Late-onset Congenital Adrenal Hyperplasia
with Cushing Syndrome
Gurbuz Erdogan
1, Recai Pabuccu
2, Sibel Ertek
3, Shoshana Israel
4, Banu Yilmaz
2,
Hilal Yilmaz
5and Gamze Caglar
2Abstract
Although hirsutism is classically part of the clinical presentation of polycystic ovarian syndrome (PCOS), congenital adrenal hyperplasia and Cushing’s syndrome (CS), CS associated with underlying late-onset con-genital adrenal hyperplasia (LCAH) in an adult has not been previously reported. We herein present the case of a 25-year-old woman who was followed for PCOS for seven years. After undergoing detailed tests de-scribed within the text, she received the diagnosis of LCAH and was found to have point mutations. Interest-ingly, she later had diagnosis of endogenous CS that regressed folowing excision of an adrenal adenoma found on MRI. The present patient thus exhibited the coexistence of two paradoxical endocrine pathologies.
Key words: congenital adrenal hyperplasia, adrenal adenoma, hirsutism, Cushing syndrome, polycystic ovary
syndrome
(Intern Med 53: 1955-1959, 2014) (DOI: 10.2169/internalmedicine.53.0654)
Introduction
Idiopathic hirsutism, polycystic ovary syndrome (PCOS) and late-onset congenital adrenal hyperplasia (LCAH) are common causes of adult hyperandrogenemia and/or hirsu-tism. The underlying pathology in hirsutism may also be Cushing’s syndrome (CS) or an androgen-secreting tumor. Since most hyperandrogenemic patients display irregular menstruation and polycystic ovaries, an inaccurate evalu-ation of the patient can result in misdiagnosis. Unless the possibility of LCAH is explored, patients admitted with these signs and symptoms are easily mistreated for PCOS. We herein present a case of LCAH treated as PCOS for seven years in which after receiving the correct diagnosis of LCAH, the patient was treated with dexamethasone and de-veloped CS symptoms with adrenal adenoma. This case is the first in the literature to involve both CS and LCAH.
Case Report
A 25-year-old patient who had received treatment for sec-ondary amenorrhea in another city for seven years was ad-mitted to Gynecology Department of Ufuk University in Au-gust, 2008. Her age of menarche was 14 years. Shortly thereafter, she was admitted to a gynecologist with com-plaints of oligomenorrhea, hair loss and hirsutism. Based on an initial diagnosis of PCOS, she was prescribed oral con-traceptives that she did not use regularly. Unfortunately, one year later, serum 17-OH P level of 22 ng/mL in the early follicular phase were underestimated and spironolactone therapy (100 mg/day) was added to the oral contraceptive treatment (Visit 1, Table). The patient subsequently experi-enced 10 kg weight gain over seven years, and her hirsutism worsened. Physical examination revealed Ferriman Gallwey score of 16, clitoromegaly (2×2 cm) and polycystic ovaries on an ultrasound evaluation. There were no other signs of virilization or a CS-like appearance. Treatment with oral
１Department of Endocrinology and Metabolic Diseases, Ufuk University Medical Faculty, Turkey,２Department of Obstetrics and Gynecology,
Ufuk University Medical Faculty, Turkey,３Endocrinology and Metabolic Diseases Department, Antalya Medicalpark Hospital and
Transplanta-tion Complex, Turkey,４Tissue Typing and Genetics Department, Hadassah Medical Organization, Israel and５Department of Internal Medicine,
Ufuk University Medical Faculty, Turkey
Received for publication March 25, 2013; Accepted for publication February 17, 2014 Correspondence to Dr. Sibel Ertek, sibelertek@yahoo.it
Table. Hormonal Test Results of the Patient on Successive Visits
Normal range
Visit 1 Visit 2 Visit 3 Visit 4*
FSH (mIU/mL) 3.5-12.5 1.17 - - 5.78 LH (mIU/mL) 2.4-12.6 0.10 - - 13.1 Estradiol (pg/mL) 12.5-166 5.0 - - 40.9 Progesterone (ng/mL) 0.2-1.5 0.60 - - 2.37 17-OH P (ng/mL) 0.15-1.1 22 17.92 23.00 7.3 DHEA-SO4 (μg/mL) 98-340 - 90.64 - 31.89 Prolactine 8.66 - -ACTH (pg/mL) 10-120 17.5 78.01 <1 91.3 Cortisol (μg/dL) 5-25 16 21.84 25.96 17.8 Testosterone total (ng/mL) 0.06-0.82 0.19 - 0.26 -Testosterone free (ng/mL) 0.29-3.18 2.52 - 2.49 -TSH (mIU/mL) 0.2-4.0 0.82 - 0.64
-*Visit 4 is test results on day 16 of menstruation, whereas others are on follicular phase.
contraceptive pills combined with cyproterone acetate (100 mg/day, 10 days/cycle) and metformin (850 mg, twice a day) did not result in any change in symptoms within three months. She subsequently consulted Endocrinology Depart-ment. Her hormonal parameters during the follicular phase were as shown in Table, Visit 2. An adrenocorticotropic hor-mone (ACTH) stimulation test was performed with the fol-lowing results: starting 17-OH P: 15.08 ng/mL, 30 minutes: 17-OH P:70.00 ng/mL, 60 minutes 17-OH P: 50.80 ng/mL. Since the morning cortisol level was 21.84 μg/dL at Visit 2, a 1 mg overnight dexamethasone suppression test was per-formed one week after the ACTH test, which demonstrated the suppression of the cortisol level to 0.9 μg/dL. Taking all of the test results together, the patient received a diagnosis of LCAH and treatment with 0.5 mg/day of dexamethasone was started.
During the first eight months of dexamethasone therapy, the patient exhibited continuously high 17-OH P level with three spontaneous menstruations, however she also devel-oped a moon face appearance, buffalo hump, weight gain, plethora, spontaneous ecchymoses and edema. In addition she received the diagnosis of glaucoma and osteoporosis with a bone mineral density T score of -3.6 in the antero-posterior axial spine. Since she displayed CS symptoms months after the initiation of steroid treatment, she was thought to have an excess accumulation of exogenous ster-oids. Because she had no intention to become pregnant, the steroid treatment was stopped, and combined oral contracep-tives with ciproterone acetate was initiated.
After 4 months the patient exhibited loss of plethora,
de-creased edema, the absence of easy bruising and buffalo hump; however the moon-face and hirsutism persisted.
Another five months later the test results obtained on the control visit were as shown on Table, Visit 3. She subse-quently underwent an additional 1 mg dexamethasone sup-pression test, and the morning plasma cortisol level was not found to be suppressed at 28.7 μg/dL. We then conducted 2 days 2 mg dexamethasone suppression test which showed the cortisol level to be 32.5 μg/dL without suppression, with a midnight cortisol level of 28.7 μg/dL. The patient under-went bilateral adrenal magnetic resonance imaging (MRI) which revealed a left adrenal adenoma presenting as a solid mass with a regular margin measuring 31×16 mm in size (Figure). In May 2011, left adrenalectomy was performed the histopathology of which demonstrated adrenocortical adenoma and myelolipoma. Histologically, there were sepa-rated nests of adenomatous cells with abundant lipid vacu-oles and a granular eosinophilic cytoplasm, without areas of mitosis or necrosis, seperated by fibrous septae, with a myelolipoid component containing adipocytes and myeloid tissue with erythrocytes, lymphocytes and megakaryocytes.
A diagnosis of LCAH was confirmed based on a genetic analysis of progesterone 21-hydroxylase (CYP21) which re-vealed a point mutation in exon 7 (V281L) and stop codon in exon 8 (Q318X). Peri-operative prednisolone replacement therapy was gradually halted over two months. At the end of the two months, the patient demonstrated significant im-provement in symptoms and loss of CS features and hirsu-tism, the recovery of spontaneous menstruation, and a plasma cortisol of 5.8 μg/dL. On a physical examination re-gression of hirsutism (Ferriman Gallwey score:8) and a de-crease in the size of the clitoris were noted. However, an ul-trasonographic evaluation revealed polycystic ovaries. The patient was found to be menstruating regularly; however her cycles were anovulatory (day 19 progesterone: 3.66 ng/mL, day 21 progesterone: 2.47 ng/mL, day 24 progesterone: 1.61 ng/mL).
The most recent laboratory findings obtained in January 2012 are as shown in Table, Visit 4 (16th day of the men-strual cycle). Due to the high possibility of a glucocorticoid reserve deficiency, the patient remains under close follow-up.
Discussion
LCAH is an autosomal recessive disease characterized by oligomenorrhea, hirsutism, acne and hair loss (1-3). In adults, PCOS and idiopathic hirsutism are considered in the differential diagnosis. In patients with LCAH, androgen ex-cess may result in PCOS-like phenotype with all manifesta-tions of PCOS, including an elevated luteinizing hormone (LH) level and a polycystic ovarian appereance potentially being observed (4-7). The frequency of PCOS has been re-ported to be 1-19% in patients with LCAH (8, 9). In LCAH patients, unlike those with PCOS, signs of virilism such as clitoromegaly may develop. Symptoms of
hyperaldostero-Figure. Magnetic resonance imaging in the coronal and axial contrast-enhanced view showing the adrenal adenoma (indicated by the arrows).
nism and hypercortisolism related to 21- hydroxylase defi-ciency can also be observed (10).
ACTH stimulation test constitutes the gold standart test for obtaining an accurate diagnosis of LCAH (7, 11). After measuring the serum 17-OH P and 11 deoxycortisol levels, a single dose (0.25 mg) of ACTH injection is performed. In patients with 21- hydroxylase deficiency, the serum 17-OH P level increases by 30 nmol/L. In contrast, in those with 11 beta hydroxylase deficiency, the 11 deoxycortisol level in-creases by three fold of the 95th percentile observed in con-trols after 30-60 minutes (12). Therefore, in patients with hyperandrogenism, in order to provide optimal management and avoid misdiagnosis, alternative diagnostic tests to ACTH stimulation tests were under investigation. In a study by Avivi and collegues, the results of ACTH stimulation tests were compared before and after six months of cyproterone asetate and etinil estradiol treatment (13). The authors de-tected significantly lower levels of 17-OH P and progester-one in the LCAH patients. Furthermore, the authors sug-gested that correlating the results of ACTH stimulation tests with the human leukocyte antigen (HLA) typing increases both the sensitivity and specifity (13).
In a Turkish population with PCOS, the rate of 11 beta hydroxylase deficiency was reported to be 8.4% (12). An-other study found 21- hydroxylase deficiency to be present in 33% of patients with symptoms of PCOS and hirsu-tism (14). The largest study (n=205) from Turkey reported a frequency of LCAH of 9.75% among patients with hirsu-tism (15). In the literature, the rate of LCAH in those with hirsutism ranges from 6% to 12% with a genetic expression of 21- hydroxylase deficiency of between 0.015 and 0.057 (5). Based on these studies, the frequency of LCAH emphasizes the need to obtain differential diagnosis in pa-tients with suspected PCOS presenting with oligomenorrhea, hair loss, acne and hirsutism. PCOS is the most common endocrinopathy in women of reproductive age (6-8%), and other pathologies with androgen excess and anovulation can mimic the features of PCOS (16, 17). Another endocrine disorder that interferes with PCOS symptoms is CS.
Al-though weight gain, hirsutism, acne, and irregular menstrua-tion are common findings in both disorders, the detecmenstrua-tion of accompanying truncal obesity, buffalo hump, striae and os-teoporosis favora a diagnosis of CS (16, 18-20). Occasion-ally, LCAH and CS can be confused due to their similarity in signs and symptoms. In the literature, there are several cases of iatrogenic CS in patients treated with corticoster-oids for LCAH (21, 22). In addition, a case of LCAH asso-ciated with physical findings of CS has been reported (23).
A decade ago, researchers suggested that adrenal tumors are capable of changing their enzymatic activity (24). Previ-ously, 21- hydroxylase and 11 beta hydroxylase deficiencies were explored in a study consisting of 48 cases of adrenal incidentaloma and 10 cases of subclinical CS (24). In that study, the results of ACTH stimulation tests showed an ex-aggerated response in adrenal incidentaloma cases, in which the increase in the 17-OH P and 11 deoxycortisol levels was significantly higher in the subclinical CS patients (24). Among the participants of that study, the 17-OH P levels declined to normal levels in seven of eight patients treated with surgery. In addition, the adrenal incidentaloma patients exhibited enzymatic diversity with alterations in enzymatic pathways being a phenomenon mostly associated with glu-cocorticoid autonomy (24). The results of that study showed that the possible effects of changes in steroideogenetic path-ways on adrenocortical tumor formation can be documented using molecular analysis. In the present case, a point muta-tion in CYP21 resulted in a higher level of 17-OH P whose conversion to 11-deoxycortisol was decreased due to 21-hydroxylase deficiency, causing LCAH. Pathophysiologi-cally, this phenomenon constituted the basis of treatment strategy for LCAH, cortisol treatment decreases the ACTH level and therefore decreases excess androgen synthesis and hirsutism in affected patients. However, our patient pre-sented with a high cortisol level and dynamic test results without supression suggesting excess adrenal cortisol pro-duction, with CS symptoms. Therefore, both genetic tests and hormonal studies, together with a postoperative patho-logical evaluation, revealed the presence of simultaneous
LCAH and an adrenal adenoma causing CS in this unique case.
Although patients with CAH have a higher incidence of adrenal incidentalomas compared to the normal population, accompanying endogenous hypercortisolism is rare. In the medical literature, two cases of Cushing’s disease with 21-hydroxylase deficiency have been reported (25). However, with the exception of a single case report (26) of the autopsy of an 8-week-old infant in 1964, the case reported here is the first in the literature to involve both CS and late-onset congenital adrenal hyperplasia.
In the present case, the patient’s signs and symptoms of CS regressed following the cessation of steroid treatment for LCAH, then later re-appeared. ACTH secretion was likely suppressed during the steroid treatment and perhaps also due to excess endogenous cortisol. The recurrent overproduction of ACTH following steroid cessation may have also played a role in this case, however, since an endogenous source was still present, we believe that this phenomenon presented a transient period of high ACTH. The rapid suppression of the ACTH level following 0.5 mg/day dose of dexametha-sone may also reflect the additional effects of endogenous cortisol. Following the cessation of dexamethasone, the pa-tient’s autonomous adrenal cortisol secretion continued with-out the need for ACTH stimulation. In addition, an abnor-mal dexamethasone suppression test result was observed prior to surgery of the adrenal mass, and the diagnosis of endogenous steroid excess was confirmed when the patient’s cortisol level declined and her symptoms regressed follow-ing excision of the adrenal adenoma found on MRI. Further-more, the diagnosis of LCAH was confirmed using a genetic analysis highlighting the uniqueness of this case with re-spect to the coexistence of two paradoxical endocrine pa-thologies.
Moreover, myelolipomas generally exhibit a variable growth rate (27), and myelolipomatous foci can be present in association with other pathological conditions of the adre-nal glands, such as hyperplasia or adenoma (28). Adenomas are hormonally active and usually have smaller size, with differing growth rates, whereas myelolipomas are generally silent and asymptomatic and although rarely exceeding 5 cm in diameter, they can reach up to 34 cm in size (29). Since the present patient had neoplasm with two different compo-nents, the growth rate of the lesion could not be estimated.
This case emphasizes the importance of making the dif-ferential diagnosis of hirsutism and applying dynamic diag-nostic tests with inter-diciplinary follow-up in patients with hormonal diseases.
The authors state that they have no Conflict of Interest (COI).
References
1. Reboul P, Merceron RE, Cordray JP, Guillerd X, Nys P, Rainaunt
M. Adrenal enzymatic block with late-onset caused by 11-hydroxylase deficiency. Apropos of 29 cases. Ann Endocrinol 53:
187-195, 1992.
2. Pang S. Congenital adrenal hyperplasia. Endocrinol Metab Clin
North Am 26: 853-891, 1997.
3. New MI. 21-hydroxylase deficiency congenital adrenal
hyperpla-sia. J Steroid Biochem Mol Biol 48: 15-22, 1994.
4. Hague WM, Adams J, Roda C, et al. The prevalence of polycystic
ovaries in patients with congenital adrenal hyperplasia and their close relatives. Clin Endocrinol 33: 501-510, 1990.
5. Chrousos GP, Loriaux DL, Mann DL, Cutler GB Jr. Late-onset
21-hydroxylase deficiency mimicking idiopatic hirsutism or poly-cysticovarian disease. Ann Intern Med 96: 143-148, 1982.
6. Azziz R, Dewailly D, Owerbach D. 1994 Clinical review 56:
Non-classic adrenal hyperplasia: current concepts. J Clin Endocrinol Metab 78: 810-815, 1994.
7. Brodie BL, Wentz AC. Late onset congenital adrenal hyperplasia:
a gynecologist’s perspective. Fertil Steril 48: 175-188, 1987.
8. Cobin RH, Futterweit W, Fiedler RP, Thornton JC.
Adrenocotico-tropic hormone testing in idiopathic hirsutism and polycystic ovar-ian disease: a test of limited usefulness. Fertil Steril 44: 224-226, 1985.
9. Benjamin F, Deutsch S, Saperstein H, Seltzer VL. Prevalence of
and markers for the attenuated form of congenital adrenal hyper-plasia and hyperprolactinemia masquerading as polycystic ovarian disease. Fertil Steril 46: 215-221, 1986.
10. Robyr D, Llor J, Gaudin G, Schneider N. Polycystic ovary
syn-drome and congenital adrenal hyperplasia: a different entity for comparable phenotypes? Rev Med Suisse 3: 1595-1596, 1598, 1600-1601, 2007.
11. Aziz R, Rafi A, Smith BR, Bradley EL Jr, Zacur HA. On the
ori-gin of the elevated 17-hydroxy-progesterone levels after adrenal stimulation in hyperandrogenism. J Clin Endocrinol Metab 70: 431-436, 1990.
12. Sahin Y, Kele!timur F. The frequency of late-onset 21-hydroxylase
and 11 beta-hydroxylase deficiency in women with polycystic ovary syndrome. Eur J Endocrinol 137: 670-674, 1997.
13. Avivi I, Pollack S, Gideoni O, Linn S, Blumenfeld Z.
Overdiagno-sis of 21-hydroxylase late onset congenital adrenal hyperplasia: correlation of corticotropin test and human leukocyte antigen typ-ing. Fertil Steril 66: 557-563, 1996.
14. Yarman S, Dursun A, Oguz F, Alagol F. 2004 The prevalence,
molecular analysis and HLA typing of late-onset 21-hydroxylase deficiency in Turkish woman with hirsutism and polycystic ovary. Endocr J 51: 31-36, 2004.
15. Unluhizarci K, Kula M, Dundar M. The prevalence of non-classic
adrenal hyperplasia among Turkish women with hyperandro-genism. Gynecol Endocrinol 26: 139-143, 2010.
16. Pall ME, Lao MC, Patel SS, et al. Testosterone and bioavailable
testosterone help to distinguish between mild Cushing’s syndrome and polycystic ovarian syndrome. Horm Metab Res 40: 813-818, 2008.
17. Trivax B, Azziz R. Diagnosis of polycystic ovary syndrome. Clin
Obstet Gynecol 50: 168-177, 2007.
18. Friedman TC, Zuckerbraun E, Lee ML, Kabil MS, Shahinian H.
Dynamic pituitary MRI has high sensitivity and specificity for the diagnosis of mild Cushing’s syndrome and should be part of the initial workup. Horm Metab Res 39: 451-456, 2007.
19. Velez DA, Mayberg MR, Ludlam WH. Cyclic Cushing syndrome:
definitions and treatment implications. Neurosurg Focus 23: E4; discussion E4a, 2007.
20. Ragnarsson O, Johannsson G. Management of endocrine disease:
Cushing’s syndrome: a structured short- and long-term manage-ment plan for patients in remission. Eur J Endocrinol 169: R139-R152, 2013.
21. Gupta P, Goyal S, Gonzalez-Mendoza LE, et al.
Corticotropin-independent cushing syndrome in a child with an ovarian tumor misdiagnosed as nonclassic congenital adrenal hyperplasia. Endocr
Pract 14: 875-879, 2008.
22. Campos SP, MacGillivray MH. Preclinical Cushing syndrome due
to an adrenocortical adenoma mimicking late-onset congenital ad-renal hyperplasia. Clin Pediatr 33: 246-248, 1994.
23. Loh V, Krishnan B, Prentice M, Panahloo A, Seal L. Late onset
congenital adrenal hyperplasia masquerading as subclinical Cush-ing’s syndrome. Endocrine Abstracts 19: 72, 2009.
24. Dall’Asta C, Barbetta L, Libé R, Passini E, Ambrosi B.
Coexis-tence of 21-hydroxylase and 11 beta-hydroxylase deficiency in ad-renal incidentalomas and in subclinical Cushing’s syndrome. Horm Res 57: 192-196, 2002.
25. Boronat M, Carrillo A, Ojeda A, et al. Clinical manifestations and
hormonal profile of two women with Cushing’s disease and mild
deficiency of 21-hydroxylase. J Endocrinol Invest 27: 583-590, 2004.
26. O’Bryan RM, Smith RW Jr, Fıne G, Mllinger RC. Congenital
adrenocortical hyperplasia wıth Cushing’s syndrome. JAMA 187: 257-261, 1964.
27. Han A, Brunett AL, Fishman EK, Marshall FF. The natural
treat-ment and history of adrenal myelolipoma. J Urol 157: 1213-1216, 1997.
28. Kenney PJ, Wagner BJ, Rao P, Heffess CS. Myelolipoma: CT and
pathologic features. Radiology 208: 87-95, 1998.
29. Boudreaux D, Waisman J, kinner DG, et al. Giant adrenal
myelol-ipoma and testicular interstitial tumor in a man with congenital 21-hydroxilase deficency. Am J Surg Pathol 3: 109-123, 1979.
