KNK water and steam batteries are produced with the required dimensions and capacities according to the needs of our customers. In order to choose the most suitable product designs, the calculations are made by using a special software program. In order to implement these calculations, the below stated information has to be informed to our side:
General Information:
Pitch : ...
Air Side Pressure Drop : ...
Water / Steam Side Pressure Drop : ...
Dimensions : ...
Tube Diameter and Die Geometry : ...
Required Information for the Water batteries:
Capacity : ...
Air Flow Rate : ...
Air Inlet Temperature & Humidity : ...
Air Outlet Temperature : ...
Water Inlet Temperature : ...
Water Outlet Temperature : ...
Air Flow Direction : ...
Required Information for the Steam Battery:
Capacity : ...
Air Flow : ...
Air Inlet Temperature : ...
Air Outlet Temperature : ...
Steam Inlet Temperature or Pressure : ...
Air Flow Direction : ...
In our batteries, aluminium, epoxy coated aluminium or copper lamellas are used with the smooth or corrugated surfaces. The lamella thicknesses are varying from 0.12 mm to 0.20 mm depending on the needs.
Copper tubes are used with the diameters of 3/8", 1/2", 5/8". The batteries are bloated as mechanically after the fin line up process by the adjustable automatic machines, in order to provide a complete contact between and due to this process the heat transfer reaches its maximum level.
Die Geometries used in the Batteries:
3/8" tubes: 25x21.65mm and 31.75x27.5mm 1/2" tubes: 31.75x27.5mm and 40x34.64mm 5/8" tubes: 40x34.64mm
In the steam batteries, the tube thickness is as 0.7 mm or 1 mm to be endurable to high levels of pressures. Copper tubes are used in steam battery collectors and in steel tubes are used in hot / cold water battery collectors. Depending on the request , the collector can be made of stainless steel tube as well. Steel fittings are used in the collectors as the standard and depending on the request, brass fittings could be used.
Drains and vents are used in all our products in order to discharged the air and water.
While tube and line number are determined, capacity of customer's need and pressure drop are considered. The most suitable cycling is chosen by comparing the pressure drop and the capacity values.
Unless otherwise stated, the batteries are tested under the pressure of 20 bars in a pool, filled with water of 40-45°C temperature. After this test, the products are washed as externally and dried.
KNK su ve buhar bataryalar›, müflteri ihtiyaçlar›na uygun olarak istenen boyutta ve kapasitede üretilmektedir. Batarya dizaynlar›nda ihtiyaçlar›n›za en uygun ürünü seçebilmek için, gerekli hesaplamalar özel bir yaz›l›m program› kullan›larak gerçeklefltirilir. Bu hesaplar›n yap›labilmesi için afla¤›da belirtilen bilgilerin taraf›m›za iletilmesi gerekir.
Genel Bilgiler:
Hatve : ...
Hava Taraf› Bas›nç Kayb› : ...
Su / Buhar Taraf› Bas›nç Kayb› : ...
Boyutlar : ...
Boru Çap› ve Kal›p Geometrisi : ...
Su Bataryalar› için Gerekli Bilgiler:
Kapasite : ...
Hava Debisi : ...
Hava Girifl S›cakl›¤› & Nemi : ...
Hava Ç›k›fl S›cakl›¤› : ...
Su Girifl S›cakl›¤› : ...
Su Ç›k›fl S›cakl›¤› : ...
Hava Ak›fl Yönü : ...
Buhar Bataryas› için Gerekli Bilgiler:
Kapasite : ...
Hava Debisi : ...
Hava Girifl S›cakl›¤› : ...
Hava Ç›k›fl S›cakl›¤› : ...
Buhar Girifl S›cakl›¤› veya Bas›nc› : ...
Hava Ak›fl Yönü : ...
Bataryalarda yüzeyleri düz ya da dalgal› olarak alüminyum, epoksi kapl› alüminyum veya bak›r lameller kullan›l›r. Lamel kal›nl›klar›, ihtiyaca göre 0.12 mm'den 0.20 mm'ye kadar de¤iflebilir.
Çaplar› 3/8", 1/2", 5/8" olan bak›r borular kullan›l›r. Bataryalar fin dizme ifllemi sonras›nda, tam temas› sa¤layacak flekilde ayarlanan otomatik makinelerde mekanik olarak fliflirilir ve bu sayede ›s› transferi maksimum seviyeye ç›kar›l›r.
Bataryalar›nda Kullan›lan Kal›p Geometrileri:
3/8" borular: 25x21.65mm ve 31.75x27.5mm 1/2" borular: 31.75x27.5mm ve 40x34.64mm 5/8" borular: 40x34.64mm
Buhar bataryalar›nda, 0.7 mm ve 1 mm gibi yüksek bas›nçlara dayan›ml› kal›n etli boru kullan›lmaktad›r. Buhar bataryalar›n›n kolektörlerinde bak›r, s›cak ve so¤uk su batarylar›n›n kolektörlerinde ise çelik boru kullan›l›r. Talep edilmesi durumunda kollektör borusu paslanmaz çelikten yap›labilir.
Kollektörlerde standart olarak çelik rakorlar kullan›lmaktad›r, talep edilmesi durumunda pirinç rakor kullan›lmaktad›r. Tüm ürünlerde hava ve su tahliyesi için pürjör ve manflon kullan›lmaktad›r.
Boru ve s›ra say›s› müflterinin ihtiyac› olan kapasite de¤eri ve bas›nç kayb› göz önünde bulundurularak belirlenir.
En uygun devreleme flekli, bas›nç kayb› ve kapasite de¤erleri karfl›laflt›r›larak seçilir.
Aksi belirtilmedikçe bataryalar montaj sonras›nda 20 bar bas›nç ile 40-45°C s›cakl›ktaki su ile dolu havuzda test edilirler. Test sonras› ürünlerin d›fl y›kamas› yap›l›r ve kurutulur.
SU VE BUHAR BATARYALARI WATER AND STEAM COILS
Katalog de¤erlerinde haber verilmeksizin de¤ifliklik yapma hakkı tarafımızca saklı tutulur.
All rights of changing any technical information are reserved without notice.
**
KNK air-conditioner condensers and evaporators are produced with any dimensions and capacities required, according to the needs of our customers. The production is realized with same capacity and dimensions, due to the picture, sample or the data sent by the customer. The calculations of capacities and dimensions for the products are carried out sensitively by the use of our special software program.
For the batteries with 3/8" pipe, 25x12.5mm, 25x21.65mm or 31.75x27.5mm fin dies are used; for the batteries with 1/2" pipe, 31.75x27.5mm or 40x34.64mm fin dies are used; for the batteries with 5/8" pipe, 40x34.64 mm fin die is used.
Depending on the needs, for the specified dies, the diamond formed production can be implemented.
All of the condenser and evaporator batteries are tested by a 35 bar pressure and they are all delivered with 3 bars nitrogen.
Depending on our customers needs, the products are electrostatic powder dyed and RAL 7038 is used as the standard color.
KNK klima kondenser ve evaporatörleri, müflteri ihtiyaçlar›na uygun olarak istenen boyutta ve kapasitede üretilmektedir.
Üretim kapasite ve boyut olarak müflteri taraf›ndan gönderilen resim, numune veya verilere uygun biçimde
gerçeklefltirilmektedir. Ürünler ile ilgili kapasite ve boyut hesaplar› kullan›lan yaz›l›m program› sayesinde hassas bir biçimde yap›labilmektedir.
3/8" borulu bataryalarda 25x12.5mm, 25x21.65mm veya 31.75x27.5mm kal›plar;
1/2" borulu bataryalarda 31.75x27.5mm veya 40x34.64mm kal›plar; 5/8" borulu bataryalarda 40x34.64mm kal›p kullan›lmaktad›r.
Talep edilmesi durumunda, belirtilen kal›plar için baklaval›
formda üretim gerçeklefltirilebilmektedir.
Tüm kondenser ve evaporatör bataryalar› 35 Bar bas›nç de¤erinde test edilir ve test sonras› 3 bar azot ile sevk edilir.
Müflteri taraf›ndan talep edilmesi durumunda ürünler elektrostatik toz boya ile boyan›r ve standart renk olarak RAL7038 kullan›l›r.
KL‹MA EVAPORATÖRLER‹ VE KONDENSERLER‹
A/C EVAPORATORS AND CONDENSERS
KL‹MA EVAPORATÖRLER‹ VE KONDENSERLER‹
A/C EVAPORATORS AND CONDENSERS
Düz / Flat Dalgal› / Corrugated
Standart gövde malzemesi olarak, alüminyum veya galvanizli sac kullan›l›r.
‹stek halinde di¤er malzemeler kullan›labilir.
Aluminium or
galvanized sheets are used as standart casing material.
Other materials are used as well on request.
TUBE SPECIFICATION
Hatve Kal›nl›k Malzeme Yüzey Kenar
Fin Spacing Thickness Material Surface Edge
25mm x 12.5mm Çapraz dizilifl
Staggered 25mm x 21.65mm
Çapraz dizilifl Staggered 31.75mm x 27.5mm
Çapraz dizilifl Staggered 31.75mm x 27.5mm
Çapraz dizilifl Staggered 40mm x 34.64mm
Çapraz dizilifl Staggered 40mm x 34.64mm
Çapraz dizilifl Staggered Ø3/8" (9.52mm)
Ø1/2" (12.7mm)
Ø1/2" (12.7mm)
Ø5/8" (15.9mm)
BORU ÖZELL‹KLER‹ F‹N ÖZELL‹KLER‹
FIN SPECIFICATION Çap
Diameter
Kal›nl›k Thickness
Geometri Geometry
Düz,Dalgal›
Flat,Corrugated
Düz,Dalgal›
Flat,Corrugated 0.35mm
0.40mm
0.40mm
1.6mm-4.2mm
1.6mm-8mm
1.8mm-10mm
0.12mm-0.2mm
0.12mm-0.2mm
0.12mm-0.2mm
Alüminyum/ Bak›r Amuminium/Copper
ÜRÜN ÖZELL‹KLER‹
PRODUCT SPECIFICATION
