Asma Khalil
St George’s Hospital, University of London, UK TTTS - MCDA TAPS - MCDA
TTTS: Modern management
• Caused by vascular anastomoses on the placenta with unbalanced blood flow between the twins
• Polyhydramnios-oligohydramnios
• Cardiac compromise
TTTS: Pathogenesis
Deepest vertical pocket:
16-20 weeks: >8cm AND <2cm
>20 weeks: >10cm AND <2cm
Diagnosis
TTTS: Diagnosis
Modified Diagnostic Criteria of TTTS
• >18 weeks
• Oligohydramnios (DVP ≤ 2cm)
• Polyhydramnios (DVP ≥ 6cm)
• 18-20 weeks
• Oligohydramnios (DVP ≤ 2cm)
• Polyhydramnios (DVP ≥ 8cm)
•>20 weeks
• Oligohydramnios (DVP ≤ 2cm)
• Polyhydramnios (DVP ≥ 10cm)
DVP in MCDA twins
Khalil UOG 2017
I: bladder donor visible II: donor empty bladder
III: critically abnormal Dopplers IV: Hydrops in one or both twins V: IUFD of one twin
Quintero Staging
TTTS: Staging
What is the staging of TTTS?
Although Quintero staging does not always accurately predict outcome or chronological evolution of TTTS, it still remains the most commonly used classification system.
Stage Classification
I Polyhydramnios oligohydramnios sequence: DVP >8cm in the recipient and DVP < 2cm in the donor
II Bladder in the donor twin not visible on ultrasound scan
III Absent or reversed umbilical artery diastolic flow, reversed ductus venosus a-wave flow, pulsatile umbilical vein flow in either twin
IV Hydrops in one or both twins V Death of one or both twins
TTTS: Staging
• Stage II, III, VI
• Symptomatic stage I
• Expectant
• Fetoscopic laser surgery
• Amniodrainage
• Cord occlusion
• TOP
When to treat
Treatment Options
TTTS: Treatment
Endoscopic laser surgery for severe TTTS
Laser vs amnioreduction
Overall survival 1.5x Donor survival 1.3x
Recipient survival 2.0x Neurological damage 0.3x Laser vs amnioreduction (n=142)
- survival (>1) 76% vs 50%
- cystic PVL 6% vs 14%
Senat et al. NEJM 2004
Endoscopic laser surgery for severe TTTS
TTTS <26 wks: Fetoscopic surgery vs amnioreduction
0.1 0.5 1 2 5 10
1.26 (0.68, 2.31) 1.14 (0.54, 2.41) 1.76 (0.91, 3.39)
Odds ratio (95% confidence interval)
0.1 0.5 1 2 5 10
Quintero 1.32 (0.85, 2.03) 2.44 (1.22, 4.90)
Hecher 1.49 (0.87, 2.55) 2.57 (1.11, 5.94)
Senat 2.07 (1.30, 3.29) 2.94 (1.48, 5.81)
1.44 (0.78, 2.67) 2.02 (0.93, 4.41) 2.32 (1.21, 4.48) Quintero
Hecher Senat
Overall survival
Recipient survival Donor survival
At least one survival
Study Outcome Odds ratio Outcome Odds ratio
0.15 (0.07, 0.34) 0.24 (0.07, 0.82) 0.43 (0.27, 0.69) Quintero
Hecher Senat
Neurological Morbidity
Pre-op assessment
Exclude fetal anomalies (+/-detailed echo), placental site, cord insertions and cervical length FLS for stage II-IV TTTS and for symptomatic stage I TTTS or stage 1 with short cervix
FLS scheduled within 24-48 hours from 16 weeks’ gestation
Pre-surgical management
Blood group and Rhesus typing
Scan to check viability and reconfirm donor axis, cord insertions and determine entry site Utero relaxant: Indomethacin 100mg PR or Nifedipine 10mg PO
Analgesia: Diclofenac 100 mg PR stat; co-dydramol 2 tablets PO stat; Pethidine 50-100mg IM Anxiolytic: Diazepam 10 mg PO or Diazemuls 5- 10mg IV
Antibiotics: Cefuroxime 750mg or 1.5 g IV; Clindamicin 600mg IV if penicillin allergic
Endoscopic Laser surgery for severe TTTS
Procedure in dedicated operating room in Fetal Medicine or Laser-safe LW theatre
Operators Laser certified and competent at use of ultrasound, endoscopy stack and fetoscope assembly Diode Laser set starting at 30-50 watts; Nd:Yag wavelength 1064 nm power 50-60 W
Choice of straight zero degree and 30 degree “steerable” or curved fetoscopes;
Size of fetoscope: 1.6mm to 2.2mm
Protocol
Endoscopic Laser surgery for severe TTTS
Sterile procedure and anaesthesia
Aseptic technique
Placement of sterile covers over instruments that approach table
Insertion
Full assembly of fetoscope and check of Laser safe environment, check of aiming beam Anaesthesia: Local infiltration (10-20mls 1% lidocaine) to skin and peritoneum or spinal Anaesthesia.
2-3 mm skin incision with surgical knife
Insertion of fetoscope trocar under US guidance PCR or Karyotype/Array sent at amniodrainage Amnioinfusion in selected cases
Confirmation of site of intertwin membrane and then placental vascular equator
Laser coagulation
Solomon technique
Amniodrainage post Laser
Controlled drainage of polyhydramnios to “normalise” amniotic fluid
Endoscopic Laser surgery for severe TTTS
Follow-up
US assessment 1-6hrs post-op
Same day discharge or admit overnight
Clear documentation of labelling of donor and recipient twins by laterality/cord insertions Telephone update of referring clinicians, written update
Scan locally in 1 week and then fortnightly if comfortable with MCA PSV assessment Fetal MRI to be considered from 28 weeks’ gestation
What is the treatment of choice for TTTS?
Laser ablation is the treatment of choice for TTTS at
Quintero stage ≥II. A
Conservative management with close surveillance or laser ablation can be considered for Quintero stage I.
B
When laser expertise is not available, serial amnioreduction is an acceptable alternative after 26 weeks.
A
Centres performing Laser for TTTS: at least 15 procedures/year
TTTS: Treatment
TTTS: Stage 1
Evolution of Stage 1 TTTS: Systematic Review and Meta-Analysis
Progression 27%
Expectant
At least 1 survival 87%
Amnioreduction
86%
Overall survival Double survival
79%
70%
77%
67%
Laser
81%
68%
54%
Khalil et al TRHG 2016
North American Fetal Therapy Network: intervention vs expectant management for stage I TTTS
Emery et al AJOG 2016 0
10 20 30 40 50 60 70 80 90 100
Expectant (n=49) Amnioreduction (n=30)
Laser surgery (n=45)
Survival (%)
Double survival
At least one survival (p=0.02) No survival (p=0.01)
• Retrospective multicentre cohort study
• Stage I TTTS was associated with substantial fetal mortality
• Progression in 30%
• Both amnioreduction and laser therapy ↓ the chance of no survivors
• Laser was protective against poor outcome independent of multiple factors
TTTS: Stage 1
• Monitor for TTTS from 16 wk.
• Scan every 2 weeks
• If fluid discordance:
• refer woman to a 3ry level fetal medicine centre
NICE 2011
TTTS: Screening
TTTS vs Fluid discordance
What is the protocol for screening for TTTS?
Start at 16 weeks and repeat every 2 weeks thereafter
What is the prognosis for MC twin pregnancies with amniotic fluid discordance?
Follow up on a weekly basis for progression to TTTS
• Good outcome (93% overall survival)
• Low risk of progression to severe TTTS (14%)
11-14 week
• Dating, labelling
• Chorionicity
• Screening for trisomy 21
20-22 week
• Detailed anatomy
• Biometry
• Amniotic fluid volume
• Cervical length
24-26 week
28-30 week
• Assessment of fetal growth
• Amniotic fluid volume
• Fetal Doppler
36-37 week
Delivery 32-34 week
• Assessment of fetal growth
• Amniotic fluid volume
• Fetal Doppler
• Assessment of fetal growth
• Amniotic fluid volume
• Fetal Doppler
• Assessment of fetal growth
• Amniotic fluid volume
• Fetal Doppler
Dichorionic Twin Pregnancy Monochorionic Twin Pregnancy
11-14 week
• Dating, labelling
• Chorionicity
• Screening for trisomy 21
20 week
• Detailed anatomy
• Biometry, DVP
• UA PI, MCA PSV
• Cervical length
28 week 30 week
34 week 32 week
16 week • Fetal growth, DVP
• UA PI
18 week • Fetal growth, DVP
• UA PI
• Fetal growth, DVP
• UA PI, MCA PSV
• Fetal growth, DVP
• UA PI, MCA PSV
• Fetal growth, DVP
• UA PI, MCA PSV
• Fetal growth, DVP
• UA PI, MCA PSV
22 week 24 week
26 week • Fetal growth, DVP
• UA PI, MCA PSV
• Fetal growth, DVP
• UA PI, MCA PSV
• Fetal growth, DVP
• UA PI, MCA PSV
36 week • Fetal growth, DVP
• UA PI, MCA PSV
Twin Pregnancy:
ultrasound monitoring
How should TTTS be followed-up and what is the optimal GA for delivery?
Weekly ultrasound assessment for the first two weeks after treatment, reducing to alternate weeks following clinical evidence of resolution.
In case of sIUD (post-laser)
Brain imaging in 4-6 weeks
Neurodevelopmental assessment at 2 years of age
TTTS: Management
GA at delivery: 34 weeks
Stirnemann et al AJOG 2012
Outcome of Fetoscopic Laser surgery for TTTS in Twins
• Double survival: 60%
• At least one survival: 80%
• GA at birth 33 weeks
• Cerebral palsy: 7%
• Neurologic impairment: 13%
Short-term
Long-term
TTTS: Treatment
Major neurological abnormalities:
• 7% at 34 months
• 9% at 6 years
Hoffmann et al AJNR 2013 Quarello et al JMFNM 2007 Hillman et al Obst Gyn 2011 Inklaar et al Prenat Diagn 2014
Banek et al AJOG 2003 Graef et al AJOG 2006 Graeve et al Acta Pediat 2012
The Fetal Medicine Foundation
Antenatal Brain
abnormalities (8%) Amnioreduction (14%) Laser (5%)
Expectant (21%)
Neurodevelopmental Delay
•TTTS pathology
•TTTS treatment
•Prematurity
Hoffmann et al AJNR 2013 Quarello et al JMFNM 2007 Hillman et al Obst Gyn 2011
Banek et al AJOG 2003 Graef et al AJOG 2006 Graeve et al Acta Pediat 2012
The Fetal Medicine Foundation
TTTS treated with Laser
Fetal brain MRI in the 3
rdtrimester (n=51)
Double survival
(n=45, 88.2%) sIUD
(n=6, 11.8%)
• Any brain abnormality (n=7, 7.3%)
• Major brain abnormality (n=3, 3.1%)
• GA at the Laser treatment: 17-27 weeks
• Fetal brain MRI performed: 26-35 weeks
96 fetuses undergoing brain MRI
The Fetal Medicine Foundation
Major abnormalities
• Polymicrogyria / bilateral malformation of cortical development
• Irregular cortical development / schizencephaly
• Ventriculomegaly and IVH
The Fetal Medicine Foundation
Minor abnormalities
• Delayed sulcation
• Mild ventriculomegaly
• Choroid fissure cyst
The Fetal Medicine Foundation
Brain abnormality
GA at TTTS
GA at
Laser D/R Complications
Polymicrogyria 22 22 D Cardiomegaly
Pericaridal effusion
Schizencephaly 17 17 R sIUD
Ventriculomegaly + IVH 16 19 R TAPS
Major abnormalities
• Incidence: 2-3%
• Both donor and recipient at risk
• Ischaemic and haemorrhagic brain abnormalities
• Risk factors: Incomplete Laser surgery
• TAPS
• Recurrence of TTTS
TTTS and brain abnormalities
Quarello E-et al. J Matern Fetal Neonat Med 2007
IVH (grade II) with heterogeneity of the Rt choroid plexus and of the
ipsilateral subependymal area
Bilateral IVH with extension into the left periventricular parenchyma (grade III)
Mild VM
Brain abnormalities reported
• Ventriculomegaly
• White matter injury
• Ischaemic lesions
• Periventricular leukomalacia
• IVH
• Cerebral atrophy
TTTS and
brain abnormalities
In case of sIUD (post-laser)
Brain imaging in 4-6 weeks
Neurodevelopmental assessment at 2 years
sIUD following Laser for TTTS
GA at delivery: 34 weeks
Stirnemann et al AJOG 2012
Postoperative period with highest risk of sIUD after Laser?
First postoperative week (70%) Risk factors for Donor demise:
• UA AREDF
• Growth discordance >30%
• Marginal/velamentous cord insertion
• Large number of anastomoses
Brain Abnormalities following sIUD
Griffiths et al Prenat Diagn 2015
Spontaneous Following Laser
AN brain abn 12% 15%
Infarction
Polymicrogyria
• 28 years old, P1
• Husband is studying medicine in the UK
• spontaneous MCDA twin pregnancy
• First scan at 12 weeks: no concern
• Next scan booked at 20 weeks
• 20+4 weeks
• Twin 1: sIUD, oligohydramnios
• Twin 2: alive, polyhydramnios
• Urgent referral to SGH:
• Twin 1 (demised) has oligohydramnios
• Twin 2 had polyhydramnios + severe anaemia
• Planned for urgent IUT
• Fetal brain MRI in 5 weeks
• Follow-up scans: no concern
• Fetal brain MRI at 26 weeks
irregularity at the superior aspect of the
bodies of the lateral ventricles, representing focal subependymal cystic changes. This
could be due to infection or focal white
matter injury (due to hypoxia either arterial or venous).
Fissuration is lagging 1-2 weeks.
We could organize a follow up scan to
monitor the changes.
• Follow-up scans: no concern
• Repeat Fetal brain MRI at 30 weeks
The repeat fetal brain MRI has confirmed evidence of periventricular white matter injury, which might be asociated with
neurological disability. However the brain has matured since the previous MRI, with normal sulcation for gestational age.
The parents remain committed to this
pregnancy and will not consider the option
of termination of the pregnancy. In fact, they
are moving to Canada in approximately 10
days. We would be happy to be contacted if
there is any concern.
Dear Asma,
Thank you for all the help and support you gave us to give this baby a chance to be with us today. we truly appreciate. like i promised to inform you, the baby is here. I was induced on the 28th of October, was already 2cm dilated as at the time i got to the hospital. The
induction started at 11am and he arrived 7.31pm at 7 pounds 4.4ounces. He was checked by the piediatrician and they feel he is meeting all milestones so far but we keep an eye on him. But i truly beleive all is fine with him.
I will bring him in to visit you once we return to London.
we are still in the hospital treating Jaundicr with photo therapy and he is getting better. I have attached his picture to this email. Tank you so much once again.
Kind regards,
Ndidiamaka
• 2
ndpregnancy
• Spontaneous MCDA twin
• 12 wk: normal
Low risk for Tr21, 18, 13
•16 wk: TTTS (AFV and size discordance)
T1 polyhydramnios
suspected CHD in T1 (R)
• ECHO 16 wk: pulmonary stenosis sinus bradycardia
•US at 17 wk: progression of TTTS
Laser surgery
• Post-Laser Rupture of the membranes
• Follow-up scans
• TTTS resolution
• 20 wk: moderate pulmonary stenosis in T1
• 20 wk: hyperextended neck in T2 (Ex-donor)
• Fetal brain MRI at 22 wk
Twin 1: normal brain Twin 2: abnormal
•Marked hyperextended neck
•large area of thinning of the cerebral mantle affecting both hemispheres over the frontoparietal convexities in a fairly symmetrical distribution
• Irregular cortical and ventricular surface.
•The distribution is compatible with hypoxic ischaemic brain injury causing
scarring or possibly bilateral cerebral malformation.
• Counselling re: selective cord occlusion
•Risk of PTL
•Pulmonary stenosis in T1
•Would T2 survive?
• T1: Normal growth velocity and Doppler
• T2: polyhydramnios, stomach invisible
• Contingency plan if preterm labour
• Course of steroids
• Repeat fetal brain MRI at 31 wk
Twin 1: normal brain Twin 2: abnormal
•Marked hyperextended neck
•Extensive malformation of cortical folding bilaterally involving the frontal and parietal lobes, insula and superior temporal regions.
•The brainstem and cerebellum appear normal.
•Extensive bilateral cerebral cortical malformation.
• 32wk:
•T2: Severe polyhydramnios + stomach not visible
•Mother is symptomatic
•Opted for selective cord occlusion
•Repeat course of steroids
• 33wk:
•PTL
•Uncomplicated emergency CS
•T1 doing well
TTTS: Laser technique
Solomon Trial: Selective Or Laser of the entire equator in MONochorionic pregnancies
TAPS or Recurrence
Selective Solomon
Composite outcome
P value
22% 4% <0.001
49% 34% 0.004
Primary composite outcome:
•Perinatal mortality
•Perinatal morbidity (TAPS or recurrence)
•Severe neonatal morbidity
Slaghekke et al.Lancet 2014
Complications of Fetoscopic Laser TTTS
• Single or double IUD
• Bleeding:
• Introduction site
• Placental surface
• Rupture of the membrane
• Amniodehiscence
• Iatrogenic monoamniocity
• Intrauterine infection
TTTS: Treatment
Outcome of Fetoscopic Laser surgery for TTTS in Triplet
Overall survival
DC MC
Survival of at least one fetus
P value
76% 51% <0.05
91% 70% <0.05
GA at delivery 31 28 <0.05
TTTS in Triplet Pregnancy
Twin Anaemia
Polycythaemia Sequence
• Chronic feto-fetal transfusion
• Large inter-twin Hb differences, without signs of TOPS
• Few minuscule anastomoses at the
placental surface (<1mm) allowing a slow transfusion of blood
Slaghekke et al, Fetal Diagn Therap 2010 Lopriore et al, Placenta 2007
Diagnostic Criteria
TAPS: Diagnosis
POSTNATAL
• Intertwin Hb difference >8.0 g/dl and
• at least one of the following:
• Reticulocyte count ratio >1.7
• Placenta with only small (<1mm) vascular anastomoses
ANTENATAL
• MCA-PSV >1.5 MoM in the donor and
• MCA-PSV <1.0 MoM in the recipient
Incidence
• Spontaneous: 3-5% MC twin pregnancies
• Post-laser: 2-13% TTTS cases
Placenta: minute (<1mm) AV anastomoses
Slaghekke et al, Fetal Diagn Therap 2010 Lopriore et al, Prenat Diagn 2010
AN staging
TAPS: Staging
Stage 1: MCA-PSV donor >1.5 MoM and MCA-PSV recipient <1.0 MoM, without other signs of fetal compromise
Stage 2: MCA-PSV donor >1.7 MoM and MCA-PSV recipient <0.8 MoM, without other signs of fetal compromise
Stage 3: stage 1 or 2, with cardiac compromise of donor (AREDF in UA, pulsatile flow in UV, increased PI or reversed flow in DV)
Stage 4: Hydrops of donor
Stage 5: IUD of one or both fetuses preceded by TAPS
Stage Intertwin Hb difference, g/dl
1 >8.0
2 >11.0
3 >14.0
4 >17.0
5 >20.0
PN staging
Slaghekke et al, Fetal Diagn Therap 2010 Lopriore et al, Prenat Diagn 2010
TAPS: Outcome
RECIPIENT
• Healthy (Hb discordance)
• Neonatal morbidity
• severe polycythemia
• Thrombocytopenia
• Ischemic limb necrosis
• Cerebral injury
• NND DONOR
• Healthy (Hb discordance)
• Neonatal morbidity
• Severe anemia
• Cerebral injury
• NND
Slaghekke et al, Fetal Diagn Therap 2010 Lopriore et al, Prenat Diagn 2010
TAPS: Management
Management options
• Expectant
• IOL
• IUT
• Selective feticide
• Fetoscopic laser
Lopriore et al, AJOG 2008 Herway et al, UOG 2009 Slaghekke et al, Fetal Diagn Ther 2010 Lopriore et al, Placenta 2007 Genova et al, Fetal Diagn Ther 2013
Slaghekke et al, UOG 2014 Lopriore et al, Prenat Diagn 2010
The Fetal Medicine Foundation
