3D Brachytherapy Treatment in Locally Advanced Cervical
Cancer: A Case Presentation
Received: February 10, 2019 Accepted: February 19, 2019 Online: June 28, 2019 Accessible online at: www.onkder.org
Kamuran İBİŞ,1 Nazmiye DÖNMEZ KESEN2
1Department of Radiation Oncology, Istanbul University, Institute of Oncology, Istanbul-Turkey 2Department of Medical Physics, Istanbul University, Institute of Oncology, Istanbul-Turkey
SUMMARY
Cervical cancer is the most frequent gynecologic malignancy worldwide and is the fourth most common cancer among women. The treatment of locally advanced cervical cancer is concomitant radiochemother-apy. Intracavitary brachytherapy is used following concomitant external radiotherapy with cisplatin chemotherapy. Three-dimensional brachytherapy is currently the treatment of choice for cervical cancer. It was previously shown that high-dose rate (HDR) brachytherapy and low-dose rate brachytherapy have similar survival rates in cervical cancer. The advantages of HDR brachytherapy are possibility of treatment in outpatient basis, no radiation exposure for staff, advanced ability of controlling the immobilization of applicators, and better dose optimization. In this case report, the treatment planning of a patient with lo-cally advanced cervical cancer from Istanbul University Oncology Institute, with three-dimensional plan-ning and HDR intracavitary brachytherapy following chemoradiotherapy, is discussed.
Keywords: Brachytherapy; cervical cancer; radiotherapy. Copyright © 2019, Turkish Society for Radiation Oncology
Introduction
Cervical cancer is the most frequent gynecologic ma-lignancy worldwide and is the fourth most common cancer among women.[1] More than 90% of cervical tu-mors are squamous cell carcinomas, whereas 7%–10% of tumors are adenocarcinomas. Magnetic resonance imaging (MRI) is used for the initial evaluation, as well as for the evaluation, of extracervical spread of the tumor.[2] MRI is also useful for brachytherapy treat-ment planning and precise target volume definition. [3] 2-[18F]-fluoro-2-deoxy-D-glucose (FDG) positron emission tomography (PET)–computed tomography (CT) is increasingly used for the determination of treatment response in addition to diagnosis.[4,5]
The Federation Internationale de Gynecologie et d’Obstetrique (FIGO) staging system was based
prin-cipally on clinical examination. It was revised in 2018 by the FIGO Gynecologic Oncology Committee, and imaging and pathological findings were added if avail-able.[6] Radiological imaging, especially MRI and PET–CT scanning, occurred for staging near treat-ment planning and response evaluation. Patients with locally advanced cervical cancer (stages IB2 to IVA) are treated with brachytherapy following external radio-therapy (RT) combined with chemoradio-therapy (cisplatin). We present a case with cervical cancer treated with brachytherapy following concomitant radiochemother-apy in the Department of Radiation Oncology of the Institute of Oncology at Istanbul University.
Case Report
A 71-year-old woman suffering from vaginal hemor-rhage for 2 months was admitted to our clinic. The
pa-Dr. Kamuran İBİŞ İstanbul Üniversitesi, Onkoloji Enstitüsü, Radyasyon Onkolojisi, İstanbul-Turkey E-mail: kamuranibis@gmail.com
evaluation of the biopsy obtained from gynecologic on-cology revealed squamous cell carcinoma of the cervix. Bimanual rectovaginal examination prior to the treat-ment detected eroded cervix by endophytic cervical tumor and left parametrial invasion. Abdominopelvic MRI showed a 73×65 mm sized cervical tumor that in-vaded the left parametrium (Fig. 1). Pretreatment PET– CT evaluation revealed a 54×55 mm sized mass with increased FDG uptake in the cervical region (Fig. 2). Intracavitary brachytherapy following external pelvic RT with concomitant chemotherapy was planned for the patient classified as stage IIB according to the FIGO 2018 staging system. The patient received 50 Gy/25 Fr external RT (three-dimensional conformal radiation
therapy), and concomitant cisplatin of 40 mg/m2 was
also delivered. Bimanual rectovaginal examination fol-lowing external beam RT revealed dramatic regression of cervical lesion and only mild left parametrial inva-sion. Abdominopelvic MRI prior to brachytherapy tients’ medical history, as well as her family history, was
unremarkable. The ages of menarche and menopause were 14 and 35 years, respectively. The histopathological
Fig. 1. Abdominopelvic MRI (T2-weighted images)
prior to treatment. (a) Sagittal and (b) transverse images.
a b
Fig. 2. PET–CT images prior to treatment. (a) Sagittal and (b) transverse images.
a
showed complete response of the cervical lesion (Fig. 3). The patient was prepared for general anesthesia before brachytherapy. She was examined under general anes-thesia. Urinary catheter was inserted, and silver seed
was also placed into the cervix. The most suitable appli-cators were selected for the patient. Thereafter, a 26 mm diameter ring applicator was placed following insertion of a 4 cm length tandem. Anteroposterior and lateral radiographs were obtained via C-arm X-ray machine. The patient was scanned with a 2 mm slice thickness by Philips Brilliance Big Bore 4D CT machine. Images from CT scan were imported into the brachytherapy planning system (Oncentra version 4.0; Nucletron, Veenendaal, Netherlands). Then, CT images were con-toured for high-risk clinical target volume (HR-CTV) and organs at risk (bladder, rectum, and sigmoid) using the Groupe Européen de Curiethérapie–European Soci-ety for Therapeutic Radiation Oncology (GEC-ESTRO) guidelines (Fig. 4).
At the beginning of brachytherapy treatment plan-ning, catheter reconstruction was done directly on CT to determine the path for the source to track in each catheter. The offset and indexer values of the applica-tors were entered into the planning system (−7 mm and −6 mm offset values for ring and tandem appli-cators, respectively; 1500 mm indexer value for each applicator). Figure 5 shows the catheter reconstruction on CT images for different planes.
In the planning system, ensure that each catheter has the same number as the device channel num-ber. After catheter reconstruction, the normalization process was performed. Target volume was selected for normalization point. Plan was normalized such that 90% of the target volume received the prescribed dose.
The source dwell positions were automatically gen-erated by providing a 1–2 mm margin to the target volume. After autoactivation of the source dwell posi-tions, the dose distribution was controlled in each CT cross-section. The source dwell positions were created manually by using the Forward Optimization Method (FOM) to achieve optimal target coverage with less critical organ doses. FOM is one of the treatment plan optimization methods in which treatment plans are generated manually. In this method, dwell positions Fig. 3. Abdominopelvic MRI (T2-weighted images)
fol-lowing external radiotherapy. (a) Sagittal and (b) transverse images.
a b
Fig. 4. Target volume and critical organ volumes in axial,
coronal, and sagittal planes.
Fig. 5. Catheter reconstruction view from (a) transverse, (b) coronal, and (c) sagittal images.
and dwell times are changed manually until the desired dose distribution on the target volume is achieved without exceeding the critical organ dose limits.[7]
The prescribed dose was obtained by using biolog-ical equivalent dose models. The dose prescribed that 90% of the target volume received 5.5 Gy per fraction, and that the plan was performed in five fractions. Graphical dose optimization was conducted by chang-ing the isodoses manually to maximize target volume conformality and minimize critical organ doses (Fig. 6). This process continues until the appropriate dose distribution is achieved by controlling the dose vol-ume histogram (DVH). DVH of the treatment plan is shown in Figure 7. Great care was taken to retain the target volume of the cold dose regions and the hot dose regions in the rectum, bladder, and sigmoid and 2 cc, 1 cc, and 0.1 cc volumes within the specified limits.
The gynecologic examination 2 months after treat-ment was found to be normal. Month 3 MRI scan and also month 6 PET–CT scan showed complete response.
The patient remains disease-free for 4 years following the initial treatment.
Discussion
Brachytherapy following concomitant radiochemother-apy is the standard treatment in locally advanced can-cer of the can-cervix. Treatment planning of brachytherapy through three-dimensional imaging accurately defines the tumor and aids with the accuracy of irradiation dose delivery that may also reduce normal tissue doses and toxicity.[8] The GEC-ESTRO guidelines [9,10] de-scribe volumes for MR-based contouring. The American Brachytherapy Society organized a study about the use of image-based brachytherapy in 2007 [11] and updated it in 2014. A panel of radiation oncologists specializing in gynecologic oncology established a contouring atlas to delineate the CTV in locally advanced cancer of the cervix with a high consensus rate. Patients with parame-trial extension mostly gained advantage from MRI scan-ning with respect to delicate brachytherapy planscan-ning. [12] The atlas is available online at www.nrgoncology.org. It is recommended that 90% of HR-CTV dose-planning within the EQD2 limits (EQD2 ≥80 Gy) for D2cc should be 90 Gy for the bladder and 70–75 Gy for the rectum and sigmoid colon. The fraction doses of brachytherapy were also determined according to the BED and EQD2 dose calculations in our treatment planning. The GEC-ESTRO guidelines delineated 3D planning volumes in brachytherapy in 2005 and determined the tumor and whole cervix tissue as HR-CTV while brachytherapy and recommended total delivery of the prescribed dose to HR-CTV. Intermediate risk CTV (IR-CTV) was de-fined as a 1 cm margin around HR-CTV+ initial sites of involvement.[9] It is used less frequently than HR-CTV in the USA. HR-CTV does not contain endometrium and vagina unless an obvious residual disease initially. Eifel and Klopp believed that regression of the vaginal Fig. 6. Treatment plan dose distributions in (a) transverse, (b) coronal, and (c) sagittal planes.
a b c
Fig. 7. Dose volume histogram of the brachytherapy
or myometrial infiltration area toward the cervix is un-likely in contrast to paracervical tumors. Therefore, they suggested including the initial site of disease into the HR-CTV especially if it is not used in IR-CTV treatment planning.[13] The IR-CTV was not used in our clinic. We routinely include the initial site of disease into the HR-CTV if uterus and/or vaginal extension are present at the initial evaluation. Although it is possible to per-form adaptive brachytherapy using simulation CT scan at the beginning of each fraction of brachytherapy, it is not a very practical approach in daily routine in most RT clinics. Similar to the presented case, we normally per-form the remaining fractions in patients with complete response if the organ at risk doses are acceptable, after placing the seed into the cervix, and confirming the po-sitions of applicators with the aid of anteroposterior and lateral radiographs. We prefer scanning with simulation CT for each brachytherapy application if there is residual tumor or need for re-check of organ at risk doses.
Conclusion
Brachytherapy is an important treatment modality in locally advanced cervical cancer. 3D brachytherapy pro-vides high local control rates with maximum protection of the organs under risk in the course of irradiation. Informed consent: The patient allowed the use of medical
data and images for the publication as a case report.
Peer-review: Externally peer-reviewed.
Conflict of Interest: The authors declare that they have no
conflict of interest.
Authorship contributions: Concept – K.İ.; Design – K.İ.,
N.D.K.; Supervision – K.İ.; Materials – K.İ., N.D.K.; Data collection &/or processing – K.İ., N.D.K.; Analysis and/or interpretation – K.İ.; Literature search – K.İ.; Writing – K.İ., N.D.K.; Critical review – K.İ.
