High-speed internet in just a few steps.
Radio TV/STB DATA
A) B)
High-speed for your home
Sign up to our service portal – MeinVodafone
Look forward to exciting information and interesting news about your internet connection.
Go to MeinVodafone here:
vodafone.de/meinvodafone
Similar to figure
1
What does your cable socket looks like?
Your cable socket has 4 or 3 connections (figure A) or 2 connec- tions (figure B). If the socket has 2 connections, screw or plug the multimedia socket adapter on it.
2
Connecting your cable router
2a Plug the connecting cable on the DATA port of your cable socket or of the multimedia socket adapter and the other end into your cable router.
2b Plug the power cable into your cable router and the power adapter into the electric socket. If your cable router has a rocker switch, put it on I. Wait until the Power and the Internet LEDs light up continuously. This can take up to 15 minutes. Please continue only after that.
Multimedia socket adapter
3a Via LAN
First, check whether LAN is activated on your device. Connect your computer with your cable router via network cable.
3b Via Wi-Fi through WPS
First, check whether your device supports WPS. Hold down the WPS button on your cable router until the WPS LED flashes.
Then, activate WPS within 2 minutes on the device you wish to connect with your cable router.
3
Connecting devices
Manually via Wi-Fi
You will find pre-set access data on your cable router:
WLAN-Name (SSID) and WLAN-Passwort. Open the menu for Wi-Fi settings on the device that you wish to connect.
Select your network (SSID) and enter the WLAN-Passwort.
4
Connecting your telephone (optional)
You can connect your telephone directly to your cable router.
Please use the port TEL 1 for this. It can take up to 10 minutes for your telephone to be activated.
To change settings on your cable router, enter http://192.168.0.1 in your internet browser. You will find the Kennwort on your cable router and on the supplied card.
WLAN-Name: Vodafone-XXXXXX XXXXXXXXXXXXXX
WLAN-Passwort: WLAN-Passwort
WLAN-Name
Install your cable router now. It’s very easy with these instructions.
Do you prefer to install with video or digital step-by-step instructions? You will find these here:
Have fun with GigaNetz by Vodafone.
Welcome to Vodafone
Overview
Time needed for installation
How to position your cable router
Position your cable router vertically. A central, elevated location is best. Objects or furniture positioned in front of your cable router will reduce Wi-Fi range.
How to avoid sources of interference
Do not place your cable router near a baby monitor or large metal objects such as a fridge or flat-screen TV.
Installing your cable router
Updates and activation can additionally take up to 10 minutes
15 minutes
Connecting devices with Wi-Fi or LAN 5-20 minutes, depending on the number of devices
Connecting your telephone optional
Activation can additionally take up to 10 minutes
5 minutes
Please also read the safety instructions for operation of our supplied devices, which are enclosed in our delivery. Other devices, e.g. telephone, laptop or tablet, are not included.
vodafone.de/installieren
Activating WPS
Similar to figure
or
1
4
Are accessories missing or do you need help with installation?
You can reach us by phone at: 0800 172 12 12
around the clock2a
3b
3a
2b
