290
Video Article / Video Makalesi
Turkish Journal of Thoracic and Cardiovascular Surgery 2021;29(2):290-291
http://dx.doi.org/doi: 10.5606/tgkdc.dergisi.2021.20728
Transcatheter tricuspid valve-in-valve implantation
in a dysfunctional bioprosthetic valve
Transkateter yolla disfonksiyonel biyoprotez kapak içine triküspit kapak implantasyonu Alper Güzeltaş, İbrahim Cansaran Tanıdır, Bekir Yükcü, Erman Cilsal, Murat Şahin
Department of Pediatric Cardiology, Istanbul Mehmet Akif Ersoy Thoracic and Cardiovascular Surgery Training and Research Hospital, Istanbul, Turkey
Received: September 08, 2020 Accepted: December 25, 2020 Published online: April 26, 2021
Correspondence: Alper Güzeltaş, MD. İstanbul Mehmet Akif Ersoy Göğüs Kalp ve Damar Cerrahisi Eğitim ve Araştırma Hastanesi,
Çocuk Kardiyoloji Kliniği, 34303 Küçükçekmece, İstanbul, Türkiye. Tel: +90 542 - 256 06 01 e-mail: alperguzeltas@hotmail.com
©2021 All right reserved by the Turkish Society of Cardiovascular Surgery.
This is an open access article under the terms of the Creative Commons Attribution-NonCommercial License, which permits use, distribution and reproduction in any medium, provided the original work is properly cited and is not used for commercial purposes (http://creativecommons.org/licenses/by-nc/4.0/).
Güzeltaş A, Tanıdır İC, Yükcü B, Cilsal E, Şahin M. Transcatheter tricuspid valve-in-valve implantation in a dysfunctional bioprosthetic valve. Turk Gogus Kalp Dama 2021;29(2):290-291
Cite this article as:
A 23-year-old female patient was being followed due to Ebstein anomaly since birth. Cone procedure was performed, when the patient reached 21 years old, due to the increased tricuspid valve insufficiency and New York Heart Association (NYHA) Functional Class IV. Valve insufficiency was considered mild-to-moderate postoperatively. One month after the operation, the patient referred to the hospital with heart failure and echocardiography revealed severe tricuspid valve insufficiency. A Pericarbon More™ stented biological valve (Sorin Group, Saluggia, Italy) No. 31 was surgically implanted in the tricuspid position and an epicardial pacemaker was implanted due to permanent atrioventricular block after surgery. Although tricuspid valve functions were good during the early postoperative period, valve functions were gradually deteriorated over time. Two years after surgery, transthoracic and transesophageal echocardiography revealed that one of the Pericarbon More™ valve leaflets was immobile, while the other leaflets were thickened, resulting in severe tricuspid valve insufficiency and moderate tricuspid valve stenosis (Video 1 and 2).
The patient was admitted to cardiac catheterization lab for transcatheter tricuspid valve-in-valve
implantation. A 29-mm Edwards Sapien-XT® valve
(Edwards Lifesciences Corp., CA, USA) was prepared with adding 2-cc extra volume to its balloon. The pacing rate of the epicardial pacemakers pacing rate increased to 180 bpm during valve implantation into the tricuspid position (Video 3). Severe tricuspid valve
insufficiency and stenosis were diminished after new valve implantation. Angiographic stenosis gradient decreased from 15 mmHg to 5 mmHg, and the valve functions were good in the post-interventional period with no valvular insufficiency (Video 4 and 5).
In conclusion, transcatheter valve implantation into the bioprosthesis at the tricuspid valve position is an effective method for reducing the number of repetitive surgical interventions.[1-3]
291 Güzeltaş et al.
Transcatheter tricuspid valve-in-valve implantation
Declaration of conflicting interests
The authors declared no conflicts of interest with respect to the authorship and/or publication of this article.
Funding
The authors received no financial support for the research and/or authorship of this article.
REFERENCES
1. Gaia DF, Palma JH, de Souza JA, Buffolo E. Tricuspid transcatheter valve-in-valve: An alternative for high-risk patients. Eur J Cardiothorac Surg 2012;41:696-8.
2. McElhinney DB, Cabalka AK, Aboulhosn JA, Eicken A, Boudjemline Y, Schubert S, et al. Transcatheter tricuspid valve-in-valve implantation for the treatment of dysfunctional surgical bioprosthetic valves: An International, Multicenter Registry Study. Circulation 2016;133:1582-93.
3. Sanon S, Cabalka AK, Babaliaros V, Rihal C, Gafoor S, Webb J, et al. Transcatheter tricuspid valve-in-valve and valve-in-ring implantation for degenerated surgical prosthesis. JACC Cardiovasc Interv 2019;12:1403-12. Video 4. Transesophageal and transthoracic echocardiography after surgery showing the movements of Edwards Sapien XT®
valve. No insufficiency in color Doppler imaging.
Video 3. Transcatheter valve-in-valve implantation with Edwards Sapien XT® valve into the tricuspid position. Heart rate increasing
to 180 bpm with epicardial pacemaker pacing while inflating the balloon to ensure valve stabilization.
Video 5. Three-dimensional transesophageal echocardiography showing normal valve functions of Edwards Sapien XT® after the
procedure. Video 2. Three-dimensional transesophageal echocardiography
