91
and Safe Treatment Modality for Intermediate
Risk/Submassive Pulmonary Embolism
Caglar Ozmen,
1MD, Ali Deniz,
1MD, Rabia Eker Akilli,
1MD, Onur Sinan Deveci,
1MD,
Caglar Emre Cagliyan,
1MD, Halil Aktas,
1MD, Aziz İnan Celik,
1MD, Ayca Acikalin Akpinar,
2MD,
Nezihat Rana Disel,
2MD, Hüseyin Tugsan Balli,
3MD, İsmail Hanta,
4MD,
Mesut Demir,
1MD, Ayhan Usal,
1MD, and Mehmet Kanadasi,
1MD
Summary
Pulmonary embolism (PE) is a potentially life-threatening condition and the fact that 90% of PE originate from lower limb veins highlights the significance of early detection and treatment of deep vein thrombosis.1) Massive/high risk PE involving circulatory collapse or systemic arterial hypotension is associated with an early mortality rate of approxi-mately 50%, in part from right ventricular (RV) failure.2) Intermediate risk/submassive PE, on the other hand, is defined as PE-related RV dysfunction, troponin and/or B-type natriuretic peptide elevation despite normal arterial pressure.3) Without prompt treatment, patients with intermediate risk PE may progress to the massive category with a potentially fa-tal outcome. In patients with PE and right ventricular dysfunction (RVD), in hospifa-tal morfa-tality ranges from 5% to 17%, significantly higher than in patients without RVD.4,5) (Int Heart J 2016; 57: 91-95)
Key words: Right ventricular dysfunction, Circulatory collapse, Hypotension
I
n patients with massive PE, systemic thrombolysis hasbeen demonstrated to reduce mortality rates.6) Patients with high-risk PE and a low risk of bleeding should re-ceive thrombolysis, as may patients with intermediate risk PE.7) In comparison to anticoagulation alone, systemic throm-bolysis can reverse RV dilatation within 24 hours of treat-ment.8,9) Despite these effects, thrombolytic therapy is associat-ed with a higher incidence of major bleassociat-eding complications defined as intracranial or retroperitoneal hemorrhage or bleed-ing leadbleed-ing directly to death, hospitalization, or transfusion.10,11) Ultrasound-accelerated thrombolysis (USAT) using the
EkoSonic® Endovascular System (EKOS corporation; Bothell;
WA) uses low-intensity, high-frequency ultrasound that disso-ciates fibrin strands without causing thrombus fragmentation. The acoustic energy enhances thrombolytic penetration into the thrombus, and increases thrombus surface area exposed to lytic drug.12) This method enhances dissolution of more organ-ized thrombus.
There is a need for effective treatment alternatives for acute PE that facilitate the reversal of RVD without causing an excess in systemic bleeding complications. The purpose of this study was to evaluate the results of clinical efficacy and safety of USAT in patients with intermediate risk PE, retrospectively.
Methods
Patients: The study population was composed of patients who
underwent USAT at Cukurova University Faculty of Medicine between October 2012 and August 2013. Ten intermediate risk PE patients were included in the study. The clinical records of all patients were reviewed and clinical data were recorded. We used recombinant tissue plasminogen activator (rt-PA) as a thrombolytic agent for this procedure. Intermediate risk PE pa-tients were treated with this therapy if they fulfilled all of the following criteria: a) dyspnea, hypoxia with no hemodynamic instability, b) evidence of PE by multi-detector contrast-en-hanced computed tomography (CT), and c) RVD found from transthoracic echocardiography defined as the case that had shown any of the following 3 findings; 1) The ratio of the right ventricular end-diastolic diameter to the left ventricular end-di-astolic diameter is ≥ 0.9; 2) wall motion abnormality of right ventricle; and 3) tricuspid regurgitation jet velocity (TRV) ≥ 2.8 m/sec.13) Patients with any contraindications to thrombolytic therapy according to the European Society of Cardiology (ESC) guidelines regarding acute PE did not undergo USAT.14) Written informed consent was obtained in all patients prior to the procedure. This study was approved by the local Institu-tional Review Board (2013/26-7).
EkoSonic device: The EkoSonic® system includes a
multiple-lumen infusion catheter with a removable coaxial ultrasound
From the Departments of 1 Cardiology, 2 Emergency Medicine, 3 Radiology, and 4 Chest Diseases, Cukurova University, Faculty of Medicine, Adana, Turkey.
Address for correspondence: Caglar Ozmen, MD, Department of Cardiology, Cukurova University, Faculty of Medicine, 01330, Balcali, Saricam, Adana, Turkey. E-mail: caglarozm@hotmail.com
Received for publication July 7, 2015. Revised and accepted July 9, 2015. Released in advance online on J-STAGE December 17, 2015. All rights reserved by the International Heart Journal Association.
core wire containing a series of miniature ultrasound transduc-ers, which are connected to a control unit that delivers low-in-tensity ultrasound with concomitant thrombolytic drug infu-sion into the thrombus. A 5.2 Fr multilumen side port infuinfu-sion catheter, with infusion lengths of 6 to 50 cm, accommodates the coaxial 0.035-inch ultrasound core wire. The system deliv-ers ultrasound energy (2.2 MHz) radially along the coaxial in-fusion zone with simultaneous rt-PA inin-fusion. The control unit continuously monitors variables, including temperature and ul-trasound energy power output in the treatment zone, by means of thermocouples incorporated into the catheter, and automati-cally adjusts delivered ultrasound power to optimize thrombol-ysis. The acoustic streaming energy dissociates the fibrin and increases the fibrin porosity without causing distal emboliza-tion, which also facilitates the penetration of thrombolytic agent into the thrombus for receptor binding.
Treatment regimen: All patients received unfractionated
heparin using a standard weight-based algorithm and doses were adjusted according to the activated partial thromboplastin time prior to, during, and after USAT treatment. The placement of the EkoSonic Endovascular System was performed in the cardiac catheterization laboratory. Venous access was obtained via the common femoral vein using a micropuncture needle and 6 Fr introducer sheath. Following placement of the intro-ducer sheath, a 260 cm, 0.035-inch guidewire and 6 Fr pigtail catheter were advanced into the desired location in the PA and then pulmonary arteriograms were obtained. Once the location of a pulmonary arterial thrombus was identified, the pigtail catheter was then removed and the EkoSonic infusion catheter was advanced over the guidewire until the distal catheter tip was positioned at the distal edge of the thrombus under fluor-oscopy. In case of bilateral PE, an EkoSonic® catheter was in-troduced into the PA containing higher thrombus load. After fi-nal positioning, the guidewire was then removed and replaced by the ultrasound core wire (endowave catheter) which was connected to the control unit for ultrasound energy transmis-sion. Continuous infusion of thrombolytic was initiated through the drug lumen of the infusion catheter, and ultrasound energy was delivered with simultaneous infusion of the throm-bolytic drug. Normal saline was continuously infused through a central lumen (60–70 mL/hour) to provide baseline cooling in the endowave catheter. Thrombolysis was performed using rt-PA. Patients were transported to the coronary care unit. Pa-tients received rt-PA and ultrasound for 12 hours. Follow-up echcardiography and CT scan were performed 2 days after the completion of treatment. Follow-up pulmonary angiography was performed in the following days. All patients were placed on long-term oral warfarin therapy.
Pulmonary angiography: An interventionalist analyzed the
preintervention and postintervention pulmonary angiography for evidence of thrombus removal according to the Miller score.15) Preinterventional and postinterventional pulmonary arterial pressures were also recorded during pulmonary angi-ography.
Computed tomography analysis: CT examinations were
per-formed on an Asteon S4 (Toshiba Medical Systems, Tokyo). Preinterventional and postinterventional CT angiography im-ages were read by an experienced observer in examining tho-racic CT scans. The RV diameter was measured on the trans-verse section that showed the tricuspid valve at its widest. The RV diameter was measured from the inner wall to the inner
wall at the widest point in the chamber, which was typically in the basal third of the RV. The LV diameter was measured on the transverse image that showed the mitral valve at its widest and, like the diameter of the RV, was measured from the inner wall to the inner wall at the widest portion of the LV. The right-to-left ventricular dimension ratio (RV/LV ratio) was then
cal-culated.16) For evidence of thrombus removal, the Qanadli
score was used.17) Preinterventional and postinterventional Qa-nadli scores were calculated for each patient.
Echocardiographic analysis: Transthoracic (TTE)
echocardi-ography was performed with the Vivid S5 cardiovascular ultra-sound system (3S 1.5-3.6 MHz probe for transthoracic GE Medical Systems, Buckinghamshire, UK). Preinterventional and postinterventional standard color 2-dimensional echcardio-graphic Doppler examinations were performed by experienced echocardiographers. The end-diastolic dimensions of the right and left ventricles were measured in the apical 4-chamber views from the septal endocardial border to the lateral wall en-docardial border at their widest point just above the mitral valve and tricuspid valve annulus. Also, the end-diastolic di-mensions of the right and left ventricles were measured in the parasternal long axis view. The RV/LV ratio was then deter-mined for each view. Tricuspid annular plane systolic excur-sion (TAPSE) was measured by M-mode recordings from the apical 4-chamber view, with the cursor placed at the free wall of the tricuspid annulus. From the apical 4-chamber view, the transtricuspid gradient derived from tricuspid regurgitation jet velocity (TRV) was measured. The RV outflow tract velocity integral (RVOT VTI) was recorded from the parasternal short axis view at the aortic valve level with the pulsed-wave (PW) Doppler sample volume positioned in the center of the RV out-flow tract just proximal to the pulmonary valve. The area under the velocity curve was traced. Pulmonary acceleration time (PAT) was measured from the parasternal short-axis view with the PW Doppler sample volume placed at the annulus of the pulmonary valve. PAT was defined as the interval between the onset of systolic pulmonary arterial flow and peak flow veloci-ty.
Statistical analysis: Statistical analysis was performed using
the statistical package SPSS v 17.0. For each continuous varia-ble, normality was checked by the Kolmogorov Smirnov and Shapiro-Wilk tests and by histograms. Comparisons of pre and post operation days were conducted using the Wilcoxon test and the Friedman test was used for data that was not normally distributed. Line plots were obtained using Microsoft Excel. Values of P < 0.05 were considered statistically significant.
Results
Demographics and procedural details: Mean age was 53.2 ±
14.1 years and 60% of patients were male. All patients had a symptom duration of less than 14 days and were at intermedi-ate risk (normotensive, RV dysfunction or dilatation). On CT, PE with a median Qanadli score of 19 (18-27) was detected in all patients. Baseline median RV end diastolic diameter was 41 (36-52) mm and the baseline median RV/LV ratio was 1.26 (0.76-1.84) on CT. On echocardiography the RV/LV ratio in the 4-chamber view was 0.99 (0.71-1.22) with a median TRV of 3.35 (2.8-4.1) m/s. All patients underwent pulmonary angi-ography. The median of mean pulmonary artery pressure (PAP)
was 34 (22-50) mmHg during catheterization. USAT were per-formed successfully in all patients. Overall, we used rt-PA 0.05 mg/kg/hour for each patient. The mean rt-PA dose was 31.7 mg ± 3.22 and infusion time was 12 hours. The EkoSonic de-vice was removed quickly when the infusion was completed. The rt-PA infusion time was considered to be 12 hours for all patients as there was no bleeding complication during this pe-riod.
Endpoint analyses: We performed follow-up
echocardiogra-phy in all patients 2 days and 6 months later in the follow-up, except for the patient who died on the 13th day of hospitaliza-tion. Baseline characteristics of the patients are presented in Supplemental Table I, and laboratory data and symptoms are presented in Supplemental Table II. Preintervention, postinter-vention, and 6 month follow-up variables are shown in Supple-mental Table III. Echocardiographic parameters showing RV dysfunction significantly improved after treatment and this sig-nificant difference was maintained during the 6 months of fol-low-up. The RV/LV ratio in the 4-chamber view decreased from 0.99 (0.71-1.22) to 0.82 (0.55-0.93) after treatment and to 0.73 (0.54-0.88) 6 months later (P = 0.005, P < 0.001, respec-tively) (Supplemental Figure 1A). TRV decreased from 3.35 (2.8-4.1) m/s to 2.50 (2.1-3.8) m/s after treatment and to 2.20 (2.0-2.7) m/s 6 months later (P = 0.004, P < 0.001, respective-ly). Pulmonary acceleration time increased from 86 (66-112) ms to 113 (76-135) ms after treatment and to 133 (110-147) ms 6 months later (P = 0.008, P < 0.001, respectively). TAPSE increased from 14 (12-21) mm to 21 (15-34) mm after treat-ment and to 24 (13-34) mm 6 months later (P = 0.005, P = 0.001 respectively).
Follow-up CT angiography was performed in all patients after 2 days of USAT treatment. The RV/LV ratio decreased from 1.26 (0.76-1.84) to 0.91 (0.62-1.10) at follow-up (P = 0.005) (Supplemental Figure 1B). The median RV end diastol-ic diameter was reduced from 41 (36-52) mm to 34 (29-41) mm (P = 0.005). The Qanadli score was significantly reduced from 19 (18-27) to 11 (3-15) (P = 0.005).
We performed follow-up pulmonary angiography in all patients after the USAT procedure. The pre- and postinterven-tional pulmonary angiography results are shown in Supple-mental Figure 2 and SuppleSupple-mental Figure 3. PA systolic and mean pressures decreased significantly from the baseline val-ues of 49 (31-80) and 34 (22-50) mmHg, to 29 (14-63) and 6 (2-27) mmHg, respectively. (P = 0.005 for each) (Supplemen-tal Figure 1C). The Miller score was significantly reduced from 21 (13-28) to 8 (4-16) (P = 0.005).
Clinical outcomes: All patients except one survived to hospital
discharge with an average hospital stay of 9 ± 4 days (range, 4–16 days; median 6 days). This patient had been hospitalized in the ICU due to organophosphate intoxication, and PE was detected on the 6th day of her hospital stay. Seven days after USAT she died of liver failure. The average duration of stay in the intensive care unit was 3 days (median, 2 days). We sus-pected no recurrent PE during the hospital stay of the patients. No minor or major bleeding complications were observed.
Discussion
In the present study, we observed that catheter-directed USAT treatment resulted in a reduced thrombolytic dose,
re-versed RV dilatation, improved RV dysfunction, and decreased pulmonary clot burden and PA pressures in intermediate risk PE patients. İn addition no bleeding event was reported.
Current ESC guidelines support the use of thrombolysis in the management of intermediate risk PE patients without an elevated risk of bleeding.18) In randomized trials and clinical practice, systemic PE thrombolysis is associated with high bleeding risk.18,19) Anticoagulation with heparin is a widely used therapy in intermediate risk PE patients, but this treatment does not remove thrombus burden or restore vascular flow. In the ULTrasound Accelerated Thrombolysis of Pulmonary Em-bolism (ULTIMA) trial, a randomized, prospective, controlled study of PE patients at intermediate risk of death, catheter-di-rected USAT was superior to anticoagulation with heparin alone in reversing RV dilatation and dysfunction at 24 hours, without an increase in bleeding complications.20) In their trial, USAT reduced the RV/LV ratio from 1.28 at baseline to 0.99 over 24 hours, which was comparable to the effect seen with tenecteplase in the TIPES trial.21) The control group in the UL-TIMA study received unfractionated heparin without throm-bolysis, and there was no significant reversal of right ventricu-lar dilatation with an RV/LV ratio of 1.20 at baseline and 1.17 at 24 hours (RV/LV ratio mean absolute reduction 0.03). In our study, USAT reduced the RV/LV ratio from 0.99 (0.71-1.22) to 0.82 (0.55-0.93) on echocardiography and from 1.26 (0.76-1.84) to 0.91 (0.62-1.10) on CT at two days. RV dysfunction is known to be associated with adverse prognosis in PE pa-tients.22) We also examined the alteration in other parameters related to RV dysfunction on echocardiography and long-term follow-up as RV echocardiography provides valuable informa-tion about chronic thromboembolic pulmonary hypertension.23) After the procedure and at 6th months of follow-up, we found improvements in TRV, PAT, and TAPSE.
In the ULTIMA trial there were significant reductions in systolic, diastolic, and mean PAP measured invasively. In our study, systolic, mean, and diastolic PA pressures all decreased like in the ULTIMA trial. In the ULTIMA trial, rtPA was used up to 20 mg over 15 hours during the USAT procedure, and no significant increase in bleeding complications was reported compared to heparin. In our study, we used 31.7 mg rt-PA over 12 hours. During the USAT procedure we did not observe any bleeding complications. In the ULTIMA trial, the significant decrease in the RV/LV ratio at 90 days follow-up was main-tained (from 1.28 to 0.95). Also in our study, the difference be-tween the basal and 6 month follow-up RV/LV ratio remained significant. Although the ULTIMA study and our study dem-onstrated a hemodynamic benefit from USAT therapy, further studies are warranted to determine whether this benefit trans-lates into improved clinical outcomes. All patients except one were discharged alive in our study. Treatment success as evi-dence of thrombus removal was also examined using the Qa-nadli and Miller scoring systems.15,17) We observed a reduction of the Miller score from 21 (13-28) to 8 (4-16) and the Qanadli score from 19 (18-27) to 11 (3-15).
One of our patients who died of organophosphate intoxi-cation did not reflect the reduced clinical efficacy of USAT since she did not die due to PE. Related complications of inter-ventional therapy for PE such as dissection, pericardial tam-ponade, pulmonary hemorrhage, distal embolization, arrhyth-mia, contrast nephropathy, anaphylaxis, hemorrhage and groin
ob-served in our study.
Ultrasound exposure does not cause mechanical fragmen-tation of the clot, however, it does increase the flow rate through thrombi, probably by disaggregation of uncrosslinked fibrin fibers into smaller fibers. This results in increased trans-port of the lytic agent into the clot, alteration of binding affini-ty, and increased maximum binding.25) Thereby, USAT reduces the amount of drug required for thrombolysis.
The EkoSonic® system has been studied in the treatment of patients with stroke,26) peripheral arterial occlusion,27) DVT,28) and PE.29-31) Chamsuddin, et al 29) concluded that USAT was an effective method for treating massive thrombolysis in their study of 10 acute massive PE patients. They emphasized the thrombolytic dose lowering effect of USAT. Lin, et al 30) compared USAT with catheter directed thrombolysis (CDT) in their retrospective study of 25 patients with massive PE. They suggested that USAT provides a lower thrombolytic dosage, reduced thrombolytic infusion time, and fewer treatment relat-ed complications and higher treatment efficacy in terms of thrombus removal compared to non-ultrasound assisted cathe-ter directed thrombolysis. Engelhardt, et al 31) performed a ret-rospective analysis of 24 intermediate and high risk PE pa-tients. They reported that low-dose USAT rapidly reverses RV dilatation and pulmonary clot burden.
There are some limitations in our study. It was retrospec-tive and without a control group, and in addition, the limited length of follow-up and small number of patients indicate the findings should be interpreted cautiously.
In conclusion, USAT improved RV dysfunction, de-creased clot burden, and caused no bleeding complications in intermediate risk PE patients. USAT therapy may be a safe and effective treatment option for intermediate risk PE patients. Additional prospective, randomized clinical studies are neces-sary to validate our results with this USAT therapy in acute PE patients.
Disclosure
Conflicts of interest: The authors declare that there is no
con-flict of interest.
References
1. Nitta D, Mitani H, Ishimura R, et al. Deep vein thrombosis risk stratification. Int Heart J 2013; 54: 166-70.
2. Goldhaber SZ, Visani L, De Rosa M. Acute pulmonary embolism: clinical outcomes in the International Cooperative Pulmonary Em-bolism Registry (ICOPER). Lancet 1999; 353: 1386-9.
3. Ohigashi H, Haraguchi G, Yoshikawa S, et al. Comparison of bi-omarkers for predicting disease severity and long-term respiratory prognosis in patients with acute pulmonary embolism. Int Heart J 2010; 51: 416-20.
4. Dalen JE, Alpert JS. Natural history of pulmonary embolism. Prog Cardiovasc Dis 1975; 17: 259-70. (Review)
5. Dalen JE. Pulmonary embolism: what have we learned since Vir-chow? Natural history, pathophysiology, and diagnosis. Chest 2002; 122: 1440-56. (Review)
6. Konstantinides S, Geibel A, Olschewski M, et al. Association be-tween thrombolytic treatment and the prognosis of hemodynami-cally stable patients with major pulmonary embolism: results of a multicenter registry. Circulation 1997; 96: 882-8.
7. Horlander KT, Mannino DM, Leeper KV. Pulmonary embolism mortality in the United States, 1979-1998: an analysis using multi-ple-cause mortality data. Arch Intern Med 2003; 163: 1711-7. 8. Becattini C, Agnelli G, Salvi A, et al; TIPES Study Group. Bolus
tenecteplase for right ventricle dysfunction in hemodynamically stable patients with pulmonary embolism. Thromb Res 2010; 125: e82-6.
9. Konstantinides S, Tiede N, Geibel A, Olschewski M, Just H, Kasper W. Comparison of alteplase versus heparin for resolution of major pulmonary embolism. Am J Cardiol 1998; 82: 966-70. 10. Konstantinides S, Geibel A, Heusel G, et al; Management
Strate-gies and Prognosis of Pulmonary Embolism-3 Trial Investigators. Heparin plus alteplase compared with heparin alone in patients with submassive pulmonary embolism. N Engl J Med 2002; 347: 1143-50.
11. Thabut G, Thabut D, Myers RP, Bernard-Chabert B, Marrash-Chahla R, Mal H, Fournier M. Thrombolytic therapy of pulmo-nary embolism: a meta-analysis. J Am Coll Cardiol 2002; 40: 1660-7.
12. Sharafuddin MJ, Hicks ME, Jenson ML, Morris JE, Drasler WJ, Wilson GJ. Rheolytic thrombectomy with use of the AngioJet-F105 catheter: preclinical evaluation of safety. J Vasc Interv Radiol 1997; 8: 939-45.
13. Piazza G, Goldhaber SZ. Management of submassive pulmonary embolism. Circulation 2010; 122: 1124-9.
14. Torbicki A, Perrier A, Konstantinides S, et al. Guidelines on the diagnosis and management of acute pulmonary embolism: the Task Force for the Diagnosis and Management of Acute Pulmo-nary Embolism of the European Society of Cardiology (ESC). Euro Heart J 2008: 29: 2276-315.
15. Miller GA, Sutton GC, Kerr IH, Gibson RV, Honey M. Compari-son of streptokinase and heparin in treatment of isolated acute massive pulmonary embolism. Br Med J 1971; 2: 681-4. 16. Reid JH, Murchison JT. Acute right ventricular dilatation: a new
helical CT sign of massive pulmonary embolism. Clin Radiol 1998; 53: 694-8.
17. Qanadli SD, El Hajjam M, Vieillard-Baron A, et al. New CT index to quantify arterial obstruction in pulmonary embolism: compari-son with angiographic index and echocardiography. AJR Am J Roentgenol 2001; 176: 1415-20.
18. Fiumara K, Kucher N, Fanikos J, Goldhaber SZ. Predictors of ma-jor hemorrhage following fibrinolysis for acute pulmonary embo-lism. Am J Cardiol 2006; 1: 97: 127-9.
19. Dalla-Volta S, Palla A, Santolicandro A, et al. PAIMS 2: alteplase combined with heparin versus heparin in the treatment of acute pulmonary embolism. Plasminogen activator Italian multicenter study 2. J Am Coll Cardiol 1992; 20: 520-6.
20. Kucher N. The ULTIMA Trial. 62nd Annual Scientific Session of the American College of Cardiology (ACC.13) Available at: http:// www.acc.org/education-and-meetings/image-and-slide-gallery/ media-detail?id=2c7c4fba064845c3b7ace6cebb012150 Accessed October 23, 2015.
21. Becattini C, Agnelli G, Salvi A, et al. Bolus tenecteplase for right ventricle dysfunction in hemodynamically stable patients with pulmonary embolism. Thromb Res 2010; 125: e82-6.
22. Konstantinides S. Pulmonary embolism: impact of right ventricu-lar dysfunction. Curr Opin Cardiol 2005; 20: 496-501. (Review) 23. Shiino K, Sugimoto K, Yamada A, et al. Usefulness of right
ven-tricular basal free wall strain by two-dimensional speckle tracking echocardiography in patients with chronic thromboembolic pul-monary hypertension. Int Heart J 2015; 56: 100-4.
24. Uflacker R. Interventional therapy for pulmonary embolism. J Vasc Interv Radiol 2001; 12: 147-64. (Review)
25. Harpaz D. Ultrasound enhancement of thrombolytic therapy: ob-servations and mechanisms. Int J Cardiovasc Intervent 2000; 3: 81-9.
26. IMS II Trial Investigators. The Interventional Management of Stroke (IMS) II Study. Stroke 2007; 38: 2127-35.
27. Wissgott C, Richter A, Kamusella P, Steinkamp HJ. Treatment of critical limb ischemia using ultrasound-enhanced thrombolysis
(PARES Trial): final results. J Endovasc Ther 2007; 14: 438-43. 28. Parikh S, Motarjeme A, McNamara T, et al.
Ultrasound-accelerat-ed thrombolysis for the treatment of deep vein thrombosis: initial clinical experience. J Vasc Interv Radiol 2008; 19: 521-8. 29. Chamsuddin A, Nazzal L, Kang B, et al. Catheter-directed
throm-bolysis with the Endowave system in the treatment of acute mas-sive pulmonary embolism: a retrospective multicenter case series. J Vasc Interv Radiol 2008; 19: 372-6.
30. Lin PH, Annambhotla S, Bechara CF, et al. Comparison of percu-taneous ultrasound-accelerated thrombolysis versus catheter-di-rected thrombolysis in patients with acute massive pulmonary em-bolism. Vascular 2009; 17: S137-47.
31. Engelhardt TC, Taylor AJ, Simprini LA, Kucher N. Catheter-di-rected ultrasound-accelerated thrombolysis for the treatment of acute pulmonary embolism. Thromb Res 2011; 128: 149-54.
