FA4-MS02 Design and Properties of Functional Molecular Materials
25th European Crystallographic Meeting, ECM 25, İstanbul, 2009
Acta Cryst. (2009). A65, s 240 Page s 240
FA4-MS02-P01
Synthetic,
Structural
and
Luminiscence
Properties of a New Phosphorescent Cadmium
Chloride Network with 2-aminopyrimidine. Duane
Choquesillo-Lazarte
a, Juan Manuel García Ruiz
a,
Antonio Rodríguez-Diéguez
b, Enrique Colacio
b.
aLaboratorio de Estudios Cristalográficos,
IACT-CSIC.
bDepartamento de Química Inorgánica,
Universidad de Granada.
E-mail: duanec@ugr.es
In recent years the study on the self-assembly of organic and inorganic molecules in the solid state has become one of intense research activity [1] because it extends the range of new solids which can be designed to have particular physical and chemical properties. Hydro(solvo)thermal in situ metal/ ligand reactions, as a new bridge between coordination chemistry and organic synthetic chemistry [2], are of great interest for the discovery of novel coordination architectures and organic reactions.[3] Although in situ metal/ligand reactions have been extensively investigated for many decades, only a few kinds of organic ligand in situ reactions have been found under hydro(solvo)thermal conditions. The exploration of new in situ metal/ligand reactions has remained a challenge for researchers in both coordination and organic chemistry. We report the hydrothermal reaction of CdCl2 with 2-aminopyrimidine in water yielding one 2D metal-organic coordination framework [CdCl2(PymNH2)] (PymNH2 = 2-aminopyrimidine). This compound is a sheet coordination network, consisting of corner-sharing chains of Co2(μ-Cl)2 bridged by PymNH2 through ring nitrogen atoms. Additionally, this polymer exhibits strong phosphorescence at room temperature in the solid state. [1] R. Robson, B. E. Abrahams, S. R. Batten, R. W. Gable, B. F. Hoskins and J. Lieu, Supramolecular Architecture, ACS publications, Washington, DC, 1992. [2] A. Rodríguez-Diéguez and E. Colacio, Chem. Commun, 2006, 4140. [3] P. Vishweshwar, D. A. Beauchamp, M. J. Zaworotko, Cryst. Growth Des. 2006, 6, 2429.
Keywords: polymer structure; tetrazolate; luminiscence
FA4-MS02-P02
Structural and Magnetic Properties of Two Novel
Fe(III) Schiff Base Complex. Yasemin Yahsi
a, Hulya
Kara
a, Orhan Buyukgungor
b, Anastasia Iakovenko
c,
Lorenzo Sorace
c.
aBalıkesir University, Faculty of
Art and Science, Department of Physics, Balıkesir,
Turkey.
bOndokuz Mayıs University, Faculty of
Art and Science, Department of Physics, Samsun,
Turkey.
cDipartimento di Chimica and UdR INSTM,
Universita` di Firenze, Firenze, Italy.
E-mail: yahsi@balikesir.edu.tr
Two novel monomeric [C18H17Cl3N2O2Fe] (1) and dimeric [C38H36N4O4Cl6Fe2] (2) Fe(III) tetradentate schiff base complexes have been synthesized and their crystal structures have been determined by single crystal X-ray diffraction analysis. The compound 1 crystallizes in monoclinic space
group P21/c with a= 8.740, b= 15.469, c= 14.564 Å, β= 107.045° and the X-ray structure analysis of monomeric Fe(III) complex shows that the Schiff base ligand coordinates toward one iron atom in a tetradentate mode and each iron atom is five coordinated. This monomeric Fe(III) complex is such like a dimeric iron complex with the 2.89 Å non-bonding interatomic Fe…O distances and the coordination geometry around iron atom can be described as a distorted square pyramid. In compound 1 the equatorial sites are occupied by the N2O2 donor atoms
of the schiff base ligand, with average bond distances of Fe–N=2.081 and Fe–O=1.894 Å, and the apical chloride atom, with Fe–Cl=2.237 Å. The compound 2 crystallizes in triclinic space group P-1 with a=8.443, b=9.289, c= 12.600 Å, α= 82.085°, β= 79.107°, γ= 86.436° and the X-ray structure analysis of dimeric Fe(III) complex shows that the Schiff base ligand coordinates toward one iron atom in a tetradentate mode and each iron atom is six coordinated. The structure of 2 is a centrosymmetric dimer in which the iron (III) atoms are linked by µ-phenoxo bridges from one of the phenolic oxygen atoms of each Schiff base ligand to the opposite metal center and the two halves of the dimer are related by a crystallographic inversion center and the environment around each iron atom can be described as a distorted octahedral geometry. The variable-temperature (2–300 K) magnetic susceptibility (χ) data of the these two compounds have been investigated.
Keywords: magnetic properties; X-ray crystal structure analysis; iron complexes
FA4-MS02-P03
Use of [Fe(dithiooxalate)
2NO]
2-as a Molecular
Tecton in Crystal Engineering. Hulya Kara
a,
Christopher J. Adams
b, A. Guy Orpen
b.
aDepartment
of Physics, Balikesir University, Balikesir ,Turkey.
b
School of Chemistry, Department of Chemistry,
Bristol University, Bristol, UK.
E-mail: hkara@balikesir.edu.tr
A series of crystalline salts based on the [Fe(dto)2NO] 2-(dto = 1,2-dithiooxalate) dianion with hydrogen bond donor cations have been synthesised following a molecular tectonics approach. The chelating Fe(dto)∙∙∙HN supramolecular synthon has been exploited in a systematic study of its robustness. The effects of competition between hydrogen-bond acceptors, of the shape and functionality of the cations are discussed. The preparation and structural characterisation of the new crystalline phases [4,4′-H2bipy][Fe(dto)2NO][H2O] (1), [3,3′-H2bipy] [Fe(dto)2NO] (2), [H2Me4bipyz]2[Fe(dto)2NO][H2O]2 (3) (Me4bipyz = 3,3’,5,5’-tetramethyl-4,4’-bipyrazole) are reported. The charge-assisted NH∙∙∙dto synthon is formed in each of compounds 1–3. Cryomagnetic susceptibility measurements on these compounds from 3.6 K to room temperature indicated the operation of an antiferromagnetic interaction between Fe(III) atoms in each case. The best fit superexchange parameters are: J1= -12.47cm-1 for 1, J
2 =-15.20 cm-1 for 2, J
3= -11.34 cm-1 for 3 where H= -2JS1S2.
Keywords: iron complexes; magnetic properties; crystal engineering
