Corresponding author: Bülent Erol
Department of Orthopaedics and Traumatology The Hospital of University of Marmara
Tophanelioglu Caddesi, No: 13/15 Altunizade/Istanbul
E-mail: bulerol@hotmail.com Tel:+90 216 325 45 82 Fax: 216 325 45 82
Marmara Medical Journal 2004;17(3);140-145
REVIEW
EVALUATION OF PEDIATRIC MUSCULOSKELETAL TUMORS
Bülent Erol, Murat Bezer, Osman Güven
Department of Orthopaedics and Traumatology,School of Medicine, Marmara University,Istanbul, Turkey
ABSTRACT
A wide range of musculoskeletal tumors occurs in the pediatric population. Physicians should be aware of the clinical and radiographic manifestations of these tumors in order to provide timely specialist referrals so that early diagnosis and treatment can be achieved. Improvements in diagnosis and treatment have increased survival for many children with malignant musculoskeletal tumors.
Keywords: Pediatrics, Musculoskeletal tumors
PEDİATRİK MUSKÜLOSKELETAL TÜMÖRLER
ÖZETPediatrik popülasyonda geniş bir yelpazeyi içeren musküloskeletal tümörler görülebilir. Bu tümörlerin ilgili uzmanlara zamanında danışılabilmesi ve dolayısıyla erken tanı ve tedavinin sağlanabilmesi için, doktorların çocukluk çağı musküloskeletal tümörlerinin klinik ve radyografik bulguları hakkında bilgi sahibi olmaları gerekir. Tanı ve tedavideki ilerlemeler habis musküloskeletal tümörlü çocukların çoğunda sağkalım oranını arttırmıştır.
Anahtar Kelimeler: Pediatri, Musküloskeletal tümörler
INTRODUCTION
Pediatric musculoskeletal tumors are uncommon,
and when they occur, are usually benign. Early
detection of a malignant musculoskeletal tumor
may not only make the difference between life
and death, but also may allow for successful limb
salvage surgery rather than amputation of the
limb. The primary bone and soft tissue tumors of
childhood can be classified based on their tissue
origin (Table I).
Table I: Classification of pediatric musculoskeletal tumors based on tissue of origin
Bone tumors
Bone origin; osteoid osteoma, osteoblastoma, osteosarcoma
Cartilaginous origin; osteochondroma, chondroblastoma, chondromyxoid fibroma, enchondroma, periosteal chondroma
Fibrous origin; nonossifying fibroma, fibrous dysplasia, osteofibrous dysplasia, desmoplastic fibroma
Miscellaneous; unicameral bone cyst, aneurysmal bone cyst, giant cell tumor Langerhans cell histiocytosis, Ewing sarcoma
Musculoskeletal manifestations of leukemia Bone lymphomas
Metastatic tumors; neuroblastoma, retinoblastoma, hepatoblastoma
Soft tissue tumors
Vascular tumors; hemangioma, vascular malformations
Nerve origin; neurolemmoma, neurofibroma, malignant peripheral nerve sheath tumor Fibrous origin; fibromatosis, fibrosarcoma
Muscular origin; rhabdomyosarcoma Miscellaneous; synovial sarcoma Primitive neuroectodermal tumors Ganglion and synovial cyst
Marmara Medical Journal 2004;17(3);140-145 Bülent Erol, et al.
Evaluation of Pediatric Musculoskeletal Tumors
EVALUATION
Clinical evaluation
A thorough evaluation of the history of the patient
and physical examination are the basis for
determining the correct diagnosis and therapy.
Children with a musculoskeletal tumor usually
present with pain, mass, pathologic fracture, or
incidental findings on radiographs (Table II). The
physical examination should include
neurovascular examination of the affected
extremity, range of motion of the adjacent joint,
and gait pattern of the patient. The size,
consistency, and mobility of a mass should be
evaluated. For soft tissue masses, small (< 5cm),
superficial, soft, and movable masses are usually,
but not always, benign. On the other hand, large
(> 5cm), deep, firm, fixed, and tender masses raise
suspicion of malignancy and are less commonly
benign.
Table II: Clinical presentations of pediatric musculoskeletal tumors 1) Pain
▪Duration ▪ Localization ▪ Severity ▪ Character
▪ Relief and how obtained 2) Mass
▪ Duration ▪ Size ▪ Consistency ▪ Mobility
3) Pathologic fracture spectrum from microfractures to displaced fractures ▪ Prior symptoms and signs
▪ Mechanism of fracture ▪ Characteristics of fracture 4) Incidental radiographic findings ▪ Prior symptoms and signs ▪ Why radiograph obtained
Most musculoskeletal tumors occur more
commonly in boys than in girls. The gender of the
patient, however, usually does not play a
significant role in formulating the differential
diagnosis. Ewing sarcoma is unusual because it
shows a race association; it is very prevalent in
whites and is rarely seen in African-Americans.
The age of the patient is important in establishing
a differential diagnosis, because certain tumors
tend to occur in certain age groups (Table III).
Table III: Peak age of common pediatric musculoskeletal tumors
Age (years) Benign Malignant
0-5 Langerhans cell histiocytosis Fibrosarcoma Osteomyelitis Metastatic tumors Leukemia Ewing sarcoma --- 5-10 Unicameral bone cyst Osteosarcoma Aneurysmal bone cyst Rhabdomyosarcoma Nonossifying fibroma
Fibrous dysplasia Osteoid osteoma
Langerhans cell histiocytosis
--- 10-20 Fibrous dysplasia Osteosarcoma Osteoid osteoma Ewing sarcoma Fibroma Chondrosarcoma Aneurysmal bone cyst Rhabdomyosarcoma
Marmara Medical Journal 2004;17(3);140-145 Bülent Erol, et al.
Evaluation of Pediatric Musculoskeletal Tumors
Radiographic evaluation
After careful history and physical examination,
looking at the imaging studies of the lesion is the
next step in the evaluation. Plain radiographs give
the most detailed information about skeletal
lesions. Plain radiographs, at least in two views
(anteroposterior and lateral), showing the entire
lesion are necessary. Thirty to 40% of a bone must
be destroyed before changes can be seen in plain
radiographs. It is often difficult to see soft tissue
tumors and soft tissue extension from bony
neoplasms with plain radiographs. It is useful to
ask some questions when evaluating plain
radiographs of bony lesions: Where is the lesion
located in the bone? What is the lesion doing to
the bone? What is the bone doing to the lesion?
What is the periosteal response
1?
The anatomic location of bony lesions should be
identified as epiphyseal, metaphyseal, or
diaphyseal, and central or eccentric (Table IV).
The lesion may be destroying or replacing the
existing bone. Bone destruction can be described
as geographic, moth-eaten, and permeative (Fig.
1).
Although none of these features are
pathognomonic for any specific neoplasm, the
type of destruction may suggest a benign or a
malignant process. Geographic bone destruction
typifies slow-growing, benign lesions, whereas
moth-eaten (i.e., characterized by multiple, small,
often clustered lytic areas) and permeative (i.e.,
characterized by ill-defined, very small oval
radiolucencies or lucent streaks) types of bone
destruction mark rapidly growing, infiltrating
tumors
2. The response of the bone to the
neoplastic process involves the response of the
adjacent cortex and periosteum
3. The lesion may
be contained by the cortex or “walled off” by
dense sclerotic bone, implying a very
slow-growing or static lesion, or it may destroy the
cortex and form a soft tissue mass, mostly
indicating an aggressive neoplastic process. Like
the pattern of bone destruction, the pattern of
periosteal reaction is an indicator of the biologic
activity of a lesion. Although no single periosteal
response is unique for a given lesion, a continuous
periosteal reaction indicates a long-standing
(slow-growing) benign process. An interrupted
periosteal reaction, on the other hand, is
commonly seen in malignant tumors; in these
tumors, the periosteal reaction may appear in a
sunburst (“hair-on-end”) or onion-skin
(lamellated) pattern. A reactive periosteal cuff at
the periphery of the tumor, a Codman’s triangle,
also may form (Fig. 2).
Marmara Medical Journal 2004;17(3);140-145 Bülent Erol, et al.
Evaluation of Pediatric Musculoskeletal Tumors Table IV: Common locations of pediatric bone tumors Epiphysis Pelvis
Chondroblastoma Ewing sarcoma Brodie’s abscess of the epiphyses Osteosarcoma
Giant cell tumor Osteochondroma Fibrous dysplasia Metastasis
Metaphysis Fibrous dysplasia
Any tumor Anterior elements of spine
Diaphysis (FAHEL) Langerhans cell histiocytosis
Fibrous dysplasia Leukemia Osteofibrous dysplasia Metastatic Langerhans cell histiocytosis Giant cell tumor Ewing sarcoma Posterior elements of spine Leukemia, lymphoma Aneurysmal bone cyst Occasional diaphyseal Osteoblastoma Osteoid osteoma Osteoid osteoma Unicameral bone cyst Rib
Multiple Fibrous dysplasia
Leukemia (metastasis) Langerhans cell histiocytosis Multiple hereditary exostoses Ewing sarcoma
Langerhans cell histiocytosis Metastasis Polyostotic fibrous dysplasia
Enchondromatosis
If the radiographs reveal a lesion that has a
potential for malignancy or do not confirm a
specific diagnosis, further staging studies are
indicated. A magnetic resonance imaging (MRI)
and a computed tomography (CT) scan will serve
as the best imaging to further evaluate the lesion.
MRI best demonstrates the soft tissue anatomy
and intramedullary extension of the tumor. The
ability of MRI to produce images of the body in
three planes (axial, sagittal, coronal) provides a
significant advantage in defining the extent of
many tumors (Fig.3A-B)
4. MRI remains the
modality of choice for staging, for evaluating
response to preoperative chemotherapy, and for
long-term followup of most bone and soft tissue
sarcomas. CT can demonstrate bone destruction
and mineralization (calcifications or bone
formation within the tumor), and is particularly
helpful for bone tumors involving axial skeleton
(i.e., pelvis, spine) (Fig.4). A total body
radionuclide bone scan will evaluate the biologic
activity of the primary bone lesion and search for
other lesions within the skeletal system. It may be
indicated to locate obscure lesions such as osteoid
osteoma or stress fracture.
Fig 3A-B: (A) The coronal T2-weighted image of the proximal leg shows an expansile lesion in the proximal fibula, replacing the bone marrow. Increased signal, representing edema is also seen in the muscles surrounding the mass (arrow). (B) The axial T2-weighted image demonstrates complete replacement of the marrow with a large soft tissue component surrounded by a thin layer of new bone formation. In addition, soft nodules (arrows) are seen outside the margin of bone formation. The diagnosis of this lesion is osteosarcoma.
Marmara Medical Journal 2004;17(3);140-145 Bülent Erol, et al.
Evaluation of Pediatric Musculoskeletal Tumors
Fig 4: The axial computed tomography image of the pelvis demonstrates destructive lesions in the right sacral alae and a lytic lesion in the right ilium. The diagnosis of this lesion is Non-Hodgkin’s lymphoma of bone.
Staging and biopsy
Staging of lesions that appear to be malignant is
required prior to biopsy. Staging includes a total
body bone scan, a CT scan of the chest, and a
MRI of the primary lesion (Table V). Based on
these studies, a biopsy can be planned to confirm
the diagnosis. Biopsy should be the last step in the
evaluation of a patient with a bone or soft tissue
sarcoma and should be performed following
completion of the radiographic staging and
preoperative consultation with the oncologist,
radiologist, pathologist, and surgeon. After
staging studies are completed, a differential
diagnosis can be formulated.
Table V: Current treatment principles of malignant bone tumors of childhood Staging of primary lesion and search for other lesions
Magnetic resonance imaging of the primary site including the joint above and below Total body radionuclide bone scan; to search for bone metastases and skip lesions Computed tomography of the chest; to search for lung metastases
Pediatric oncology consultation Incisional biopsy
Intraoperative frozen section
Bone marrow aspiration/biopsy for Ewing sarcoma Broviac placement for chemotherapy
Preoperative neoadjuvant chemotherapy (usually multiagent chemotherapy)
Repeat magnetic resonance imaging after chemotherapy and prior to definitive surgery Radiographic evaluation of the tumor response to chemotherapy (change in size of tumor, change in amount of tumor edema, involvement of neurovascular structures) Surgical planning
Surgery; excision of the tumor with wide surgical margins
Limb-salvage surgery; resection of the tumor with wide surgical margins and reconstruction. Currently, possible in most patients with extremity sarcoma Amputation
Histologic examination of resection specimen
Histologic evaluation of the tumor response to chemotherapy (> 90% tumor necrosis demonstrates good response)
Verification of wide surgical margins
Continued chemotherapy (adjuvant chemotherapy) after local control surgery
Usually same protocol with neoadjuvant chemotherapy if tumor response to chemotherapy is good Followup
Marmara Medical Journal 2004;17(3);140-145 Bülent Erol, et al.
Evaluation of Pediatric Musculoskeletal Tumors
The best biopsy method for a musculoskeletal
neoplasm depends on the differential diagnosis,
the location of the neoplasm, and the ability of the
pathologist to make a diagnosis on a sample of
tissue. A well-planned biopsy provides an
accurate diagnosis and facilitates treatment. On
the other hand, a poorly performed biopsy may
fail to provide a diagnosis and more importantly,
may have a negative impact on treatment options
and/or survival. Needle aspiration may provide
adequate tissue for a histologic diagnosis;
however, many oncologic surgeons prefer an open
incisional technique, which also provides
sufficient tissue for the multiple studies often
needed, including newer molecular diagnostics.
Incisional biopsy involves removing only a
portion of the tumor without contaminating the
surrounding soft tissue structures. A biopsy is best
accomplished at the institution that would perform
the definitive surgery if it becomes necessary
5,6.
REFERENCES
1. Enneking WF: Musculoskeletal tumor surgery. New York, Churchill Livingstone, 1983.
2. Madewell JE, Ragsdale BD, Sweet DE: Radiologic and pathologic analysis of solitary bone lesions. Part I: Internal margins. Radiol Clin North Am 1981; 19: 715-48.
3. Ragsdale BD, Madewell JE, Sweet DE. Radiologic and pathologic analysis of solitary bone lesions. Part II: Periosteal reactions. Radiol Clin North Am 1981; 19: 749-83.
4. Gillespy T III, Manfrini M, Ruggieri P, Spanier SS, Petterson H, Springfield DS. Staging of intraosseous extent of osteosarcoma: Correlation of preoperative CT and MR imaging with pathologic macroslides. Radiology 1988; 167: 765-67.
5. Simon MA, Biermann JS. Biopsy of bone and soft tissue lesions. J Bone Joint Surg 1993; 75A: 616-21.
6. Erol B, Dormans JP, States L, Pawel B. Tumors. In: Cramer KE, ed. Orthopaedic Surgery Essentials-Pediatrics. Philadelphia: Lippincott Williams & Wilkins, 2004: 250-270.
