Ø 120 Süzgeç Bafll›€› SEC 10
Süzgeç Bafll›€› SEN 10 Süzgeç Bafll›€› SES 10
Süzgeç Bafll›€› KES 11
Süzgeç Bafll›€› KEN 11
Süzgeç Bafll›€› ER 12 Ürün
Ürün
Ürün
Ürün
Ebat (mm)
Ebat (mm)
Ebat (mm)
Ebat (mm)
29
150
Ø110
130
Ø110
29
150
130
S 10 Serisi süzgeç bafll›klar›
gratings, Series S 10
DALLMER Süzgeç Bafll›€› DER S 10/120
S 10 serisi süzgeç gövdelerine uygundur.
DALLMER Süzgeç Bafll›€› DES 11
S 10 serisi süzgeç gövdelerine uygundur.
DALLMER Süzgeç Bafll›€› PVC-EN 10
S 10 serisi süzgeç gövdelerine uygundur.
PVC, linolium gibi yer kaplamalar› bafll›€›n yakas›na s›cak hava kayna€› ile yap›flt›r›labilir.
DALLMER Süzgeç Bafll›€› PVC-KEN 10
S 10 serisi süzgeç gövdelerine uygundur.
PVC, linolium gibi yer kaplamalar› bafll›€›n yakas›na s›cak hava kayna€› ile yap›flt›r›labilir.
DALLMER Süzgeç Bafll›€› ERP 12
S 10 serisi süzgeç gövdelerine uygundur.
PVC, linolium gibi yer kaplamalar›n›n sabitlene- bilmesi için flanfl sistemi mevcuttur.
DALLMER type DER S 10/120 grating
Used with series S 10 drain bodies
DALLMER type DES 11 grating
Used with series S 10 drain bodies
DALLMER type ECS 10 grating
Used with series S 10 drain bodies with flange for securing flexible flooring
DALLMER type E 12, EN 12 grating
Used with series S 10 drain bodies with flange for securing flexible flooring
DALLMER type ERP 12 grating
used with series S 10 drain bodies with clamp ring for flexible flooring, 1-4 mm e.g. PVC, rubber, etc.
Gövde:
Çerçeve:
Izgara:
Kapak:
Gövde:
Çerçeve:
Izgara:
Kapak:
Gövde:
Çerçeve:
Izgara:
Gövde:
Çerçeve:
Izgara:
Gövde:
Çerçeve:
Izgara:
spigot:
frame:
grate:
cover:
spigot:
frame:
grate:
cover:
spigot:
frame:
grate:
spigot:
frame:
grate:
spigot:
frame:
grate:
ABS, Ø 100 plastik boru ile uzat›labilir.
304 paslanmaz çelik, 120 x 120 mm 304 paslanmaz çelik, Ø 115 mm 304 paslanmaz çelik, K 3 sınıfı
ABS, Ø 100 plastik boru ile uzat›labilir.
304 paslanmaz çelik, 150 x 150 mm 304 paslanmaz çelik, vida ile sabitlenebilir, 90 x 90 mm 304 paslanmaz çelik, K 3 s›n›f›
PVC-U, Ø 100 plastik boru ile uzat›labilir
PVC-U, 100 x 100 mm 304 paslanmaz çelik, vida ile sabitlenebilir ›zgaral›, K 3 s›n›f›
PVC-U, Ø 100 plastik boru ile uzat›labilir.
PVC-U, 150 x 150 mm 304 paslanmaz çelik, vida ile sabitlenebilir ›zgaral›, K 3 s›n›f›
ABS, Ø 100 plastik boru ile uzat›labilir.
ABS, Ø 138,5 mm
304 paslanmaz çelik, vida ile sabitlenebilir, K 3 s›n›f›
ABS, extendable with DN 100 plastic pipe
304 stainless steel, 120 x 120 mm 304 stainless steel, Ø 115 mm 304 stainless steel, class K 3
ABS, extendable with DN 100 plastic pipe
304 stainless steel, 150 x 150 mm 304 stainless steel, 90 x 90 mm, secured
304 stainless steel, class K 3
PVC-U, extendable with DN 100 plastic pipe
PVC-U, 100 x 100 mm 304 stainless steel, secured, class K 3
PVC-U, extendable with DN 100 plastic pipe
PVC-U, 150 x 150 mm 304 stainless steel, secured, class K 3
ABS, extendable with DN 100 plastic pipe
ABS, Ø 138,5 mm
304 stainless steel, Ø 115 mm class K 3
*secured available Kod
Kod
Kod
Kod
Kod 510198
510181
510150
510037
510389 510471
120 x 120
150 x 150
100 x 100
150 x 150
Ø 138,5 Ø 138,5 Süzgeç Bafll›€› DER S10/120
Süzgeç Bafll›€› DES 11
Süzgeç Bafll›€› PVC-EN 10
Süzgeç Bafll›€› PVC-KEN 10
Süzgeç Bafll›€› ERP 12 Süzgeç Bafll›€› ERP 12, vidal›*
Ürün
Ürün
Ürün
Ürün
Ürün
Ebat (mm)
Ebat (mm)
Ebat (mm)
Ebat (mm)
Ebat (mm)
Ø110 120
11 14 14-109
PVC yakal›!
PVC yer döflemeleri s›cak kaynak ile
yap›flt›r›labilir PVC yakal›!
PVC yer döflemeleri s›cak kaynak ile
yap›flt›r›labilir
Dallmer kapakl› süzgeç bafll›klar› hastane, endüstriyel mutfak ve hijyen gerektiren tüm uygulamalar için uygundur. Kapak kapal› iken haflerat, kötü koku, bakteri ve mikroplar›n mekana yay›lmas›n› engeller. Kapak aç›ld›€›nda kolay flekilde suyu tahliye eder.
These gratings have a cover design which enables their use in hygenic applications in industrial kitchens, hospitals and other places which require hygene.
S 10 Serisi ızgaralar grates, Series S 10
DALLMER Izgara Quadra 90
Çerçeve ECS 10 (Kod 495211) ile kullan›l›r.
5 mm, 316 paslanmaz çelik, satine yüzey
DALLMER Izgara Quadra 115
Çerçeve ECS 12 (Kod 495341) ile kullan›l›r.
5 mm, 316 paslanmaz çelik, satine yüzey
DALLMER Izgara Quadra 140
Çerçeve SES 10 (Kod 495259) ile kullan›l›r.
5 mm, 316 paslanmaz çelik, satine yüzey
Izgara Yukon 115 grate Yukon 115
Izgara Nil 115 grate Nil 115
Izgara Seine 115 grate Seine 115
Izgara Orinoco 115 grate Orinoco 115
Izgara Loire 115 grate Nil 115
DALLMER Flow 115 serisi ızgaralar
Çerçeve ECS 12 (Kod 495341) ile kullan›l›r.
“ Loire”, “Seine”, “Orinoco”, “Nil”
veya “Yukon” tasarım seçenekleri 5 mm, 316 paslanmaz çelik, satine yüzey
DALLMER type Quadra 90 grate
Used with frame ECS 10
5 mm, 316 stainless steel, satin finish
DALLMER type Quadra 115 grate
Used with frame ECS 12
5 mm, 316 stainless steel, satin finish
DALLMER type Quadra 140 grate
Used with frame SES 10
5 mm, 316 stainless steel, satin finish
DALLMER type flow 115 grates
Used with frame ECS 12
grates with Design “ Loire”, “Seine”, “Orinoco”,
“Nil” or “Yukon”, satin finish 5 mm, 316 stainless steel Kod
501653 501639 501646 501615 501622
115 x 115 115 x 115 115 x 115 115 x 115 115 x 115 Izgara Yukon 115
Izgara Orinoco 115 Izgara Nil 115 Izgara Loire 115 Izgara Seine 115
Ürün Ebat (mm)
Kod
Kod
Kod 501592
501585
501226
90 x 90
115 x 115
140 x 140 Izgara Quadra 90
Izgara Quadra 115
Izgara Quadra 140 Ürün
Ürün
Ürün
Ebat (mm)
Ebat (mm)
Ebat (mm)
Tüm ızgara ve çerçeveler iste€e özel kaplanabilir
Color grates on request
Gold Graphite
115
S 10 Serisi ızgaralar grates, Series S 10
DALLMER Izgara QuadraStone 140
Çerçeve SES 10 (Kod 495259) ile kullan›l›r.
Çerçeve ortas›na yerlefltirilmifl 50 x 50 mm ebad›nda farkl› renklerde do€al tafl içerir 5 mm, 316 paslanmaz çelik, satine yüzey QuadraStone 140 Nero Assoluto Zimbabwe
QuadraStone 140 Azul Bahia
QuadraStone 140 Rosso Verona
QuadraStone 140 Verde Forest
QuadraStone 140 Padang Hellgrau
Rezervasyon ebad›/recess size: 5 x 50 x 50 mm
DALLMER Izgara QuadraStone Custom 140
Çerçeve SES 10 (Kod 495259) ile kullan›l›r.
Kendi tafl›n›z› yerlefltirebilmeniz için 5 x 50 x 50 mm ebad›nda rezervasyonlu 5 mm, 316 paslanmaz çelik, satine yüzey
Tafl yerlefltirme
Kendi tafl›n›z› Izgara QuadraStone Custom (501509)’a yerlefltirme hizmetimizdir.
Ebatlanacak tafl 100 x 100 mm ölçüde, 5-10 mm aras› kal›nl›kta olmal›d›r
DALLMER Izgara Cut 140
Çerçeve SES 10 (Kod 495259) ile kullan›l›r.
5 mm, 316 paslanmaz çelik, satine yüzey
DALLMER type QuadraStone 140 grate
Used with frame SES 10
5 mm, 316 stainless steel, satin finish incorporating centrally recessed 50 x 50 mm stone, 140 x 140 mm
DALLMER type QuadraStone Custom 140 grate
used with frame SES 10, with central recess for 5 x 50 x 50 mm stone insert
5 mm, 316 stainless steel, satin finish
Stone fitting
We can insert a customer’s own stone into the QuadraStone Custom grate 501509.
Supplied stone must be 100 x 100 mm.
Minimum 5 mm/maximum 10 mm thick.
DALLMER type Cut 140 grate
used with frame SES 10
5 mm, 316 stainless steel, satin finish Kod
Kod
Kod Kod
501509
501660
502315 501523 501530 501547 501554 501561
140 x 140
50 x 50
140 x 140 140 x 140 140 x 140 140 x 140 140 x 140 140 x 140
Izgara QuadraStone Custom 140
Tafl yerlefltirme
Izgara Cut 140
Izgara QuadraStone 140 Nero Assoluto Zimbabwe Izgara QuadraStone 140 Azul Bahia
Izgara QuadraStone 140 Rosso Verona Izgara QuadraStone 140 Verde Forest Izgara QuadraStone 140 Padang Hellgrau
Ürün
Ürün
Ürün Ürün
Ebat (mm)
Ebat (mm)
Ebat (mm) Ebat (mm)
Izgaralar grates
DALLMER Izgara Quadra 115 round
Çerçeve ER 12 (Kod 495334) ile kullan›l›r.
5 mm, 316 paslanmaz çelik, satine yüzey, Ø 115 mm
DALLMER Izgara Astra Aquarius 115
Çerçeve ER 12 (Kod 495334) ile kullan›l›r.
5 mm, 316 paslanmaz çelik, satine yüzey Ø 115 mm
DALLMER Izgara K 140
Çerçeve SES 10 ve KEN 10 (Kod 495259) ile kullanılır. Poliamid, K 3 s›n›f›
DALLMER Izgara RHS 140
Çerçeve SES 10 ve KEN 10 (Kod 495259) ile kullan›l›r. DIN 51130 / DIN 51097‘e uygun yüzme ve dufl alanlar› için
B s›n›f› kaydırmaz yüzeyli,
5 mm, 316 paslanmaz çelik, vida ile sabitlenebilir,
R 12 / L 15 s›n›f›
Izgara RHS 140 / 1,5:
5mm, 306 paslanmaz çelik, vidal›, R 11 / K3 s›n›f›, B sınıfı kaydırmaz
DALLMER type Quadra 115 round grate
Used with frame ER 12 5 mm, 316 stainless steel, satin finish, Ø 115 mm
DALLMER type Astra Aquarius 115 grate
Used with frame ER 12 5 mm, 316 stainless steel, satin finish, Ø 115 mm
DALLMER type K 140 grate
Used with frame SES 10 and KEN 10 polyamide, class K 3
DALLMER type RHS 140 grate
used with frame SES 10 and KEN 10 conforming to DIN 51130 / DIN 51097 in swimming and shower areas non-slip class B,
5 mm 316 stainless steel, secured, class R 12 / L 15
RHS 140 / 1.5
306 stainless steel, class R 11 / K 3, non-slip class B
Kod Kod
Kod
Kod
501141 501783 502223
501806
501172
140 x 140 140 x 140 Ø 115
Ø 115
140 x 140
Izgara RHS 140 Izgara RHS 140/1,5 Izgara Quadra 115 round
Izgara Astra Aquarius
Izgara K 140
Ürün Ürün
Ürün
Ürün
Ebat (mm) Ebat (mm)
Ebat (mm)
Ebat (mm) 140
140
S 10 Serisi süzgeç bafll›klar›
gratings, Series S 10
DALLMER Çerçeve ECS 10
S 10 serisi süzgeç gövdelerine ve ›zgaralara uygundur. 90 x 90 mm ›zgaralar ile kullan›l›r.
DALLMER Çerçeve ECS 12
S 10 serisi süzgeç gövdelerine ve ›zgaralara uy- gundur. 115 x 115 mm ›zgaralar ile kullan›l›r.
DALLMER Çerçeve SES 10
S 10 serisi süzgeç gövdelerine ve ›zgaralara uygundur. 140 x 140 mm mm ›zgaralar ile kullan›l›r.
DALLMER Çerçeve KEN 10
S 10 serisi süzgeç gövdelerine ve ›zgaralara uygundur. 140 x 140 mm ›zgaralar ile kullan›l›r.
DALLMER Çerçeve ER 12
S 10 serisi süzgeç gövdelerine ve ›zgaralara uygundur. Ø 115 mm ›zgaralar ile kullan›l›r.
DALLMER type ECS 10 frame
Used with series S 10 drain bodies and grates suitable for grates 90 x 90 mm
DALLMER type ECS 12 frame
Used with series S 10 drain bodies and grates suitable for grates 115 x 115 mm
DALLMER type SES 10 frame
Used with series S 10 drain bodies and grates suitable for grates 140 x 140 mm
DALLMER type KEN 10 frame
Used with series S 10 drain bodies and grates suitable for grates 140 x 140 mm
DALLMER type ER 12 frame
Used with series S 10 drain bodies and grates suitable for grates Ø 115 mm
Gövde:
Çerçeve:
Gövde:
Çerçeve:
Gövde:
Çerçeve:
Gövde:
Çerçeve:
Gövde:
Çerçeve:
spigot:
frame:
grate:
cover:
spigot:
frame:
spigot:
frame:
spigot:
frame:
spigot:
frame:
Polipropilen, Ø 100 plastik boru ile uzat›labilir
304 veya 316 (V4A) paslanmaz çelik, vida yuval›
Polipropilen, Ø100 plastik boru ile uzat›labilir
304 veya 316 (V4A) paslanmaz çelik, vida yuval›
Polipropilen, Ø 100 plastik boru ile uzat›labilir
304 paslanmaz çelik, vida yuval›
Polipropilen, Ø 100 plastik boru ile uzat›labilir
ABS, vida yuval›
ABS, Ø 100 plastik boru ile uzat›labilir
304 veya 316 (V4A) paslanmaz çelik, Ø 120 mm
ABS, extendable with DN 100 plastic pipe
304 stainless steel, 120 x 120 mm 304 stainless steel, Ø 115 mm 304 stainless steel, class K 3
polypropylene, extendable with DN 100 plastic pipe
304 or 316 (V4A) stainless steel, with threaded inserts
polypropylene, extendable with DN 100 plastic pipe
304 stainless steel, with threaded inserts
polypropylene, extendable with DN 100 plastic pipe
ABS, with threaded inserts
ABS, extendable with DN 100 plastic pipe
304 or 316 (V4A) stainless steel, Ø 120 mm
Kod
Kod
Kod
Kod
Kod 495211 495228
495341 495389
495259
495242
495334 495396
100 x 100 100 x 100
120 x 120 120 x 120
150 x 150
150 x 150
Ø 120 Ø 120 Çerçeve ECS 10
Çerçeve ECS 10 (V4A)
Çerçeve ECS 12 Çerçeve ECS 12 (V4A)
Çerceve SES 10
Çerçeve KEN 10
Çerçeve ER 12 Çerçeve ER 12 (V4A) Ürün
Ürün
Ürün
Ürün
Ürün
Ebat (mm)
Ebat (mm)
Ebat (mm)
Ebat (mm)
Ebat (mm)
Ø110 14 14-111
9
150
Ø110 150
14 14 16-114
Ø110
14
Ø120
9-105
6,2
RENO yenileme sistemi RENO renovation system
DALLMER RENO Yenileme Çerçevesi
100 X 100 mm, 120 X 120 mm veya 150 X 150 mm ebatlar› mevcuttur.
Yeni kaplama ile renove edilen zeminde eski süzgeç üzerinde kullan›l›r Malzeme: 304 paslanmaz çelik
DALLMER RENO Round
Yenileme Çerçevesi
Ø 155 mm veya Ø 120 mm ebatlar› mevcuttur.
Yeni kaplama ile renove edilen zeminde eski süzgeç üzerinde kullan›l›r Malzeme: 304 paslanmaz çelik
DALLMER RENO-frame
100 x 100, 120 x 120 or 150 x 150 mm, for installation in a new tiled floor over an existing drain
304 stainless steel
DALLMER RENO-frame Round
Ø 155 and Ø 120 mm,
for installation in a new tiled floor over an existing drain
304 stainless steel Kod
Kod
495549 500496 495518 495532 500502
Ø 120 Ø 155 120155
100 x 100 120 x 120 150 x 150
Yenileme Çerçevesi, Round Reno Yenileme Çerçevesi, Round Reno*
Reno Yenileme Çerçevesi Reno Yenileme Çerçevesi Reno Yenileme Çerçevesi
100120 150
Ürün Ürün
Ebat (mm) Ebat (mm)
*Uygun ızgaralar için S15 serisi ızgaralara bakınız suitable grates from series S15 Eski Yer Süzgeci old drain
Eski Seramik Kaplama old ceramic tiles Yeni Seramik Kaplama new ceramic tiles Reno Yenileme Çerçevesi reno frame Reno Yenileme Izgaras› grating
Eski üzerine yeni - H›zl› ve efektif yenileme iflleriniz için RENO renovasyon sistemi
Eski zemininizi yeni kaplama ile renove ederken, eski süzgeç üzerine RENO yenileme çerçevesini yerlefltiriniz.
Sistemi dizayn serimizden bir ›zgara ile tamamlayarak fl›k bir görünüm elde edebilirsiniz.
New on old - use RENO for quick, effective renovation When renovating by tiling over existing tiles, one of the RENO range of gratings can be fitted over the existing floor drain. All the frames shown here can be upgraded with grates from our Design range to further enhance a new bathroom.
S 10 Serisi aksesuarlar accessories, Series S 10
DALLMER Klape
S10 serisi süzgeç bafll›klar› ve çerçeveler ile kullan›l›r. Yer ve çat› süzgeçleri ile kullan›lan ek koku önlemidir. Susuz çal›fl›r, donmaz.
Klape, drenaj esnas›nda aç›larak suyun tahli- yesine izin verir, su akıflı olmadı€ında kapal›
durumda kal›r.
Klape S 10
ile kullan›lan
Çerçeveler: ECS 10 ve KEN 10
Süzgeç bafll›klar›: Tüm 100 x 100 mm süzgeç bafll›klar› ve süzgeç bafll›€› KE 10, KEN 10, PVC EN 10, PVC KEN 10
Klape S 12
ile kullan›lan
Çerçeveler: ECS 12 ve SES 10
Süzgeç bafll›klar›: Tüm 120 x 120 mm ve
150 x 150 mm süzgeç bafll›klar› (S 10 modeli klape ile kullan›lanlar hariç)
DALLMER self-closing flap-valve
used with series S10 gratings and frames Used on combined foul and rainwater systems, the flap-valve allows water to drain whilst pre- venting the escape of foul air and scum.
S 10
to be used withframes: ECS 10 and KEN 10
gratings: all 100 x 100 mm gratings and KE 10, KEN 10, PVC EN 10, PVC KEN 10
S 12
to be used with
frames: ECS 12 and SES 10
gratings: all 120 x 120 mm and 150 x 150 mm gratings except the ones used with flap valve S 10
‹çeri€i:
Malzeme:
Susuz çal›fl›r, donmaz
With no water seal, it cannot freeze with:
material:
conta ABS
sealABS
Kod
Kod 495839 495846
790400 790550
Ø 92Ø 108,5
400 x 400 400 x 400 Klape S 10
Klape S 12
Su Yalıtım Manfleti S 10, YapıStick Su Yalıtım Manfleti S 10, YapıBit Ürün
Ürün
Ebat (mm)
Ebat (mm) Ø92 42
Ø108,5
59
Yer süzgeçlerin koku fermatüründeki su seviyesi buharlaflma, sifonlama gibi nedenlerle azald›€›nda koku perdesi ortadan kalkar ve kötü koku bina içine yay›l›r. Dallmer klape, koku fermatüründeki suyun buharlaflarak eksilmesini önler. Su perdesi bu flekilde sürekli muhafaza edildi€inden kötü kokunun iç meka- na geçifli engellenir. Ya€mur suyu tesisat› pissu sistemine ba€land›€›nda ise, balkon ve teras süzgeçlerinden koku gelir. Bu gibi durumlarda susuz çal›flan bir önlem almak gereklidir. Klape, drenaj esnas›nda aç›larak suyun tahliyesine izin verir, su akıflı olmadı€ında kapal› durumda oldu€undan, kötü kokunun ve hafleratın balkon ve teraslara yay›lmas›na izin vermez. Susuz çalıflan bir sistem oldu€undan so€ukta donmaz, dıfl me- kan kullanımına uygundur.
Water level in the traps can be diminished due to negative air pressure in sewage pipes or evaporation. A trap without water inside can no longer protect interior from foul odour. Dallmer self closing flap valve can be installed in gratings and frames in order to improve odour protection of floor drains. It can be used with balcony and terrace drains when the rainwater system is combined with sewage system. Due to its unique functioning principle it does not freeze. It is suitable for exterior use.
klape S 10
type S 10 self-closing flap-valve
klape S 12
type S 12 self-closing flap-valve
Su yalıtım manfleti S 10, YapıStick waterproofing collar S 10, Yap›Stick
Su yalıtım manfleti S 10, YapıBit waterproofing collar S 10, Yap›Bit
Yap›Servis Su Yalıtım Manfleti S 10
S 10 serisi süzgeç gövdeleri ve Flanfl S 10 ile birlikte kullan›l›r
Su izolasyonu tabakası ile süzgeç yakası arasındaki sızdırmazlı€ı sa€lar
Su Yalıtım Manfleti S 10, YapıStick:
likit/sürme esaslı su yalıtımı malzemeleri ile kullanılır
Kendinden yapıflkan alt yüzey, likit/sürme esaslı su yalıtım malzemelerini tutucu özellikte non-woven kumafl kaplı üst yüzey
Su Yalıtım Manfleti S 10, YapıBit:
fialuma uygulamalı bitümlü membran ve solvent içeren bitümlü sürme esaslı yalıtım malzemeleri ile kullanılır
kendinden yapıflkan alt yüzey, SBS esaslı, polyester keçe taflıyıcılı bitümlü membrandan mamüldür
Yap›Servis waterproofing collar S 10
used with series S 10 drain bodies and clamp ring S 10
Waterproofing collar S 10, Yap›Stick
suitable for liquid applied waterproofing materials
self adhesive, incorporating fleece upper surface
Waterproofing collar S 10, Yap›Bit
suitable for torch applied waterproofing membranes
self adhesive, SBS modified, polyester fabric reinforced bitumen incorporating sand upper surface
S 10 Serisi aksesuarlar accessories, Series S 10
Dallmer Alt Drenaj Eleman› S 10
S 10 serisi süzgeç gövdeleri ve Flanfl S 10 ile birlikte kullan›l›r.
Zemin kaplamas› alt›na s›zan suyun su yal›t›m› katman› üzerinden tahliyesini sa€lar.
Dallmer Yal›t›m Flanfl› S 10
S 10 serisi süzgeç gövdeleri ve Manflet S 10 ile birlikte kullan›l›r.
Su yal›t›m membranlar›n›n ve manflet S 10’un süzgeç gövdesine mekanik sabitlen- mesinde kullan›l›r.
‹çeri€i: Paslanmaz sabitleme vidalar›, kauçuk conta
DALLMER Yal›t›m Flanfl› S 10 FPO
Süzgeç Gövdesi 83 FPO ve Süzgeç Gövdesi 84 FPO ile kullan›l›r. Polipropilen esasl› FPO membranlar ile uyumludur.
‹çeri€i: Paslanmaz sabitleme vidalar›
DALLMER Yal›t›m Flanfl› S 10, PVC
Süzgeç Gövdesi 83 FPO ve Süzgeç Gövdesi 84 FPO ile kullan›l›r. PVC esasl› membranlar ile uyumludur.
‹çeri€i: Paslanmaz sabitleme vidalar›
Dallmer type S 10 perforated collar/
gravel guard
used with series S 10 drain bodies and clamp ring S 10
fitted between the drain body and grating, it allows water passing through a paved terrace to drain from the waterproofing level
Dallmer type S 10 clamp ring
used with series S 10 drain bodies and water- proofing collars
stainless steel
with: stainless steel screws, rubber seal
DALLMER type FPO S 10 spacer
used with balcony drain body 83 FPO and 84 FPO with: screws
DALLMER type PVC S 10 flange
used with balcony drain body 83 FPO and 84 FPO with: screws
Kod
Kod Kod
Kod
495198
495853 495822
839503
Ø 208
Ø 308 Ø 103
Yal›t›m Flanfl› S 10, FPO Yal›t›m Flanfl› S 10
Yalıtım Flanflı S 10, PVC Alt Drenaj Eleman› S 10
Ürün
Ürün Ürün
Ürün
Ebat (mm)
Ebat (mm) Ebat (mm)
23Ø103
Teras ve balkon zeminlerindeki kaplama derzlerinden, zamanla, alt katmanlara su s›zar. Su yal›t›m tabakas›na kadar inen ve burada biriken su, yaz›n buharlaflma, k›fl›n da donma nedeniyle seramik der- zlerinin kalkmas›na, hatta seramiklerde deformasyona sebep olur. Bu durumun yaflanmamas› için çat›
süzgeçlerinin su yal›t›m› kotundan da su tahliyesi özelli€i bulunmal›d›r. Alt drenaj eleman› yerlefltirilen Dallmer süzgeçler daha yüksek alt drenaj özelli€ine kavuflur. Süzgeç gövdesi ve bafll›€› aras›na yerleflen bu parça, seramik derzlerinden su yal›t›m› seviyesine inen suyun tahliyesini sa€lar.
Rainwater can penetrate through the joints of floor tiles in balcony and terraces. Accumulated water under the tiles has wearing effects on tile flooring and water proofing system and it has to be drained away.
Dallmer perforated collar provides a secondary drainage when it is used between the drain body and the grating.
