Current Diagnosis and Management of Red-Cell
Alloimmunization
11
thCongress of Maternal Fetal Medicine and Perinatology Society of Turkey
Giancarlo Mari, MD, MBA, FACOG, FAIUM Professor and Chair
Dept. of Obstetrics and Gynecology UTHSC, Memphis, TN
At the end of this presentation the participants will be able
• To Describe
– The Rh alloimmunization story
– The role of Doppler ultrasound of the middle cerebral artery in fetal anemia
– The standard of care for the diagnosis and
management of fetal anemia
Definition of fetal anemia
Hemoglobin value below the 5 th percentile (2 SD; 95% CI)
for gestational age
Causes of fetal anemia
• Red blood cell alloimmunization
• Infections
• Fetomaternal hemorrhage
• Twin-twin-transfusion syndrome
• Thalassemia
• Enzymopathies
• Fanconi anemia
• Diamond-Blackfan anemia
Before 1968
>10,000 deaths in the USA for HDN
Rh hemolytic disease United States
~ ??? cases per year
Rhogam (1968)
“Irregular” red blood cell antigens
Blood group system Antigen
Rh C, c, e, E
Kell K, k, Ko, Kpa, Kpb, Jsa, Jsb Duffy Fya, Fyb, Fy3
Kidd Jka, Jkb, Jk3
MNSs M, N, S, s, U, Mia, Mta, Vw, Mur, Hil, Hut
Lutheran Lua, Lub
Diego Dia, Dib
Xg Xga
P PP1pk(Tja)
Public antigens Yta, Ytb, Lan, Ena, Ge, Jra, Coa, Coa-b- Private antigens Batty, Becker, Berrens, Biles, Evans,
Gonzales, Good, Heibel, Hunt, Jobbins, Radin, Rm, Ven, Wrighta, Wrightb, Zd
Karl Landsteiner
Nobel prize in Physiology/Medicine (1930) for
his discovery of human blood groups (1901)
Philip Levine, MD
RH and Fetal hemolytic disease (1937-1941)
K. Landsteiner - A,B,O phenotypes: 1901 K. Landsteiner and Wiener - anti-Rh: 1940 P. Levine - anti Rh cause of HDN: 1941 D. Bevis - Amniocentesis in HDN: 1953
Rh – Medical Discoveries
Albert William Liley
DeltaOD450 (1961)
Rh-Cell Alloimmunization:
The Story
Freda V, Am J Obstet Gynecol 1964;89:817-21
Vincent Freda and John O. Gorman (1968)
Rhogam
Cyril A. Clarke Ronald Finn
Lasker award in 1980
William Pollack
Vincent J. Freda John G. Gorman
Fetoscopy
A) Diagnosis of open spina bifida B) Fetal blood sampling
Valenti C. Am J Obstet Gynecol 1973;11:581
Fernand Daffos
Cordocentesis (1983)
Cord blood sampling
Daffos F, et al. Am J Obstet Gynecol 1983;146:985
Amniocentesis Cordocentesis
Fetal Anemia
24 wks
1
2 3
4
5 6
Mari
Blood velocity in anemia
Viscosity CO
Velocity
Christian J. Doppler was an
Austrian physicist who described the Doppler effect in 1842.
Fd = 2(Fc x V x cos α) C
Doppler Formula
Mari
Angle Dependence
Mari
Middle Cerebral Artery Peak
Systolic Velocity
C B A
D
Where to sample the MCA?
A
C
It is easy to sample the MCA with an angle of zero degrees, which allows for the real
velocity of the blood flow to be determined.
These are the steps for the correct sampling of the middle cerebral
artery peak systolic velocity.
The use of an angle corrector increases the intra- and inter-observer variability; therefore, its use is not recommended.
B
D
E F
Ultrasound Obstet Gynecol 1995;5:400
Ultrasound Obstet Gynecol 1995;5:400
Gestational Age (weeks)
16 18 20 22 24 26 28 30 32 34 36
Hemoglobin (gr/dl)
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
95
50
5
Moderate Anemia Severe Anemia
Severe Anemia with risk of Hydrops Mild Anemia
N Engl J Med. 2000;342(1):9-14
N Engl J Med. 2000;342(1):9-14
Mari G, et al N Engl J Med 2000; 342:9
1.5 MoM
Prospective study on an intention to treat
• Multicenter study in 5 tertiary referral centers
• 125 fetuses at risk for anemia
• MCA-PSV used for timing a cordocentesis
Zimmermann R, et al. Br J Obstet Gynaecol 2002;109:746
False Positive Rate
• MCA PSV single value: False positive rate: 12%
• MCA PSV trend: False positive rate: <5%
N Engl J Med 2000; 342:9
Zimmermann R, et al. Br J Obstet Gynaecol 2002;109:746
N Engl J Med 2006;355:156
All Truth Passes Through Three Stages:
•
First It Is Ridiculed• Second It is Violently Opposed
• Third It is Accepted As Being Self-Evident
A. Schopenhauer
Management of Alloimmunization
Argoti P, et al. Minerva Ginecologica, in press
Intrauterine transfusion
Overall rate of complications of 3.3% per fetus and 1.2% per procedure
A fetal loss rate of 17% when the fetal blood sampling is performed at < 20 weeks.
Zwiers C, et al. Ultrasound Obstet Gynecol. 2017;50(2):180-6
Intrauterine transfusion
• VOLUME TO TRASFUSE INTRAVASCULARLY = (Desired hematocrit-Fetal hematocrit/Donor hematocrit-desired hematocrit) x Fetoplacental volume
• VOLUME TO TRANSFUSE INTRAPERITONEALLY = (GA in weeks – 20 ) x 10
Transfusion Intervals
• The MCA-PSV hold its negative predictive value and may be factored when planning subsequent IUT intervals
• A recent randomized trial, that compared timing of
subsequent transfusions with the use of the MCA-PSV (serial upward trend of values > 1.5 MoM) vs. expected decrease in fetal hematocrit found no differences in mean hemoglobin levels at birth, number of IUT procedures or in the rates of adverse infant outcomes
Dodd JM, et al. Ultrasound Obstet Gynecol. 2018;51(3):306-12
Immunoglobulin
Zwiers C, et al. Am J Obstet Gynecol. 2018;219(3):291 e1- e9
PETIT study: retrospective study in 12 fetal therapy centers, of early onset, (<13 weeks of gestation) intrauterine
immunoglobulin treatment, of pregnancies previously affected by severe hemolytic disease of the fetus and newborn (HDFN)
Results suggested that IG therapy may delay the onset of severe anemia and may decrease the incidence of hydrops and the need of newborn exchange transfusion
Is the MCA-PSV reliable for the diagnosis of fetal anemia due to
other causes?
Which patients are candidates for the assessment of the MCA-PSV?
• Patients at risk for having an anemic fetus
• Indiscrimate use of the MCA-PSV may cause more
harm than good
Conclusion
RH story
• A successful story in Fetal Medicine
• Mirror of what is happening in Fetal Medicine
First “Do no harm”
Case 1 History
• Rising delta OD
450in amniotic fluid
• 33 yo, G3 P0 Rh sensitized (anti D = 1/64)
• Fetus is Rh positive
Delta OD 450
20 25 30 35
Gestational age (weeks)
0.02 0.50
0.10
●
●
Low
Intermediate
Severe
Extremely High
Case 1 History
• Referred at 22.1 weeks’ gestation
• Cordocentesis at 22 weeks (unsuccessful)
• Rising delta OD
450in amniotic fluid
• 33 yo, G3 P0 Rh sensitized (anti D = 1/64)
• Fetus is Rh positive
Anti D = 1/256 Middle Cerebral Artery Peak Systolic Velocity
Gestational Age (wks)
Median 1.5MoM
●
● ●
Hgb = 5.5 g/dL
● MCA-PSV 70cm/S
Hgb = 7.4 g/dL
● 50cm/s
●
32cm/s
●
●
●
Hgb = 9.0 g/dL
Gestational Age (weeks)
18 20 22 24 26 28 30 32 34 36 38 40
Hemoglobin (gr/dl)
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
Severe Anemia Moderate Anemia Mild Anemia
95
50
5
Is the delta OD 450 better than MCA-PSV or vice versa?
• Am J Obstet Gynecol 1997 (SMFM);180:18
• Pereira L, et al. Am J Obstet Gynecol 2003;189:1002-6
• Oepkes D, et al Am J Obstet Gynecol 2004 (SMFM);194:3
